Specifications
1Black plastic Clamp Handle.2Internal and External Thread Clamp Handle.
3Different thread size are available.
Clamp handle,Clamping handle, adjustable clamp handle.Female clamp handle.
Hygoal supply all kinds of clamp handle.There are black Thermoplastic, black oxided steel and stainless steel are available.
Adjustable cam levers allow quick and fine adjustment of the clamping action. A knurled setting ring allows the best clamping force on the lever, while allowing the lever to be positioned in any desired direction. The slightly arched shape of the lever and its end shape provide a safe and comfortable grip, as well as an elegant design.
Base Diameter |
25 mm |
Handle Length (From Mount Center) |
79 mm |
Handle Material |
Plastic |
Height(To Hinge Pin Center) |
26.5 mm |
Hinge Pin Diameter |
8.1 mm |
Measurement System |
Metric |
Mount Type |
Internal Thread |
Thread Size |
M8 |
Type |
Adjustable |
Line Drawing: | |
A |
M8 |
B |
8.1 mm |
D |
25 mm |
F |
26.5 mm |
L |
79 mm |
Black Plastic
Internal and External Thread
Metric
A |
B |
D |
F |
L |
Thread Length |
Item No. |
M8 |
8.1 |
25 |
26.5 |
79 |
/ |
HG-G-732 |
M8 |
8.1 |
25 |
26.5 |
79 |
25 |
HG-G-733 |
M8 |
8.1 |
25 |
26.5 |
79 |
50 |
HG-G-734 |
