Help CenterVacuum Evaporation Crystallizer With Inlet Temperature Control 0-100°C 304 Material
Product Spotlights
Related Products
-
1 Year Warranty Vacuum Evaporation Crystallizer With Free Technical Training SupportUS$ 215000 - 879000MOQ: 1 Combo -
Stainless Steel Vacuum Evaporation Crystallizer 10kW 400L/Day Salt Recovery SystemUS$ 215000 - 879000MOQ: 1 Combo
-
304 Stainless Steel Vacuum Evaporation Crystallizer PLC Control 220V 50Hz 100L CapacityUS$ 215000 - 879000MOQ: 1 Combo
-
Pharmaceutical Grade Vacuum Evaporation Crystallizer for API Crystal Recovery ProcessUS$ 215000 - 879000MOQ: 1 Combo
-
Automatic Vacuum Evaporation Crystallizer With PLC Touch Screen 380V 3 Phase 200L/hUS$ 215000 - 879000MOQ: 1 Combo
As a leading manufacturer in environmental technology, Qingdao Conqinphi Environmental Technology Group Co., Ltd. proudly presents our Vacuum Evaporation Crystallizer with Inlet Temperature Control 0-100°C, crafted from high-quality 304 stainless steel. Since our establishment in 2015, we have been dedicated to providing advanced solutions for wastewater treatment and chemical processing, with a factory spanning 10,000-30,000 square meters and an annual export value of US$10 million to US$50 million. This crystallizer combines precise temperature control with vacuum evaporation technology to efficiently separate and recover valuable solids from liquid streams, offering a reliable and energy-saving solution for industries worldwide.
Our vacuum evaporation crystallizer is designed to operate under reduced pressure, lowering the boiling point of the liquid and enabling gentle evaporation at lower temperatures. This not only preserves heat-sensitive materials but also reduces energy consumption. The inlet temperature control system allows precise adjustment from 0°C to 100°C, ensuring optimal conditions for various feed solutions. Constructed from 304 stainless steel, the equipment offers excellent corrosion resistance, durability, and hygiene, making it suitable for food, pharmaceutical, and chemical industries.
Key Features & Technical Specifications
- Precise Inlet Temperature Control: The integrated PID controller maintains the inlet temperature within ±1°C of the set point, ensuring consistent evaporation and crystallization results.
- 304 Stainless Steel Construction: All wetted parts are made of 304 SS, providing excellent resistance to corrosion, oxidation, and chemical attack, extending service life.
- Vacuum Operation: The system operates under vacuum (down to -0.095 MPa), significantly reducing the boiling point of the liquid, which minimizes thermal degradation and saves energy.
- Efficient Crystallization: The combination of vacuum and controlled temperature promotes rapid formation of crystals, which can be easily separated and collected.
- Customizable Capacity: Available in a range of processing capacities from 50 L/h to 5000 L/h, tailored to meet specific production requirements.
- User-Friendly Interface: Touchscreen control panel with real-time monitoring of temperature, pressure, and flow rate, allowing easy operation and data logging.
- Energy Efficient: The vacuum system and heat recovery design reduce overall energy consumption by up to 30% compared to atmospheric evaporation.
- Compact Footprint: Space-saving design with integrated components, suitable for both indoor and outdoor installations.
| Parameter | Specification |
|---|---|
| Material | 304 Stainless Steel |
| Inlet Temperature Control Range | 0°C – 100°C |
| Vacuum Level | -0.095 MPa (max) |
| Processing Capacity | 50 L/h – 5000 L/h (customizable) |
| Temperature Control Accuracy | ±1°C |
| Power Supply | 380V / 50Hz (3-phase) or customizable |
| Dimensions (L×W×H) | Varies by capacity; available upon request |
| Certifications | ISO9001, ISO14000, OHSAS18001, and others |
The vacuum evaporation crystallizer is widely used in industries such as wastewater treatment (zero liquid discharge), chemical processing (salt recovery, concentration), pharmaceutical (API crystallization), and food & beverage (juice concentration, sugar recovery). By precisely controlling the inlet temperature, our system can handle a variety of feedstocks, including those with high viscosity, fouling tendencies, or temperature sensitivity. The 304 stainless steel construction ensures compliance with hygiene standards and offers long-term reliability even in aggressive environments.
Why Choose Qingdao Conqinphi?
With over 9 years of manufacturing experience, our company employs 201-300 skilled professionals and operates a modern factory of 10,000-30,000 m². We export to global markets including North America, Europe, Southeast Asia, Africa, and Oceania, with annual export value exceeding US$10 million. Our products are certified under ISO9001, ISO14000, OHSAS18001, HACCP, and SA8000, reflecting our commitment to quality, environmental responsibility, and social compliance. We offer comprehensive after-sales support, including installation guidance, training, and spare parts supply. Our dedicated engineering team can customize the crystallizer to match your specific process requirements, ensuring optimal performance and rapid return on investment.
Join hundreds of satisfied customers worldwide who rely on Conqinphi for their evaporation and crystallization needs. Contact us today to discuss your project and request a tailored solution. Our team is ready to provide technical datasheets, quotations, and samples to demonstrate the superior performance of our vacuum evaporation crystallizer.
Frequently Asked Questions (FAQ)
-
Q: What is the maximum vacuum pressure achievable?
A: The system can reach a vacuum of -0.095 MPa, depending on the pump configuration and process conditions. -
Q: Can the temperature control handle fluctuating feed temperatures?
A: Yes, the PID controller continuously adjusts the heating input to maintain the set inlet temperature within ±1°C, even with varying feed conditions. -
Q: Is the 304 stainless steel suitable for corrosive solutions like chlorides?
A: For highly corrosive environments, we recommend upgrading to 316L stainless steel or other specialized alloys. Please consult our engineers for material selection. -
Q: What is the typical maintenance schedule?
A: Regular inspection of seals, vacuum pump oil, and control sensors is recommended every 3-6 months. Full cleaning and component check every 12 months ensure long-term reliability. -
Q: Can the crystallizer be used for zero liquid discharge (ZLD) systems?
A: Absolutely. This equipment is ideal for ZLD applications, as it efficiently concentrates and crystallizes dissolved solids, recovering clean water. -
Q: What is the delivery time for a standard unit?
A: Typical delivery is 30-45 days after order confirmation, depending on customization requirements. Expedited options are available upon request. -
Q: Does the equipment come with a warranty?
A: Yes, we offer a standard 12-month warranty covering manufacturing defects. Extended warranties are negotiable. -
Q: How do you ensure the product meets international quality standards?
A: Our factory holds ISO9001 and ISO14000 certifications, and we perform rigorous testing on each unit before shipment, including pressure tests, temperature calibration, and performance verification.
