Specifications
Type B Sintered wire mesh1. Good quality
2. Competitive price
3. Manufacture
4. ISO9001 & SGS certificated
Stainless Steel Wire Mesh-Type B Sintered Wire Mesh
Type B sintered wire mesh is sintered together by multi layers of plain-woven square mesh. Owing to the large aperture ratio, the sintered mesh possesses good permeability, large flow. It is mainly applied to air filter and liquid filter. It can be made according to the customer's request because every layer of wire mesh is alternative.
Material
The standard materials are SUS304(AISI304), SUS316(AISI316), SUS316L(AISI316L).
Special Alloy Steel Hastelloy, Monel, Inconel are available at customer's request .
Dimension
The standard sizes are 500x1000mm, 600x1200mm, 1000x1000mm, 1200x1200mm. Any size within the above ranges could be made according to the customer's request.
Application
Filter Disc
Sand-proofing Filter Tube in Petroleum
Filter Cartridge
Technical Data
Model |
Structure |
Filter rating (u) |
Thickness(mm) |
Weight(kg/m2) |
Porosity(%) |
B2-0.5T |
Filter layer+60 |
2-100 |
0.5 |
1.6 |
60 |
B3-0.7T |
60+Filter layer+60 |
2-100 |
0.7 |
2.4 |
56 |
B3-1.0T |
50+Filter layer+20 |
20-200 |
1.0 |
3.3 |
58 |
B3-2.0T |
Filter layer+20+8.5 |
20-250 |
2.0 |
6.5 |
58 |
B4-1.0T |
60+Filter layer+40+20 |
2-200 |
1.0 |
4.4 |
44 |
B4-1.7T |
40+Filter layer+20+16 |
2-200 |
1.7 |
6.2 |
54 |
B5-1.9T |
30+Filter layer+60+20+16 |
2-200 |
1.9 |
5.3 |
52 |
B5-2.5T |
80+Filter layer+30+10+8.5 |
2-200 |
2.5 |
8.8 |
55 |
B7-2.0T |
50+Filter layer+40+20+40+Filter layer+50 |
2-150 |
2.0 |
7.4 |
58 |
