Auto Heater Control Valve Flange Connect
Name:Auto Heater Control Valve Flange Connect
Model: 200X
Diameter:DN40-DN800
Medium:Fresh water,sewage,sea water,weak acid,weak base etc.
Temperature:0°C~80°C
Body material:Grey cast iron,ductile iron
Connection:Flange
Features of Auto Heater Control Valve Flange Connect:
Using direct acting diaphragm type structure, the internal structure is very simple, no jam, reliable performance, durable. Stain resistant scale, needs no filters, no need to by-pass pipe, the pipe is very simple, can save a lot of space and piping costs. Outlet pressure precision adjustable, in general situation, can be thought of outlet pressure is not affected by the inlet pressure, outlet pressure variation is 8% of the delta, P1). Excellent hydraulic characteristics, small pressure loss, reduced pressure ratio can reach more than 10:1. Can meet the requirements of a variety of relief, especially suitable for the manifold pressure relief system.
Function and use: use medium pressure changes to finish self-control while maintaining the controlled system through which the same medium pressure valve. Apply for dual-pipe heating system, pressure control. Assurance system will remain basically unchanged, reducing noise, balanced resistance, eliminate fire and water heating network imbalance.
| Nominal Pressure | 1.0MPA | 1.6MPA | 2.5MPA |
| Test pressure of the shell | 1.5MPA | 2.4MPA | 3.75MPA |
| Sealed test pressure | 1.1MPA | 1.76MPA | 2.75MPA |
| Suitable temperature | ≤80°C | ||
| Suitable medium | water | ||
In the 19 years, we have customers in many countries around the world.
1.We promise no leakage and breakage for valves. Every butterfly valve will test for 2 times test pressure before leave factory. We will replace the valve if there is quality problem within 24 months guarantee period.
2.We obtained ISO9001 quality system certification.We inspect the parts of valve carefully, 48 produce steps, try to supply you ideal valve.
3.We can supply different kinds of materials according to customers' requests,such as DI,cast steel,SS304,SS316 body and disc. EPDM,NBR,PTFE,Viton etc. Enough stock ensure fast delivery.
4.We have more than 150 types body moulds, which include ISO,DIN,ANSI,BS standard.
5.We own full-automatic machine paint line, match high-temperature baking house,which makes smooth paint and good appearance of valve.
About Jinerjian
Jinerjan (Tianjin) Valve Co., Ltd. is a manufacturer which is specialized in researching, producing and exporting wafer butterfly valves, flange butterfly valves, electric butterfly valves, pneumatic butterfly valves and dual plate check valves. Through all staff"s efforts, our business has expanded rapidly in the past 18 years. We have set up foundry, machining and assembly workshop
