Hengshui Ruibin New Materials LLC, a dedicated manufacturer established in 2019 with a factory spanning 1,000–3,000 square meters and a team of 101–200 employees, presents our Standard Compliant FRP Cable Tray designed for demanding industrial environments. This tray delivers a robust load capacity of 100 kg/m in a convenient 3-meter length, backed by a 1-year warranty and a comprehensive installation guide. Built from high-quality fiber-reinforced plastic, it offers exceptional corrosion resistance, electrical insulation, and long-term durability—making it a reliable choice for cable management systems worldwide.
The FRP cable tray is engineered to meet standard compliance requirements, ensuring seamless integration into various projects. Its lightweight yet strong construction reduces structural load on supports, while the non-conductive nature enhances safety in electrical installations. Below, we detail the key features and technical specifications.
Key Features & Benefits
- High Load Capacity: Rated at 100 kg/m, suitable for supporting multiple cables in heavy-duty applications.
- Corrosion & Chemical Resistance: FRP material withstands harsh environments, including chemical plants, wastewater treatment, and coastal areas.
- Electrical Insulation: Non-conductive and non-magnetic, reducing risk of electrical interference and ensuring worker safety.
- Lightweight Design: Approximately 70% lighter than steel trays, simplifying transportation and installation.
- Fire Retardant Properties: FRP inherently resists flame spread (optional enhanced fire-retardant grade available).
- UV Resistance: Surface treatment protects against sunlight degradation, suitable for outdoor use.
- Easy Installation: Pre-cut 3m sections with included guide; compatible with standard fittings and supports.
- Customizable Dimensions: Width, height, and colors can be tailored to project requirements.
Technical Specifications
| Parameter | Value |
| Material | Fiberglass Reinforced Polyester (FRP) |
| Standard Length | 3 meters |
| Load Capacity | 100 kg/m (uniformly distributed load) |
| Width Options | 100mm, 150mm, 200mm, 300mm, 400mm (customizable) |
| Height Options | 50mm, 75mm, 100mm (customizable) |
| Color | Yellow, Green, Gray, Blue (custom colors upon request) |
| Operating Temperature | -40°C to +80°C |
| Fire Rating | Class 1 (optional Class 0 available) |
| Certification | ISO9001, ISO9000 |
| Warranty | 1 year |
Our FRP cable trays are manufactured using advanced pultrusion and molding processes, ensuring consistent quality and dimensional accuracy. The smooth surface reduces cable abrasion, and the integral flanges provide excellent rigidity. Each tray is thoroughly tested for load performance before shipment.
Application Scenarios
- Power generation and distribution systems
- Telecommunication and data centers
- Chemical and petrochemical plants
- Water and wastewater treatment facilities
- Mining and offshore platforms
- Commercial buildings and tunnels
With an annual export value of US$2.5 million to US$5 million, Hengshui Ruibin New Materials LLC has established a global presence, shipping to markets across North America, South America, Europe, Asia, Africa, and Oceania. Our ISO9001 and ISO9000 certified production management ensures every product meets international quality standards. We ship from the ports of Tianjin and Qingdao, providing reliable logistics to customers worldwide.
Choose our Standard Compliant FRP Cable Tray for a cost-effective, long-lasting cable management solution. The included installation guide simplifies setup, and our dedicated after-sales team is ready to support you. Contact us today to discuss your specific requirements or request a quotation.
Frequently Asked Questions
-
Q: What is the maximum load capacity of this FRP cable tray?
A: The tray is rated for 100 kg/m uniformly distributed load. For higher loads, please contact us for custom designs. -
Q: Can the tray be used outdoors?
A: Yes, the FRP material is UV-resistant and weatherproof, making it suitable for outdoor installations. Optional enhanced UV protection is available. -
Q: Is the tray fire-resistant?
A: Standard FRP offers good fire retardancy. For stricter requirements, we can provide Class 0 fire-rated trays upon request. -
Q: What colors are available?
A: Standard colors include yellow, green, gray, and blue. Custom colors can be matched to your project specifications. -
Q: Does the tray come with installation accessories?
A: The tray itself is supplied with a detailed installation guide. Connectors, brackets, and other accessories are available separately. -
Q: How long is the warranty?
A: We offer a 1-year warranty against manufacturing defects. Extended warranty options are negotiable. -
Q: Can the tray be cut to a shorter length?
A: Yes, the 3-meter sections can be cut on-site using standard tools. We also offer custom lengths in bulk orders. -
Q: What certifications does your company have?
A: Our factory is ISO9001 and ISO9000 certified, ensuring consistent quality control. We can provide certificates upon request.
