Help CenterStainless Steel Type A Sintered Wire Mesh
Related Products
-
Stainless Steel 5-layer Sintered Wire MeshUS$ 200 - 500MOQ: 10 Pieces -
5-layer Type A Stainless Steel Sintered Wire MeshUS$ 200 - 500MOQ: 10 Pieces
-
Stainless Steel Type D Sintered Wire MeshUS$ 200 - 500MOQ: 10 Pieces
-
Type A Sintered Wire Mesh, 5-layer Sintered Wire MeshUS$ 200 - 500MOQ: 10 Pieces
-
Stainless Steel Wire Mesh-Type B Sintered Wire Mesh Anping FactoryUS$ 200 - 500MOQ: 10 Pieces
Specifications
Type A Sintered Wire MeshFiltering rate 1-100 micron
Material SS304, SS316, SS316L
500x1000, 600x1200, 1000x1000, 1200x1200
Type A Sintered Wire Mesh
The Structural Drawing of Type A Sintered Wire Mesh:
Type A Sintered Wire Mesh is a standard combination of 5-layer sintered wire mesh which has the widest application. Five different layers of stainless steel wire mesh are combined, and then sintered together through vacuum sintering, compressing, and rolling, forming a porous product.
Material:
The standard materials are SUS304(AISI304), SUS316(AISI316), SUS316L(AISI316L).
Special Alloy Steel Hastelloy, Monel, Inconel are acceptable base on customer's requirement.
Dimension:
The standard dimensions are 500x1000mm, 600x1200mm and 1000x1000mm, 1200x1200mm, and other dimensions in between are also available.
Characteristic:
Wide Range of Filtering Rate
It has the steady filter rating from 1 micron to 100 micron.
Steady Filtering Rate
Due to the two protective layers, the mesh of the filter layer is not easy to deform.
High Mechanical Strength
Owing to the support of fourth and fifth reinforcing layers, it has higher resistance to pressure and mechanical strength.
Easy to be Cleaned
It is very easy to be washed, especially to reverse wash, by virtue of adopting the surface layer filtration material
Heat Resistance
It can resist the heat up to 480°C.
Corrosion Resistance
It has the property of anti-corrosion as a result of adopting the material of SUS316L.
Tractability
It suits for many kinds of machining, such as cutting, bending, punching, stretching, welding and so on.
Technical Data:
Model |
Nominal Filter Rating |
Structure |
Thicknes s |
Air Permeability (L/min/cm2) |
Bubble Pressure (mm H2O) |
Weight |
Porosity |
A5-1 |
1 |
100+400×2800+100+12×64+64×12 |
1.7 |
1.81 |
360-600 |
5-layer sintered wire mesh(8.4)
6-layer sintered wire mesh |
37% |
A5-2 |
2 |
100+325×2300+100+12×64+64×12 |
1.7 |
2.35 |
300-590 |
||
A5-5 |
5 |
100+200×1400+100+12×64+64×12 |
1.7 |
2.42 |
260-550 |
||
A5-10 |
10 |
100+165×1400+100+12×64+64×12 |
1.7 |
3.00 |
220-500 |
||
A5-15 |
15 |
100+165×1200+100+12×64+64×12 |
1.7 |
3.41 |
200-480 |
||
A5-20 |
20 |
100+165×800+100+12×64+64×12 |
1.7 |
4.50 |
170-450 |
||
A5-25 |
25 |
100+165×600+100+12×64+64×12 |
1.7 |
6.12 |
150-410 |
||
A5-30 |
30 |
100+450+100+12×64+64×12 |
1.7 |
6.7 |
120-390 |
||
A5-40 |
40 |
100+325+100+12×64+64×12 |
1.7 |
6.86 |
100-350 |
||
A5-50 |
50 |
100+250+100+12×64+64×12 |
1.7 |
8.41 |
90-300 |
||
A5-75 |
75 |
100+200+100+12×64+64×12 |
1.7 |
8.7 |
80-250 |
||
A5-100 |
100 |
100+150+100+12×64+64×12 |
1.7 |
9.1 |
70-190 |
Note: The 6-layer sintered wire mesh is to be added one layer of 12 mesh to the 5-layer sintered mesh. Its thickness is 3.5mm, it has the higher anti-pressure ability.
