Qingdao Conqinphi Environmental Technology Group Co., Ltd., established in 2015 with a factory area of 10,000-30,000 square meters and over 200 skilled employees, is proud to present our Sodium Sulfite Crystallization Evaporator Fully Automatic CIP Cleaning System. This advanced equipment integrates efficient crystallization technology with a fully automated Clean-in-Place (CIP) system, ensuring high purity sodium sulfite production while minimizing downtime and manual labor. Designed for the chemical, pharmaceutical, and food industries, our evaporator guarantees consistent product quality and operational reliability.
The system utilizes forced circulation evaporation to concentrate sodium sulfite solution, followed by controlled crystallization to obtain uniform crystals. The integrated CIP system automatically cleans all internal surfaces without disassembly, reducing contamination risks and extending equipment life. With PLC-based automation, operators can monitor and adjust parameters such as temperature, pressure, and flow rate in real time, ensuring optimal performance and energy efficiency.
Key Features & Technical Specifications
- High-Efficiency Crystallization: Forced circulation design with external heat exchanger ensures rapid heat transfer and uniform crystal growth.
- Fully Automatic CIP System: Pre-programmed cleaning cycles using spray balls and circulation pumps, capable of cleaning all product contact surfaces.
- PLC Touch Screen Control: Intuitive HMI with real-time data logging, alarm management, and remote monitoring capability.
- Robust Construction: Made from high-grade stainless steel (304 or 316L) with polished internal surfaces to prevent fouling and corrosion.
- Energy Saving: Multiple-effect evaporation design reduces steam consumption by up to 30% compared to single-effect systems.
- Customizable Capacity: Standard evaporation rates from 1,000 L/h to 50,000 L/h, with tailored solutions for specific production volumes.
| Parameter | Specification |
|---|---|
| Evaporation Capacity | 1,000 – 50,000 L/h |
| Operating Temperature | 60°C – 120°C |
| Operating Pressure | Atmospheric – 0.5 MPa |
| Material of Construction | SS304 / SS316L |
| CIP Cleaning Cycle Time | 30 – 60 minutes (adjustable) |
| Power Supply | 380V/50Hz (customizable) |
Advantages & Customer Benefits
- Reduced Labor Costs: Fully automatic operation and CIP cleaning eliminate the need for manual cleaning and constant supervision.
- Consistent Product Quality: Precise control of crystallization parameters ensures uniform crystal size and high purity of sodium sulfite.
- Minimal Downtime: CIP system cleans the evaporator in less than an hour, allowing rapid changeover between batches.
- Enhanced Safety: Closed system design with safety interlocks and pressure relief valves protects operators and environment.
- Eco-Friendly: Waste heat recovery and condensate reuse options reduce water and energy consumption.
Trust & Reliability
As a manufacturer with over 10 years of experience and annual export value exceeding US$10 million, Qingdao Conqinphi Environmental Technology Group Co., Ltd. has delivered crystallization systems to clients across North America, Europe, Southeast Asia, and Africa. Our factory, spanning 10,000-30,000 m², is equipped with advanced CNC machining and welding facilities, and we hold multiple certifications including ISO9001, HACCP, OHSAS18001, and others. Each system undergoes rigorous factory acceptance testing (FAT) before shipment. We offer comprehensive after-sales support, including on-site commissioning, training, and spare parts supply. Contact us today to discuss your sodium sulfite crystallization needs and experience reliable, high-performance equipment.
Frequently Asked Questions (FAQ)
-
Q: What is the typical evaporation capacity for sodium sulfite crystallization?
A: Our standard systems range from 1,000 to 50,000 L/h, but we can customize capacity based on your production requirements. Please provide your target throughput for a tailored solution. -
Q: Can the CIP system handle different cleaning agents?
A: Yes, the CIP system is designed to work with various cleaning solutions such as caustic soda, nitric acid, and water. The cleaning cycle parameters (temperature, time, concentration) are fully programmable via the PLC. -
Q: What materials are used for the evaporator and piping?
A: Standard construction is stainless steel 304 for non-corrosive applications, and SS316L for corrosive environments. Food-grade or pharmaceutical-grade finishes are available upon request. -
Q: How long does the CIP cleaning process take?
A: A typical cleaning cycle lasts 30 to 60 minutes, depending on the number of stages and degree of fouling. The system can be set to clean automatically between batches or at scheduled intervals. -
Q: Is remote monitoring or SCADA integration possible?
A: Yes, our PLC supports Modbus, Profibus, or Ethernet/IP communication protocols, allowing integration with your plant SCADA or MES system. Remote monitoring via a web interface is also optional. -
Q: What is the expected lifespan of the equipment?
A: With proper maintenance and operation, the evaporator system can last 15-20 years or more. We provide detailed maintenance manuals and offer extended warranty options. -
Q: Do you provide installation and commissioning services?
A: Yes, we offer on-site installation supervision and commissioning by our experienced engineers. Training for your operators is also included in the package. -
Q: What certifications does your equipment comply with?
A: Our products are manufactured under ISO9001 quality management system and can be certified to meet HACCP, OHSAS18001, and other standards as required. CE certification is available upon request for EU markets.
