Welcome to Hengshui Ruibin New Materials LLC, a professional manufacturer established in 2019 with a factory spanning 1,000–3,000 square meters and a dedicated team of 101–200 employees. We are proud to present our Fiberglass Grating — a versatile, corrosion-resistant solution designed for demanding industrial environments. With a 1-year warranty, free sample offer, and mill test report included for every order, we ensure your confidence from the very first inquiry. Our grating complies with international standards, making it an ideal choice for platforms, walkways, and trench covers across multiple industries.
Our fiberglass grating is engineered to deliver exceptional strength-to-weight ratio, long service life, and minimal maintenance. Whether you need a lightweight alternative to steel or a non-conductive flooring solution, this product meets your requirements. Below we detail the key features and technical specifications that set our grating apart.
Key Features & Benefits
- Corrosion Resistance – Impervious to chemicals, moisture, and UV radiation, ideal for harsh environments like chemical plants, wastewater treatment, and marine applications.
- High Strength-to-Weight Ratio – Up to 75% lighter than steel grating, reducing installation costs and structural load requirements.
- Non-Conductive & Non-Magnetic – Enhances safety in electrical environments and MRI rooms.
- Anti-Slip Surface – Gritted top provides excellent traction even when wet or oily.
- Low Maintenance – No need for painting, coating, or rust-proofing; simple wash-down keeps it clean.
- Customizable Dimensions – Available in various panel sizes, thicknesses, and mesh configurations to suit your project.
- Easy Installation – Can be cut and drilled on-site with standard tools; compatible with clips or bearing bars.
- Fire Retardant Options – Flame spread index as per ASTM E84 (available upon request).
Technical Specifications
| Property | Value |
| Material | Fiberglass reinforced polyester / vinyl ester resin |
| Resin Type | Isophthalic polyester, vinyl ester (optional for chemical resistance) |
| Glass Content | 30% – 45% by weight |
| Panel Size | Standard: 1220mm x 3660mm (custom sizes available) |
| Thickness | 25mm, 38mm, 50mm (other thicknesses upon request) |
| Mesh Opening | 30mm x 30mm, 38mm x 38mm, 50mm x 50mm |
| Load Capacity | Up to 500 kg/m² (depending on configuration) |
| Operating Temperature | -40°C to +120°C (higher with special resin) |
| Surface Finish | Gritted top (silica sand or aluminum oxide) |
| Warranty | 1 year |
Our fiberglass grating is manufactured under strict quality control processes and complies with international standards such as ASTM E84, ASTM D635, and others. Each batch comes with a mill test report detailing resin content, mechanical properties, and dimensional accuracy. This transparency ensures you receive exactly what you ordered.
Why Choose Hengshui Ruibin New Materials LLC?
Since our establishment in 2019, we have grown to become a trusted supplier of composite products with an annual export value of US$2.5 Million – US$5 Million. Our factory is ISO9001 and ISO9000 certified, reflecting our commitment to quality management. With 101–200 skilled employees and a 1,000–3,000 sqm facility, we ensure timely production and consistent product quality.
We serve customers across North America, South America, Europe, Asia, Africa, and Oceania, shipping from the ports of Tianjin and Qingdao. Our main markets include diverse industries such as oil & gas, chemical processing, food & beverage, and marine. We offer free samples for evaluation, and our technical team supports you with custom designs, load calculations, and installation guidance. When you choose our fiberglass grating, you choose reliability, compliance, and long-term performance.
Don't settle for less. Request your free sample today and experience the difference in quality. Our mill test report and 1-year warranty give you peace of mind. Contact us for a quote or technical consultation — we are ready to serve you.
Frequently Asked Questions
-
Q: What is the typical lead time for fiberglass grating orders?
A: For standard sizes and colors, lead time is 15–20 working days. Custom orders may require 25–30 working days. We prioritize urgent requests and can expedite upon negotiation. -
Q: Can I get a free sample before placing a bulk order?
A: Yes, we offer free samples (within reason) to help you evaluate the quality, surface finish, and load performance. You only pay for shipping if applicable. -
Q: What does the mill test report include?
A: The mill test report provides data on resin content, glass content, flexural strength, tensile strength, dimensional tolerances, and compliance with standards. It is issued per batch and can be customized upon request. -
Q: Is your fiberglass grating suitable for outdoor use?
A: Absolutely. Our grating uses UV-stabilized resin and is resistant to degradation from sunlight, rain, and temperature extremes. It is commonly used in outdoor platforms, catwalks, and drainage covers. -
Q: Do you offer color options?
A: Yes, standard colors are yellow, green, and gray. Custom colors are available for volume orders (minimum quantity may apply). -
Q: How do I install the grating?
A: Installation is straightforward. You can cut panels to size with a standard saw, drill holes for fasteners, and secure them using clips, clamps, or bearing bars. We provide installation guides upon request. -
Q: What is the load capacity of your grating?
A: Load capacity depends on panel thickness, mesh size, and resin type. For a 38mm thick panel with 38x38mm mesh, the safe working load is approximately 400 kg/m². We can provide a detailed load chart for your specific configuration. -
Q: Do you have certifications like ISO or CE?
A: Our company is ISO9001 and ISO9000 certified. We can also provide compliance documentation for other standards as required by your project (e.g., ASTM, EN). Please specify your requirements.
For more information, technical support, or to request a free sample, please contact our sales team. We look forward to building a long-term partnership with you.
