Netis Portable DSL Modem Router
Negotiable
MOQ: 1000 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Products Status:
Stock
Style:
Internal
Type:
Wireless
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Netis Wired ADSL ModemNegotiableMOQ: 1000 Sets -
Netis ADSL Modem RouterNegotiableMOQ: 1000 Pieces
-
Netis ADSL Modem for High Speed Internet ConnectionNegotiableMOQ: 1000 Pieces
-
Netis Wireless ADSL Modem DL-4101NegotiableMOQ: 1000 Pieces
-
Netis 300Mbps Wireless N ADSL2+ Modem Router, Detachable AntennasNegotiableMOQ: 1000 Pieces
Products Status
Stock
Style
Internal
Type
Wireless
Interface Type
Other, 1 * 10/100M Auto MDI/MDIX RJ45 1*RJ11
Transmission Rate
Other, Downstream: Up to 24Mbps Upstream: Up to 1Mbps
Certification
CE FCC
Brand Name
netis
Model Number
DL4201
Place of Origin
Guangdong, China
netis Portable DSL Modem Router
Product Description
The netis DL4201 Wired ADSL2+ Modem Router is a high performance modem router that provides a full rate of ADSL2+ standard. It is a 2 in 1 device that combines the function of a high-speed DSL modem and a one-Port 10/100Mbps router. With the built-in Quick Start Wizard, you can easily create a secure and high-speed wired network to share files, music, photos, and printers with multiple computers.
Features
- 2 in 1: Combine ADSL2/2+ Modem and Router in a single device
- Provides Quick Start Wizard to help you set up your network in Minutes
- Slim body design.Idea for home and office use
- LEDs indicate port activity
Specification
| netis Portable DSL Modem Router | |
| Hardware | |
| Interface | 1 * 10/100M Auto MDI/MDIX RJ45 1*RJ11 |
| LED | InternetADSL LAN Power |
| Power Supply | DC 5V/0.8A(Output) |
| Dimensions (L x W x H ) | 72mm X 69mm X 25mm |
| Software | |
| Standards | IEEE 802.3,IEEE 802.3u |
| Data Rate |
Downstream: Up to 24Mbps Upstream: Up to 1Mbps |
| ADSL Feature |
Full-rate ANSI T1.413 Issue 2 ITU-T G.992.1(G.DMT) ITU-T G.992.2(G.Lite) ITU-T G.992.3 ITU-T G .992.5 ITU-T K.2.1 |
| ATM / PPP Protocols |
ATM Forum UNI3.1/4.0 PVC (up to 8PVCs) ATM Adaptation Layer Type 5 (AAL5) ATM QoS Bridged and routed Ethernet encapsulation VC and LLC based multiplexing PPP over Ethernet (RFC2516) PPP over ATM (RFC 2364) IPoA (RFC1577/2225) |
| Main Features |
DHCP, DHCP relay NAT, Static Routing VPN (PPTP, L2TP, IPSec) Pass-through PVC/Ethernet Port Mapping DNS Relay, DDNS IGMP Multicast, IGMP snooping V1/V2 Virtual server, DMZ, ACL (Access Control List) UPnP |
| Management |
Web Based Configuration (HTTP), Remote management, Telnet management, command Line Interface, TR-069, SNMP, Web Based Firmware Upgrade, CWMP (TR-069), Diagnostic Tools |
| Others | |
| Certification | CE FCC |
| Environment |
Operating Temperature: 0℃~40℃ Storage Temperature: -40℃~70℃ Operating Humidity: 10%~90%RH non-condensing Storage Humidity: 5%~90%RH non-condensing |
| Package |
1 * DL4201 1 * Quick Installation Guide 1 * Power Adapter 1* Ethernet Cable 2* RJ11 cable 1* Splitter |
For more information about our company and products, please visit our official website .
