Forklift Truck Price CPC15

Forklift Truck Price CPC15 thumbnail-1
Forklift Truck Price CPC15 photo-1
US$ 10,000 - 30,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
China
Model Number:
CPC15
Contact Supplier Request Quote Chat Now
Zhengzhou Dongfeng Mid-South Enterprise Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Tianjin Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin China
Model Number CPC15
Type Powered Pallet Truck
Rated Loading Capacity 1500kg
Max. Lifting Height 6000mm
Min. Lifting Height 3000mm
Fork Length 920mm
Fork Width 100mm
Overall Dimensions 2210x1080x1995mm
Certification CE & ISO9001

Specifications

1. ISO&CE certificate
2. One year warranty
3. OEM color & logo

Speciality parameter Model     CPC15
Power type     Diesel
Rated capacity   kg 1500
Load center d mm 500
Lift height h2 mm 3000
Mast tilt angle(forward/backward) α/β Deg 6/12
Front overhang L3 mm 425
Wheel-base L4 mm 1400
Tread(front/rear) b4/b5 mm 890/925
Performance parameter Travel brake     Hydraulic-Foot pedal
Parking brake     Mechanical-Hand level
Lift speed(laden)   mm/s 440
Lower speed(with/without load)   mm/s laden<600,without load>300
Travel speed(without load)   km/h 15
Max. gradeability(laden)   % 20
Max.Towing(with/without load)   KN 13/11
Weight Distribution with load(front/rear)     3560/680
Weight Distribution without load(front/rear)     1080/1660
Power,transmission and others Engine Model     NC485BPG
Manufacturer     Xinchang
Rated power   kw 30/2600
Max.rotation     131/1800
Displacement     2.27
Battery Voltage   V 12
Capacity   Ah 100
Gearbox Transmission type     Mechanical
Gears,speed(front/rear)     Ⅱ/Ⅱ
Tyre type     Pneumatic tyres
Model Front     6.5-10-10PR
Rear     5.0-8-8PR
Others Dead.weight   kg 2740
Free lift height h4 mm 135
Fork Thickness×Width×Length c×b×a mm 35×100×920
Overall dimensions Overall length(without forks) L2 mm 2210
Overall width b1 mm 1080
Overall height Extended height(mast) h1 mm 3975
Lowered height(mast) h3 mm 1995
Overhead guard h7 mm 1995
Min. turning radius Wa mm 2050
Min.under ground clearnce Under mast m1 mm 110
Center of wheel-base m2 mm 140



 Warranty Period: 12 months(calculating from the date the vehicle arrives at the destination port)
