Help CenterDIGITAL MULTIMETER DT4253
US$ 346.67 - 346.67
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
China
Brand Name:
HIOKI
Model Number:
DT4253-20
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
DIGITAL MULTIMETER DT4281US$ 716.67 - 716.67MOQ: 1 Set -
DIGITAL MULTIMETER DT4282US$ 875 - 875MOQ: 1 Set
-
Clamp Ground Resistance Tester FT6380US$ 1,876.67 - 1,876.67MOQ: 1 Set
-
HIOKI IR4056-20 Digital Megger (HiTESTER 3454-11)US$ 416.67 - 416.67MOQ: 1 Set
-
HIOKI IR4057-20 Digital Megger (HiTESTER 3454-11)US$ 666.67 - 666.67MOQ: 1 Set
Place of Origin
China
Brand Name
HIOKI
Model Number
DT4253-20
Operating Temperature
-10℃~50℃
Dimensions
84 mm*174 mm*52 mm
Product Description
Regarding DMM Accuracy
Due to the many ranges and functions available in a DMM, only the basic accuracy is indicated for reference. Please refer to the individual catalogs for detailed accuracy information.
| DC voltage | 600.0 mV to 1000 V, 5 ranges, Basic accuracy: ±0.3 % rdg. ±5 dgt. |
|---|---|
| AC voltage 40 to 500 Hz | 6.000 V to 1000 V, 4 ranges, Frequency characteristics: 40 Hz - 1 kHz Basic accuracy: ±0.9 % rdg. ±3 dgt. (True RMS, crest factor 3) |
| Resistance | 600.0 Ω to 60.00 MΩ, 6 ranges, Basic accuracy: ±0.7 % rdg. ±5 dgt. |
| DC current | 60.00 μA to 60.00 mA, 4 ranges, Basic accuracy: ±0.8 % rdg. ±5 dgt. |
| AC current, 40 to 500 Hz | N/A |
| AC current (use with the clamp on probes) 45 to 1k Hz | 10.00 A to 1000 A, 7 ranges Add the Clamp on probe accuracy to Basic accuracy: ±0.9 % rdg. ±3 dgt. (True RMS, crest factor 3) |
| Temperature (use with DT4910) | K: -40.0 to 400.0 °C, Add the Temperature probe accuracy to Basic accuracy: ±0.5 % rdg. ±2 °C |
| Voltage detection | N/A |
| C (capacitance) | 1.000 μF to 10.00 mF, 5 ranges, Basic accuracy: ±1.9 % rdg. ±5 dgt. |
| Frequency | AC V, AC A measurement: 99.99 Hz (5 Hz or more) to 9.999 kHz, 3 ranges, 99.99 kHz (only for AC V) Basic accuracy: ±0.1 % rdg. ±1 dgt. |
| Continuity check | Continuity threshold [ON]: 25 Ω or less (Indicate buzzer sound, red LED), [OFF]: 245 Ω or more Response time: 0.5 ms or more |
| Diode test | Open terminal voltage: 5.0 V or less, Testing current 0.5 mA or less, Threshold of forward voltage: 0.15 V to 1.5 V |
| Other functions | Filter function, Display value hold, Auto hold, Max/Min/Average value display, Relative display, Auto-power save, USB communication (option) |
| Display | Main and Sub displays: 4-digits LCD, max. 6000 digits, bar graph |
| Display refresh rates | 5 times/s (Capacitance measurement: 0.05 to 5 times/s, depending on measured value, Frequency: 1 to 2 time/s, Temperature: 1 time/s ) |
| Power supply | LR03 alkaline batteries ×4, Continuous use: 130 hours (back light OFF) |
| Dimensions and mass | 84 mm (3.31 in)W × 174 mm (6.85 in)H× 52 mm (2.05 in)D, 390 g (13.8 oz) (with batteries and holster) |
| Accessories | Test lead L9207-10 ×1, Holster ×1, Instruction manual ×1, LR03 alkaline battery ×4 |
