Application
As a tedder: it can spread and flip the green-cut materials and withdraws, for drying evenly.
1). Spread, swath or windrow so crops dry down faster,
2). Tailor your tedding operations to a variety of crops and conditions by varying PTO speed or tine position,
3). Fixed-tine position provides aggressive tedding and is ideal for use in fresh-cut material or crops where leaf and shatter losses are not a concern
4).Cam-operated tine position allows the tine bar rollers to follow the cam track to lift and release crop gently and save valuable leaves
As a rake: it can collect teh dried materials into lines fro balers to pick up and pack them.
1). Precise raking action produces fluffy, uniform windrows that dry evenly
2). Self-centering wheels provide extral maneuverability by allowing you to make sharp turns and back up easily without lifting the machine.
The specification of hay rake
Model |
MGR2500 |
MGR3500 |
MGR400 |
Tedding width |
250cm |
350cm |
400cm |
Dimension |
2100x2500x950mm |
3100*3500*1000mm |
4010x3539x1196mm |
Weight |
160kg |
200kg |
290kg |
Tines of per rotors |
4 |
6 |
6 |
No of rotors |
6 |
8 |
8 |
Working speed |
4-8km/h |
4-8km/h |
4-8km/h |
Matched power |
18-50hp |
20-80hp |
35-80hp |
PTO RPM |
540r/m |
540r/m |
540r/m |
1.By adjusting the tines,hay rake can be used as rake or tedder.
2.as a tedder,it can spread and flip the green-cut materials and withdraws,for drying evenly.
3.as a rake,it can collect the dried materials into lines for balers to pick up and pack them.
Shandong Weifang Xiaer Machinery Co., Ltd. was founded in the year of 2006, which was conveniently located in Weifang city, is only 180km to Qingdao port and Qingdao airport.
Our company has accumulated abundant designing and manufacturing experience in agricultural machinery and components, brought up a group of experienced technical managements, and formed a well-trained staff team. With a whole set of perfect production system and quality assurance system, the technical level of the company keeps ahead at home. And parts of products are exported to the countries all over the world with the main body.
No business too small, no problem too big.
