Forklift Truck Price CPCD60A

Forklift Truck Price CPCD60A thumbnail-1
Forklift Truck Price CPCD60A photo-1
US$ 10,000 - 30,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
China
Model Number:
CPCD60A
Contact Supplier Request Quote Chat Now
Zhengzhou Dongfeng Mid-South Enterprise Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Tianjin Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin China
Model Number CPCD60A
Type Powered Pallet Truck
Rated Loading Capacity 6000kg
Max. Lifting Height 6000mm
Min. Lifting Height 3000mm
Fork Length 1220mm
Fork Width 175mm
Overall Dimensions 4780x1910x2430mm
Certification CE & ISO9001

Specifications

1. ISO&CE certificate
2. One year warranty
3. OEM color & logo



Mode CPCD60 A   Rear overhang 730mm   Axle loading-with/withoutrated load ,front  17920/5940kg
 Power type  Diesel  Overall length  5460mm  Engine- Model  LR6108G73
 Rated capacity  6000kg  Overall width  2164mm  Engine-Manufacturer Yituo
 Load center 600 mm  Overall height-Extendedheight(mast)  4315mm  Engine-Rated output  88/2200 kw
 Lift height  3000mm  Overall height-Lower Height (mast)  2850mm  Engine- Rated torque  440/1600 kw N .m/r/min
 Free lift height 200 mm  Overall height-Overhead guard  2490mm  Engine- Displacement  6.87L
 Mast tilt angle (Forward/Backward)  6°/12°Deg  Height of traction bar  510mm  Gearbox-Transmission type  Hydraulic
 Lift speed (with/without load) 320/340mm/s   Wheelbase  2800mm  Gearbox-Transmission
number of speed(Front/Rear)		  2/2
 Lower speed (with/without load)  with<600 without>300mm/s  Tread- front 1600 mm  Battery- Voltage  24V
 Max. gradeability (with load)  20%  Tread- Rear  1700mm  Battery-Capacity  2*100Ah
 Min. turning radius 3950mm  Tyre- Model- Front  9.00-20-14PR
  		  Travel speed (with/without load)  23/26km/h
 Min. intersecting aisle  3660mm  Tyre- Model-Rear  9.00-20-14PR

 fork Length 1220mm  Groundclearance- Under mast  195mm
 fork Width  175mm  Groundclearance-Center of wheelbase  245mm
 fork Thickness  80mm  Service brake- Travel brake  Hydraulic
  Fork carriage width 350-2140 mm  Service brake-Parking brake  Mechanical
  Front overhang 710 mm  Self.weihgt  13200kg



 Warranty Period: 12 months(calculating from the date the vehicle arrives at the destination port)
