8 tubes skid CNG tube trailer
Tube quantity: 8 PCS
Working pressure: 20Mpa, 25Mpa
CNG filling capacity: 4466Nm3, 4540Nm3
Burst pressure: 33.4Mpa, 37.65Mpa
Chassis: Two axis
² CNG tube trailer skid tube container is made by jumbo tube for storage and transporting of CNG and other
compressed gas (e.g. hydrogen, helium, oxygen, etc.), by using tubular shape storage with working pressure
200bar, 250bar, which are approved by ISO11120:1999 standard for transportation purpose, the tubes will
fitted into 20ft, 40ft ISO containers, enables them transportable by trailer and supply CNG to daughter station
or non-piping region.
² Tube skid container of CNG tube trailer is an ideal way for CNG mass transportation, with CNG capacity up to
8481Nm3 per container, also it is a more reliable, safer and lower cost way than small cylinder cascade.
Larger capacity with fewer valves and tubes to avoid gas leakage, simple structure, easier daily maintenance,
minimize the cost of CNG.
Specific Parameter of 8 tubes skid container CNG tube trailer
| CNG Tube Skid Container Data Sheet (8 tubes) | |||||
| Tube Skid Container |
Net Weight (without chassis) | 23310Kg | Jumbo Tube | Tube Qty | 8PCS |
| CNG Loading Weight | 3672Kg | Total Water Volume | 16.16NM3 | ||
| Total Weight (without chassis) | 26982Kg | Hydratastic Test Pressure | 375bar | ||
| CNG Loading Volume | 5100NM3 | (ODxWTKxL) | φ559x17.4x9920mm | ||
| Working Pressure | 250bar | Remark | Chassis | Two axis | |
| Leakage Test Pressure | 250bar | Working Temp | -40~60°C | ||
| Container Diemension | 12192x2438x1400mm | Approval | BV, ISO, CE | ||
| Bursting discs | Burst Pressure | 375bar | Release-hole Diameter | ≥φ20 | |
The above specification is one of our regular one, special specification tailored for Customers' are available.
CNG tube skid container
CNG tube trailer Display
Company Information
Yukun Machinery Co., Ltd has many years experiences in producing cng gas cylinder, cng tubes container, lng tanker, cng-1 cylinder, cng-2 cylinder, jumbo cylinder, winding cylinder, cryogenic gas transport equipment, cng tube trailer etc. with the most certificates, including ISO, DOT, CE, KGS, ASME etc, and our products have export to more than twenty countries, such as USA, Colombia, Peru, Brazil, Thailand, Indonesia, Nigeria, Egypt, etc, the up to world class quality and good service won the great reputation among the customers.
Payment Terms
Money Transfer, PayPal, Money Gram, Bank Transfer, Escrow, Way of payment T/T or Western Union
Order's payment: T/T 30% deposit, T/T balance before delivery
Bulk Order Shipping
By Sea/By Air
