1, main technical data:
upper roller adding pressure: 490T
Max width of roll board 12500mm
The length of working rolls 12600mm
Up roll diameter Φ380mm
Down roll diameter Φ320mm
Up Support roll diameter: Φ350mm
Down support roll diameter: Φ270mm
Distance between two down rolls 440mm
Support rolls group: 7
No rolls of each group: 2 upper/ 4 down
Drive speed about 3.5m/min
Upper roll move speed while add pressure: 150mm/min
Max capacity of coiled board : T20*B125008R500(σs≤345Mpa)
Max stroke of upper roll: 410mm
Hydraulic system working pressure: 19.5MPa
Hydraulic motor 22KW
Main motor 55KW
Power:
