Welcome to Anping County Boli Hardware Wiremesh Products Factory, a trusted manufacturer with over 25 years of expertise since 1998. Our 304 Stainless Steel Brazed Plate Heat Exchanger is engineered to deliver outstanding performance in demanding HVAC applications. With a design pressure of 30 Bar and a maximum operating temperature of 225°C, this compact heat exchanger combines high durability with space-saving efficiency, making it the ideal choice for heating, ventilation, and air conditioning systems requiring reliable thermal transfer under extreme conditions.
Built from premium-grade 304 stainless steel, our brazed plate heat exchanger ensures excellent corrosion resistance and long service life. The vacuum-brazing process creates a strong, leak-proof structure that withstands high pressures and temperatures while maintaining superior heat transfer efficiency. The compact design minimizes footprint, allowing easy integration into existing systems or new installations where space is limited.
Key Features & Technical Specifications
- Material: 304 stainless steel plates and connections; copper brazing for high-strength seals.
- Design Pressure: Up to 30 Bar (435 psi) – suitable for high-pressure HVAC loops.
- Max Temperature: 225°C (437°F) – handles hot water, steam, and thermal oils.
- Compact Design: Plate thickness optimized for maximum heat transfer in minimal volume.
- Application: Ideal for HVAC systems – chillers, boilers, heat pumps, district heating, and cooling towers.
- Connection Options: Available in NPT, BSP, or flanged connections; sizes customizable from 1/2" to 2".
- Flow Configuration: Counter-current flow for high log mean temperature difference (LMTD).
- Plate Count: Customizable based on required heat load (from 10 to 200 plates).
- Certification: Manufactured under strict quality control; CE and ISO certifications available upon request.
| Parameter | Value |
|---|---|
| Plate Material | 304 Stainless Steel (AISI 304) |
| Brazing Material | Copper (99.9% purity) |
| Max Design Pressure | 30 Bar |
| Max Operating Temperature | 225°C |
| Min Operating Temperature | -196°C (cryogenic applications possible) |
| Connection Size | 1/2" to 2" (customizable) |
| Plate Thickness | 0.4 mm – 0.6 mm |
| Heat Transfer Coefficient | Up to 6000 W/m²·K (depending on media) |
Advantages for Your HVAC System
- High Efficiency: Turbulent flow induced by plate corrugation maximizes heat transfer, reducing energy consumption.
- Compact Footprint: Up to 80% smaller than shell-and-tube exchangers with similar capacity, saving valuable floor space.
- Durability: 304 stainless steel resists corrosion from water, glycol, and mild chemicals; copper brazing ensures leak-free joints.
- Easy Maintenance: No gaskets or moving parts; only periodic cleaning required (backflushing or chemical cleaning).
- Versatility: Suitable for both liquid-to-liquid and liquid-to-vapor applications (e.g., steam condensers, water heaters).
- Customizable: Plate count, connection type, and overall dimensions tailored to your specific heat load and space constraints.
With over 25 years of manufacturing experience, Anping County Boli Hardware Wiremesh Products Factory has been a reliable partner for global HVAC projects. Our annual export value exceeds US$5 million, serving markets across North America, South America, Europe, Asia, Africa, and Oceania. We ship from major Chinese ports including Tianjin, Qingdao, Shanghai, and Foshan, ensuring timely delivery. Our dedicated quality control team inspects every unit before shipment, guaranteeing compliance with strict international standards.
Every heat exchanger undergoes rigorous pressure testing (1.5x design pressure) and helium leak detection to ensure zero leakage. We also offer customized solutions: from plate geometry to connection orientation, we work closely with your engineering team to meet exact requirements. Whether you need a standard unit for a chiller or a specialized design for a high-temperature heat pump, our product delivers consistent performance.
Choose our 304 Stainless Steel Brazed Plate Heat Exchanger for your HVAC needs – a combination of high pressure/temperature capability, compact design, and long-term reliability. Contact us today for a quotation or technical consultation. We are committed to providing cost-effective solutions with fast lead times and excellent after-sales support.
Frequently Asked Questions (FAQ)
1. What is the maximum working pressure for this heat exchanger?
The design pressure is 30 Bar (435 psi). However, we can offer units with up to 45 Bar upon request for special applications.
2. Can this heat exchanger be used with steam?
Yes, the 304 stainless steel construction and copper brazing can handle steam up to 225°C. For higher temperature steam, we recommend nickel brazing options.
3. What media are compatible with the 304 stainless steel plates?
It is compatible with water, glycol mixtures, steam, thermal oils, and many mild chemicals. Avoid strong chlorides or acids; for aggressive media, we offer 316L or titanium alternatives.
4. What are the standard connection sizes available?
We offer connections from 1/2" to 2" in NPT, BSP, or flanged. Custom sizes are available on request.
5. How do I determine the correct plate count for my application?
Provide us with flow rates, inlet/outlet temperatures, and allowable pressure drop – our engineering team will calculate the optimal plate count to meet your heat duty.
6. Is the heat exchanger easy to clean?
Yes, the brazed plate design does not allow mechanical disassembly, but it can be cleaned in place (CIP) using chemical flushing or backflushing with appropriate solvents.
7. What is the typical lifespan of this heat exchanger?
With proper maintenance (e.g., water treatment, regular cleaning), it can last 15–20 years or more in HVAC applications, depending on operating conditions.
8. Do you provide custom mounting brackets or insulation?
Yes, we offer custom mounting frames, insulation jackets, and additional accessories. Please specify your requirements during ordering.
