Germany CAT6 FTP Faceplate Wall Outlet
1. Auto-Machine Produce : stable quality & short leading time
2.100% QC test , 100% pass fluke test
3. OEM & ODM Services
4. Excellent R&D group support
5. Entity factory ,welcome to check the factory any time.
Description
Category 6 wall outlet (80 type Faceplate), fit for horizontal distribution in the equipment room and equipments connecting.
| Techinical Details: | ||||||
| Current Rating | 1.5 Amps | |||||
| Insulation Resistance | 500 Megaohm | |||||
| DC Resistance | 0.1 ohm MAX | |||||
| Voltage | 150 VAC MAX | |||||
| Insertion Life | ≥ 1000 Mating Cycles | |||||
| Plug Retention Force | 89N | |||||
| Temperature | — 60~80 °C | |||||
| IDC Accept | 22-24 AWG Solid Wire | |||||
| Wire Scheme | T568A/ B | |||||
| Test Standard | TIA CAT6 Perm Link | |||||
| Performance | Pass FLUKE Test | |||||
| Cable Insert | Cable Insert from Side( Horizontally) | |||||
| Material: | ||||||
| Housing | ABS& PC | |||||
| Shield | Zinc Die Casting | |||||
| Spring Wire | Phosphor Bronze With Gold-plated 6-50μover nickel | |||||
| IDC Contact | Phosphor Bronze | |||||
| IDC Holder | High Impact PC | |||||
| PCB | Glass Fiber (One PCB) | |||||
