Help CenterPultruded FRP Cable Tray 400mm Width, 200mm Height, 3mm Wall, Anti-Static, Non-Conductive
Product Spotlights
Related Products
-
Corrosion Resistant FRP Cable Tray 50mm Depth, 2.5mm Thickness, Mill Test Report AvailableNegotiableMOQ: 300 Meters -
FRP Cable Tray 300mm x 100mm x 6000mm, UV Resistant, Fire Retardant Class V-0, 150kg/m Load CapacityNegotiableMOQ: 300 Meters
-
FRP Cable Tray With 5-Year Warranty, Mill Test Report Included, 300mm x 100mm x 6000mmNegotiableMOQ: 300 Meters
-
FRP Cable Tray for Chemical Plants, Corrosion Resistant, 200mm x 100mm, 2.5mm ThickNegotiableMOQ: 300 Meters
-
Molded FRP Cable Tray 200mm Depth, 4mm Thick, High Mechanical Strength, 300kg/m CapacityNegotiableMOQ: 300 Meters
As a leading manufacturer based in Hengshui, Hebei, China, Hengshui Ruibin New Materials LLC specializes in high-quality FRP composite solutions. Our Pultruded FRP Cable Tray with 400mm width, 200mm height, and 3mm wall thickness is engineered to provide superior performance in demanding environments. This cable tray is anti-static and non-conductive, making it an ideal choice for electrical and data cable management where safety and reliability are paramount. With over 101-200 skilled employees and annual export value exceeding US$2.5 million, we deliver products that meet international standards.
Our pultrusion process ensures consistent fiber alignment and resin impregnation, resulting in a lightweight yet strong cable tray that resists corrosion, UV radiation, and chemical attack. The 400mm width offers ample space for multiple cables, while the 200mm height provides robust protection. The 3mm wall thickness enhances structural integrity, supporting heavy loads without deformation. Whether used in power plants, communication towers, or industrial facilities, this tray delivers long-term durability.
Key Features & Benefits
- Anti-Static & Non-Conductive: Eliminates the risk of static discharge and electrical shock, ideal for sensitive electronic environments.
- Corrosion Resistant: Withstands harsh chemicals, moisture, and salt spray, extending service life in marine or industrial settings.
- High Strength-to-Weight Ratio: Easy to handle and install, reducing labor costs and support structure requirements.
- Fire Retardant: Classified as self-extinguishing (optional formulation available upon request).
- UV Stabilized: Maintains mechanical properties and appearance under prolonged sun exposure.
- Customizable Lengths: Available in standard 6m lengths or cut to customer specifications.
Technical Specifications
| Parameter | Value |
| Width | 400mm |
| Height | 200mm |
| Wall Thickness | 3mm |
| Material | E-glass fiber + polyester/vinyl ester resin |
| Load Capacity | Up to 150 kg/m (depending on support span) |
| Operating Temperature | -40°C to +120°C |
| Flame Spread Index | ≤25 (ASTM E84) |
| Surface Resistivity | 10^6 - 10^9 Ω/sq (anti-static) |
| Color | Yellow, gray, or custom |
| Standard Length | 6m (customizable) |
The anti-static property is achieved through the inclusion of conductive carbon fibers or special additives, ensuring static dissipation in sensitive areas like data centers and chemical plants. The non-conductive nature of the FRP matrix prevents accidental grounding and reduces the risk of short circuits. Additionally, the tray's smooth surface minimizes cable abrasion, prolonging cable life.
Why Choose Hengshui Ruibin?
Since 2019, we have grown into a reliable manufacturer with a factory spanning 1,000-3,000 square meters. Our team of 101-200 professionals ensures strict quality control from raw material selection to final packaging. We hold ISO9001 and ISO9000 certifications, reflecting our commitment to consistent quality. Our products are exported to major markets including North America, South America, Europe, Southeast Asia, Africa, and Oceania, shipped via Tianjin or Qingdao ports. With annual export value between US$2.5 million and US$5 million, we have proven our capability to serve global clients efficiently.
We offer customization options for length, color, and additional features such as UV protection or enhanced fire retardancy. Each tray undergoes rigorous testing for dimensional accuracy, load capacity, and anti-static performance. Our competitive pricing, combined with fast delivery and responsive technical support, makes us a preferred partner for cable management projects.
Contact us today for a quote or sample. Let our Pultruded FRP Cable Tray bring safety and reliability to your next installation. We are committed to providing solutions that exceed your expectations.
Frequently Asked Questions
-
Q: Is this cable tray suitable for outdoor use?
A: Yes, the FRP material is UV stabilized and corrosion resistant, making it ideal for outdoor environments such as solar farms, substations, and railway tracks. -
Q: Can I get the tray in different colors?
A: Absolutely. We offer standard colors like yellow and gray, and can customize to match your requirements. Color additives are integrated during the pultrusion process for long-lasting finish. -
Q: What is the maximum load capacity?
A: The load capacity depends on the support span. For a typical span of 1.5m, the tray can support up to 150 kg/m. For specific spans, please consult our technical team for detailed load tables. -
Q: Does the anti-static property degrade over time?
A: No, the anti-static property is inherent to the material composition (conductive fibers) and does not wear off. It remains effective for the entire service life under normal conditions. -
Q: How is the tray shipped?
A: Standard lengths are 6m, but we can cut to shorter lengths for easier shipping. We pack in bundles with protective padding to prevent damage during transit. Shipment is from Tianjin or Qingdao ports. -
Q: Do you provide installation accessories?
A: Yes, we offer compatible brackets, splice plates, covers, and fasteners made from the same FRP material to ensure complete system compatibility. Contact us for a full accessory list. -
Q: What is the minimum order quantity?
A: For standard sizes, MOQ is 50 meters. For custom specifications, MOQ may vary. We welcome small trial orders and large bulk orders alike. -
Q: Is the tray fire-rated?
A: Our standard formulation meets flame spread index ≤25 (ASTM E84). For applications requiring higher fire resistance, we can supply a fire-retardant grade resin (optional). Please specify your requirements.
