Help CenterNeoprene Bearing Pad 50mm x 50mm x 5mm, 60 Shore A, Low Temperature Flexibility -40°C, Standard Compliant
Product Spotlights
Related Products
-
FRP Drainage Channel With Technical Support and Custom Length Service Standard CompliantNegotiableMOQ: 300 Meters -
Lightweight FRP Drainage Channel 100mm Width Load Class C250 Corrosion ResistantNegotiableMOQ: 300 Meters
-
FRP Drainage Channel Load Class D400 150mm Width Slip Resistant Grate for RoadwaysNegotiableMOQ: 300 Meters
-
FRP Drainage Channel for Highway and Bridge Drainage Systems Load Class F900NegotiableMOQ: 300 Meters
-
FRP Drainage Channel With 5-Year Warranty and Mill Test Report for Quality AssuranceNegotiableMOQ: 300 Meters
Hengshui Ruibin New Materials LLC, established in 2019, has rapidly grown into a reliable manufacturer of high-performance elastomeric products. With a factory spanning 1,000–3,000 square meters and a dedicated team of 101–200 employees, we specialize in producing neoprene bearing pads that meet rigorous international standards. Our 50mm x 50mm x 5mm neoprene bearing pad, featuring a hardness of 60 Shore A and outstanding low-temperature flexibility down to -40°C, is engineered to deliver consistent performance under extreme conditions. Whether you need vibration isolation in bridges, building foundations, or industrial machinery, this pad offers a durable, cost-effective solution backed by our ISO 9001 quality management system.
This product is designed to provide reliable load distribution and accommodate structural movements while resisting environmental degradation. The neoprene compound ensures excellent resistance to ozone, UV, and aging, making it suitable for both indoor and outdoor applications. Below we detail the key features, technical specifications, and benefits that set this bearing pad apart from conventional alternatives.
Product Features & Benefits
- Low Temperature Flexibility (-40°C): Maintains elasticity and load-bearing capacity even in arctic environments, preventing brittle failure.
- 60 Shore A Hardness: Optimal balance between stiffness and damping, ideal for moderate load applications without excessive deflection.
- Neoprene (Polychloroprene) Construction: Superior resistance to weathering, ozone, oils, and chemicals compared to natural rubber or SBR.
- Precision Dimensions: 50mm x 50mm x 5mm (±0.5mm tolerance) ensures consistent fit and easy installation.
- ISO 9001 Compliant Manufacturing: Rigorous quality control at every stage, from raw material selection to final inspection.
- Customizable Options: Available in different sizes, hardness levels (40–80 Shore A), and shapes (square, rectangular, circular) upon request.
- Low Compression Set: Maintains thickness under sustained load, prolonging service life.
- Excellent Adhesion to Steel/Concrete: Can be bonded to plates or used directly between substrates.
Technical Specifications
| Property | Value | Test Method |
| Material | Neoprene (Polychloroprene) | ASTM D2000 |
| Hardness | 60 ± 5 Shore A | ASTM D2240 |
| Tensile Strength | ≥ 10 MPa | ASTM D412 |
| Elongation at Break | ≥ 300% | ASTM D412 |
| Low Temperature Flexibility | -40°C (no cracking) | ASTM D2137 |
| Compression Set (22h @ 70°C) | ≤ 25% | ASTM D395 |
| Operating Temperature Range | -40°C to +100°C | Continuous |
| Dimensions | 50mm x 50mm x 5mm (tolerance ±0.5mm) | Calipers |
Why Choose Hengshui Ruibin New Materials LLC?
As a dedicated manufacturer with an annual export value of US$2.5 Million – US$5 Million, we serve clients across North America, South America, Europe, Asia, Africa, and Oceania. Our 101–200 skilled employees operate a modern facility of 1,000–3,000 square meters, ensuring each neoprene bearing pad is produced with precision and consistency. We hold ISO 9001 & ISO 9000 certifications, reflecting our commitment to quality management. Our products are shipped from the Port of Tianjin or Port of Qingdao, with flexible packaging options to meet your logistics needs.
We understand that structural bearing pads must perform reliably over decades. That’s why we use only premium neoprene compounds and conduct rigorous testing on every batch. Our low-temperature formula ensures that even at -40°C, the pad remains flexible and crack-free, preventing catastrophic failures in cold climates. Whether you are a contractor, engineer, or distributor, our team is ready to support you with technical advice, custom sizes, and competitive pricing.
Ready to enhance your project’s durability? Contact us today for a quote or sample request. With our global shipping network and responsive customer service, we make it easy to get the right bearing pad for your application. Trust Hengshui Ruibin – your partner in quality elastomeric solutions.
Frequently Asked Questions (FAQ)
Q1: What is the maximum load capacity of this 50x50x5mm neoprene pad?
A: The load capacity depends on the application and support conditions. For a typical bridge bearing with adequate support, the pad can handle static loads up to approximately 1.5–2 MPa (based on 60 Shore A hardness). We recommend consulting our engineering team for specific load requirements.
Q2: Can this pad be used in direct contact with concrete or steel?
A: Yes, it can be placed directly between concrete or steel surfaces. For better adhesion, a thin layer of epoxy or neoprene-based adhesive may be applied. The pad’s surface is slightly textured to improve friction.
Q3: Does the pad require any special maintenance?
A: Neoprene is inherently resistant to weathering and aging. Periodic visual inspection for cracks or excessive compression is recommended. Under normal conditions, no maintenance is needed for the life of the structure.
Q4: What is the shelf life of this product?
A: When stored in a cool, dry place away from direct sunlight, the pad can be kept for at least 5 years without significant degradation. We recommend using within 2 years of purchase for optimal performance.
Q5: Can you provide custom sizes or hardness?
A: Absolutely. We offer customization in dimensions (thickness, width, length) and hardness (40–80 Shore A). Minimum order quantities may apply. Please contact us with your requirements.
Q6: Are the pads tested for low-temperature performance before shipment?
A: Yes, we perform low-temperature flexibility tests per ASTM D2137 on random samples from each production batch to ensure the -40°C rating is consistently met. Test reports are available upon request.
Q7: What packaging options are available?
A: Standard packaging is poly bags inside cartons, with palletizing for larger orders. We can also customize packaging (e.g., shrink wrap, wooden crates, or bulk bags) to suit your handling and shipping preferences.
Q8: Do you offer samples for evaluation?
A: Yes, we provide free samples for qualified buyers. You only pay for shipping. Contact our sales team to arrange sample delivery.
