As a professional manufacturer with over 25 years of experience (since 1998), Anping County Boli Hardware Wiremesh Products Factory is proud to present our Brazed Plate Heat Exchanger, a high-efficiency heat transfer solution designed for demanding industrial and commercial applications. Each unit is backed by a 2-year warranty and comes with a Factory Test Certificate, ensuring reliable performance and peace of mind. Our heat exchangers are exported globally to markets including North America, South America, Europe, and Asia, with annual export value exceeding US$5 million.
Our brazed plate heat exchangers are constructed from premium stainless steel 316L plates and copper brazing, offering excellent corrosion resistance and thermal conductivity. The compact design maximizes heat transfer area while minimizing footprint, making them ideal for space-constrained installations. Whether you need heating, cooling, or heat recovery, our product delivers consistent and efficient operation.
Product Features & Specifications
- High Thermal Efficiency – Up to 95% heat transfer efficiency due to turbulent flow design.
- Compact and Lightweight – Up to 80% smaller than shell-and-tube exchangers for same capacity.
- Durable Construction – Stainless steel 316L plates and copper brazing withstand high pressure and temperature.
- Easy Maintenance – No gaskets or seals to replace; factory-sealed design reduces leakage risk.
- Customizable Options – Number of plates, connection sizes, and port configurations available upon request.
- Wide Application Range – Suitable for HVAC, refrigeration, heat pumps, solar thermal, industrial process heating, and more.
- Factory Tested – Each unit undergoes pressure and leak testing before shipment, with a test certificate provided.
- 2-Year Warranty – Covers manufacturing defects, ensuring long-term reliability.
| Parameter | Value |
| Max Working Pressure | 30 bar |
| Max Working Temperature | 200°C |
| Plate Material | Stainless Steel 316L |
| Brazing Material | Copper (99.9% purity) |
| Connection Size | 1/2" to 2" (customizable) |
| Number of Plates | 10 – 200 (customizable) |
| Warranty | 2 Years |
| Test Certificate | Factory Test Certificate included |
Customer Benefits
- Reduced Energy Costs – High thermal efficiency lowers fuel or electricity consumption.
- Space Savings – Compact design fits into tight mechanical rooms, freeing up valuable floor area.
- Reliable Operation – Factory testing and robust construction minimize downtime.
- Long Service Life – Corrosion-resistant materials and copper brazing ensure durability under harsh conditions.
- Global Compatibility – Designed to meet international standards; available with various port configurations.
- Risk-Free Purchase – 2-year warranty provides peace of mind and after-sales support.
Why Choose Us?
Anping County Boli Hardware Wiremesh Products Factory has been a trusted manufacturer since 1998, with an annual export value of US$5–10 million. Our main markets span North America, South America, Europe, Asia, Africa, and Oceania. We ship from major Chinese ports including Tianjin, Qingdao, Shanghai, and Foshan. Our factory is equipped with modern production lines and testing facilities to ensure every heat exchanger meets stringent quality standards. With a 2-year warranty and a factory test certificate for each unit, we stand behind our products. Contact us today for a quotation or customized solution — we are ready to support your project with professional engineering and reliable service.
Frequently Asked Questions (FAQ)
-
Q: What is the maximum pressure rating of your brazed plate heat exchanger?
A: Our standard models are rated for up to 30 bar (435 psi). Higher pressure ratings are available upon request. -
Q: Can I get a custom number of plates?
A: Yes, we offer customizable plate counts from 10 to 200 plates to meet your specific heat transfer requirements. -
Q: What materials are used in the construction?
A: The plates are made of stainless steel 316L and are brazed with 99.9% pure copper for excellent corrosion resistance and thermal conductivity. -
Q: Do you provide a test certificate?
A: Yes, every unit is factory-tested and includes a Factory Test Certificate confirming pressure and leak tests. -
Q: What is the warranty period?
A: We offer a 2-year warranty covering manufacturing defects under normal operating conditions. -
Q: Are these heat exchangers suitable for swimming pool heating?
A: Yes, they are suitable for pool heating, but we recommend checking compatibility with pool chemicals. Please contact us for specific recommendations. -
Q: What port sizes are available?
A: Standard connection sizes range from 1/2 inch to 2 inches, with other sizes available upon request. -
Q: How do I place an order?
A: You can contact us via email or phone with your specifications (flow rate, temperature, pressure, plate count). We will provide a quotation and lead time.
