Specifications
3-roller steel plate rolling machine1,PLC control
2,pre-bending function
3,framous brand parts
1, main technical data:
upper roller adding pressure: 690T
Max width of roll board : 12500mm
The length of working rolls 12600mm
Up roll diameter: Φ430mm
Down roll diameter: Φ350mm
Up Support roll diameter: Φ360mm
Down support roll diameter: Φ300mm
Distance between two down rolls : 540mm
Support rolls group: 7
No rolls of each group: 2 upper/ 4 down
Drive speed: about 3.5m/min
Upper roll move speed while add pressure: 150mm/min
Max capacity of coiled board : T25*B125008R900(σs≤345Mpa)
Max stroke of upper roll: 410mm
Hydraulic system working pressure: 19.5MPa
Hydraulic motor: 30KW
Main motor 75KW
Power: 380V50HZ
2,supplier range :
2-1 include supplier range
1) whole machine
2) electrical system
3) hydraulic system
4) lubricate device
5) motor wire parts and necessaries.
6) hydraulic pipe parts and necessaries.
7) lubricate pipe parts and necessaries.
8) painting
9) foundation bolt and cushion
10) standard tools
11) standards parts
2-2 not include supplier range
1) user factory foundation device, wires, pipes and other parts.
2) Accessional board surrounding the machine.
3) The wire from power to electrical box.
4) Grounding parts and necessaries.
5) Hydraulic oil and lubricate crease.
working processing
