8 tubes skid CNG trailer truck
Tube quantity: 8 PCS
Working pressure: 25Mpa
CNG filling capacity: 16.16NM3
Container Dimension: 12192x2438x1400mm
Chassis & Tractor: Optional Triple axis chassis, natural gas (CNG, LNG) powered tractor.
The whole structure of semi trailer truck is divided into walking structure, large volume seamless steel cylinder and connecting device three parts. Walking structure meets the GB1589-2004 standard of loading mass and the axle load, and can be modified according to the special structure of the loading cylinder. 4 tubes skid CNG semitrailer truck not only can transport CNG, but also is an essential part of CNG filling station, other parts are hydraulic boost skid, CNG dispenser, PLC control panel, etc.
Specific Parameter
| CNG Tube Skid Container Data Sheet (8 tubes) | |||||
| Tube Skid Container |
Net Weight (without chassis) | 23310Kg | Jumbo Tube | Tube Qty | 8PCS |
| CNG Loading Weight | 3672Kg | Total Water Volume | 16.16NM3 | ||
| Total Weight (without chassis) | 26982Kg | Hydratastic Test Pressure | 375bar | ||
| CNG Loading Volume | 5100NM3 | (ODxWTKxL) | φ559x17.4x9920mm | ||
| Working Pressure | 250bar | Remark | Chassis | Two axis | |
| Leakage Test Pressure | 250bar | Working Temp | -40~60°C | ||
| Container Diemension | 12192x2438x1400mm | Approval | BV, ISO, CE | ||
| Bursting discs | Burst Pressure | 375bar | Release-hole Diameter | ≥φ20 | |
The above specification is one of our regular one, special specification tailored for Customers’ are available.
Product Details
Related Products
Payment Terms
Money Transfer, PayPal, Money Gram, Bank Transfer, Escrow, Way of payment T/T or Western Union
Order's payment: T/T 30% deposit, T/T balance before delivery
Bulk Order Shipping
Note
If you are interested in our products and want to know more information, please tell us your requirements as follows:
a. The working pressure
b. Volume capacity
c. Certificates requirements
d. Others factors you want to know
