Hengshui Ruibin New Materials LLC, a professional manufacturer established in 2019 with ISO9001 certification, proudly presents our 38mm Vinyl Ester Fiberglass Grating—specifically engineered for chemical plant flooring demanding superior corrosion resistance, 50% open area for ventilation and drainage, and built-in fire retardancy. As a trusted supplier with an annual export value of US$2.5–5 million, we deliver high-quality FRP grating solutions to markets worldwide, including North America, Europe, and Southeast Asia.
This grating is manufactured using vinyl ester resin, which offers excellent resistance to a wide range of chemicals, including acids, alkalis, and solvents. The 38mm thickness ensures robust structural integrity, while the 50% open area design maximizes light transmission, air circulation, and liquid drainage—critical for safety in chemical processing environments. Plus, our fire-retardant formulation meets Class 1 flame spread rating (ASTM E84), making it a safe choice for industrial flooring.
Key Features & Technical Specifications
| Parameter | Value |
|---|---|
| Resin Type | Vinyl Ester (e.g., Dow Derakane 470) |
| Panel Thickness | 38 mm (1.5 inches) |
| Open Area | 50% |
| Fire Rating | Class 1 (ASTM E84) |
| Load Capacity | Up to 500 kg/m² (with proper support) |
| Surface | Concave-convex / Grit-top (anti-slip) |
| Standard Panel Size | 3660mm × 1220mm (customizable) |
| Color | Gray, Green, Yellow, or custom |
Product Advantages & Customer Benefits
- Superior Chemical Resistance: Vinyl ester resin withstands aggressive chemicals, extending service life in corrosive environments.
- Enhanced Safety: Fire retardant additives reduce flame spread and smoke generation, meeting strict industrial safety codes.
- Efficient Drainage & Ventilation: 50% open area allows liquids, debris, and air to pass through, keeping floors clean and preventing slip hazards.
- Lightweight Yet Strong: At only one-third the weight of steel, it reduces structural load and is easy to handle, cut, and install on-site.
- Non-Conductive & Non-Magnetic: Ideal for electrical environments and sensitive areas where sparks must be avoided.
- Low Maintenance: Resistant to rust, rot, and UV degradation, requiring minimal upkeep over decades of service.
- Customizable Options: Available in various colors, thicknesses, and cut-to-size dimensions to fit your exact project needs.
Our manufacturing process follows strict ISO9001 quality control, ensuring consistent panel thickness, uniform resin distribution, and reliable mechanical properties. Each panel is tested for load-bearing capacity and fire resistance before shipment.
Trusted by Global Industries
Since 2019, Hengshui Ruibin New Materials LLC has grown into a leading FRP grating manufacturer with a 1,000–3,000 m² factory, a team of 101–200 skilled employees, and annual export sales exceeding US$2.5 million. Our products are shipped through major ports like Tianjin and Qingdao to clients in North America, South America, Eastern Europe, Africa, Oceania, the Middle East, and Asia.
We back our grating with a comprehensive quality guarantee: rigorous raw material inspection, in-process monitoring, and final testing. Our ISO9001:2015 certified management system ensures every panel meets your specifications. Whether you need a standard 38mm panel or a custom configuration, we deliver on time and at competitive factory prices.
Ready to upgrade your chemical plant flooring? Contact our sales team today for a quote, technical datasheet, or free sample. Let us help you create a safer, more durable workspace with our premium fiberglass grating.
Frequently Asked Questions (FAQ)
Q1: What is the difference between vinyl ester and polyester resin grating?
A: Vinyl ester resin offers superior chemical resistance, especially against strong acids, alkalis, and organic solvents. It also has better thermal stability and fire retardancy. Polyester is more economical but less durable in harsh chemical environments.
Q2: Can this grating be used outdoors?
A: Yes. Our vinyl ester grating includes UV stabilizers to resist degradation from sunlight. However, for extended outdoor exposure, we recommend adding a UV-resistant gel coat or top layer.
Q3: What is the load capacity of a 38mm grating?
A: The load capacity depends on support spacing. With a typical 600mm span, the concentrated load capacity is approximately 500 kg. For specific load requirements, we provide engineering calculations.
Q4: Is the grating fire retardant? What standard does it meet?
A: Yes, this product is formulated with fire-retardant additives. It achieves a Class 1 flame spread rating per ASTM E84, with a flame spread index below 25 and smoke developed index below 450.
Q5: How do I cut the grating to size on-site?
A: FRP grating can be cut using standard tools like a circular saw with a carbide-tipped blade or an abrasive cut-off saw. Always wear appropriate PPE (dust mask, goggles) during cutting.
Q6: Can you provide custom colors or sizes?
A: Absolutely. We can produce panels in any color, thickness (e.g., 25mm, 50mm), and cut-to-size shapes per your drawings. Minimum order quantities apply for custom colors.
Q7: What is the typical lead time?
A: For standard panels (38mm, 50% open area), lead time is 7–10 working days. Custom orders may require 15–20 working days, depending on complexity.
Q8: Is the grating non-conductive? Can it be used near electrical equipment?
A: Yes, fiberglass is an electrical insulator. Our grating is non-conductive and non-magnetic, making it ideal for use in electrical substations, control rooms, and other areas where sparking must be avoided.
