High Temperature High Pressure Resistant Epoxy Resin Fiberglass Insulation Tube

High Temperature High Pressure Resistant Epoxy Resin Fiberglass Insulation Tube

PRODUCT DESCRIPTION

High Temperature High Pressure Resistant Epoxy Resin Fiberglass Insulation Tube is manufactured with glassfiber and thermal plastic epoxyresin.It is braided by glassfiber in high pressure. It adopts reasonable helical angle and suitable tensile strength.To make sure the pressure is equal to every strand and form a stable structure. UL and RoHS compliant.

WORKING TEMPERATURE

-40°c ~ 125°c

APPLICATION

High Temperature High Pressure Resistant Epoxy Resin Fiberglass Insulation Tube is widely applied to dynamoelectric tool, home appliances, park tool and other electricity equipments.

CHARACTERISTICS

Main advantages:
-Compressing and assisting tool

-Precision and automate equipment
-Reduce cost

-Tube can be compressed, the other material -can reuse

-Excellent electricity design

-UL registered material (NFW -G-10)

Other features:
-Flexible design and size                                      -Simple design and save time
-Lead time is only 4~6 weeks if reassemble.                     -Low power
-Reduce changing time                                       -Environmental

-No storage time limited (The storage molding material is 60-120 days)

Electrical application:
-Dielectric withstand 14kV/mm                                -Longitudinal strength: 144MPa
-5000 V high voltage test for 6 seconds.                        -Water absorption is less than 0.1% in 24 hours

-Density hits 1.85 g/m3                                       -Volume resistivity: 10¹⁵

-Softening point: 240ºC                                      -NFW-G-10
-Insulation grade H                                           -Min thickness: 0.074 mm
-Temperature: 180°C                                         -UL 94 Flammability is 94HB

Standard tolerance:

- ID: ±0.0010” ±0.025mm        - length±0.010” ±0.25mm
- OD±0.0005” ±0.0125mm       - Concentricity: (TIR) 0.004” 0.10mm
