Plastic Corrugated Hose Extrusion Blow Machine
US$ 8,000 - 15,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Other, plastic pipe
Plastic Processed:
PE
Payment & Shipping
Payment Methods:
Port of Shipment:
xingang
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Plastic Corrugated Tube Extrusion Blow MachineUS$ 8,000 - 15,000MOQ: 1 Set -
Plastic Corrugated Tube Extruder Blow MachineUS$ 8,000 - 15,000MOQ: 1 Set
-
Plastic Cricket Bat Blow Molding MachineUS$ 8,000 - 15,000MOQ: 1 Set
-
Seed Tube Extrusion Blow MachineUS$ 8,000 - 15,000MOQ: 1 Set
-
Seed Tube Extrusion Blowing MachineUS$ 8,000 - 15,000MOQ: 1 Set
Condition
New
Application
Other, plastic pipe
Plastic Processed
PE
Blow Moulding Type
Extrusion Blow Moulding
Automatic
Yes
Place of Origin
Hebei, China
Brand Name
zhongyi
Model Number
xsj-3
Voltage
380V
Power(W)
20.5KW
Dimension(L*W*H)
3400*1400*2200
Weight
1400KG
Warranty
one year
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
plastic corrugated hose extrusion blow machine1.ours is a manufacture company
2.save energy
3.simple operation
4.fast-speed
plastic corrugated hose extrusion blow machine:
type |
XSJ-3 |
the length of the product mm |
800-1100 |
the quantity of the mould head |
1 |
the quantity of the mould |
2 |
production capacity pcs/hour |
700-800 |
screw diameter mm |
65 |
screw L/D |
1:25 |
the max quantity of extrusion HDPE kg/hour |
55 |
mould-locking type |
pneumatic |
the max mould dimension mm |
140×100×1200 |
blowing pressure Mpa |
0.4-0.6 |
gas consumption m3/min |
0.3 |
cooling pressure Mpa |
0.2-0.3 |
the electric power of the extruder machine kw |
11 |
The heating power of the extruder machine kw |
9.5 |
L*W*H mm |
3400×1400×2200 |
Weight KG |
1400 |
the suitable raw material |
PE/PP |
