Forklift Truck Price CPC40

Forklift Truck Price CPC40 thumbnail-1
Forklift Truck Price CPC40 photo-1
US$ 10,000 - 25,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
China
Model Number:
CPC40
Contact Supplier Request Quote Chat Now
Zhengzhou Dongfeng Mid-South Enterprise Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Tianjin Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin China
Model Number CPC40
Type Powered Pallet Truck
Rated Loading Capacity 4000kg
Max. Lifting Height 3000mm
Min. Lifting Height 195mm
Fork Length 1070mm
Fork Width 140mm
Overall Dimensions 2970x1310x2170mm
Certification CE & ISO9001

Specifications

1. ISO&CE certificate
2. One year warranty
3. OEM color & logo

4 tons diesel forklift truck YTO CPC40 with competitive price

Performance of the CPC40 Diesel Forklift

  1. Digital intelligent drive-monitoring system can facilitate obtaining an operating data of forklifts so as to achieve the whole-process control.
  2. Full hydraulic steering system reduces the operator’s fatigue greatly; it uses a horizontal oil cylinder on the compact steering axle, and garantees a steering reliability.
  3. The classically YTO ASF space frame structure applies an ergonomic & aesthetic design with an elegant outlook, a compact structure, and a comfortability in operation.
  4. The optimized rail section design of the mast has the driver enjoyed a wide-view.

Technical Parameter of the CPC40 Diesel Forklift

Speciality parameter Model     CPC40
Power type     Diesel
Rated capacity   kg 4000
Load center d mm 500
Lift height h2 mm 3000
Mast tilt angle(forward/backward) α/β Deg 6/12
Front overhang L3 mm 515
Wheel-base L4 mm 1900
Tread(front/rear) b4/b5 mm 1040/980
Performance parameter Travel brake     Hydraulic-Foot pedal
Parking brake     Mechanical-Hand level
Lift speed(with/without load)   mm/s 380/440
Lower speed(with/without load)   mm/s laden<600,without load>300
Travel speed(with/without load)   km/h 19/20
Max. gradeability(laden)   % 18
Max.Towing(with/without load)   KN 20/16
Weight Distribution with load(front/rear)     8190/800
Weight Distribution without load(front/rear)     2050/2910
Power,transmission and others Engine Model     A495BPG
Manufacturer     Xinchang
Rated power   kw 40/2650
Rated rotation     174/1800
Displacement     2.98
Battery Voltage   V 12
Capacity   Ah 100
Gearbox Transmission type     Mechanical
Gears,speed(front/rear)     Ⅱ/Ⅱ
Tyre type     Pneumatic tyres
Model Front     250-15-16PR
Rear     6.5-10-12PR
Others Dead.weight   kg 5000
Free lift height h4 mm 170
Fork Thickness×Width×Length c×b×a mm 50×140×1070
Overall dimensions Overall length(without forks) L2 mm 2970
Overall width b1 mm 1310
Overall height Extended height(mast) h1 mm 4240
Lowered height(mast) h3 mm 2170
Overhead guard h7 mm 2170
Min. turning radius Wa mm 2710
Min.under ground clearnce Under mast m1 mm 135
Center of wheel-base m2 mm 160



 Warranty Period: 12 months(calculating from the date the vehicle arrives at the destination port)



Other Forklift Truck Series:

Forklift Truck Price CPC40

Sales manager: Ms. Dream Chen

Dongfeng Group

Dongfeng Mid-south Enterprise Co., Ltd.

Cell: 0086-18538016313

Skype:overseas_dongfeng04
