Qingdao Conqinphi Environmental Technology Group Co., Ltd., established in 2015 with a factory spanning 10,000-30,000 square meters, is proud to present our Double Four-Effect Evaporator built with 316L stainless steel, CIP cleaning capability, 220V power supply, 600L/H processing capacity, and semi-automatic operation. This evaporator is designed to deliver exceptional energy efficiency and reliable performance for concentration processes in food, pharmaceutical, and chemical industries. As a manufacturer with annual export value exceeding US$10 million, we combine advanced engineering with rigorous quality control to offer a solution that maximizes evaporation efficiency while minimizing operational costs.
Key Features & Technical Specifications
- 316L Stainless Steel Construction – Superior corrosion resistance, ideal for acidic or saline solutions, ensuring long service life and product purity.
- Four-Effect Evaporation Design – Utilizes vapor recompression to achieve high energy savings, reducing steam consumption by up to 60% compared to single-effect evaporators.
- CIP (Clean-in-Place) System – Built-in automated cleaning nozzles allow thorough cleaning without disassembly, reducing downtime and labor costs.
- Semi-Automatic Operation – User-friendly PLC control with manual override, providing flexibility for batch processes while maintaining consistent quality.
- 220V Power Supply – Compatible with standard industrial electrical systems, simplifying installation in many regions.
- 600 L/H Capacity – Suitable for medium-scale production, balancing throughput with footprint.
- Compact Footprint – Optimized layout saves floor space, ideal for limited production areas.
| Parameter | Value |
|---|---|
| Material of Construction | 316L Stainless Steel |
| Number of Effects | 4 (Double Four-Effect) |
| Evaporation Capacity | 600 L/H |
| Power Supply | 220V, 50/60 Hz (3-phase optional) |
| Cleaning Method | CIP (Clean-in-Place) |
| Automation Level | Semi-Automatic |
| Operating Temperature | Up to 120°C (adjustable) |
| Dimensions (L×W×H) | Customizable, typical 3.5m × 1.8m × 2.2m |
Detailed Advantages & Benefits
The Double Four-Effect Evaporator is engineered to maximize thermal efficiency. Each effect reuses vapor from the previous stage, dramatically reducing energy consumption. The 316L construction ensures compatibility with a wide range of liquids, including those containing chlorides or other corrosive agents. The integrated CIP system allows for automated cleaning cycles, which not only saves labor but also ensures consistent hygiene standards critical for food and pharmaceutical applications. The semi-automatic control system provides operators with real-time monitoring and adjustment capabilities, while still allowing manual intervention when needed. With a capacity of 600 L/H, this evaporator is ideal for small to medium-sized production lines that require reliable, energy-efficient concentration.
Benefit to your business:
- Lower operating costs thanks to multi-effect energy savings.
- Reduced maintenance downtime with CIP cleaning.
- High product purity due to 316L material and gentle evaporation.
- Flexible automation level suits different operator skill levels.
- Compact design fits into existing plant layouts.
Company Credibility & Trust
Qingdao Conqinphi Environmental Technology Group Co., Ltd. has been a trusted manufacturer since 2015, with a factory size of 10,000-30,000 square meters and a dedicated team of 201-300 employees. Our annual export value exceeds US$10 million, and we serve markets across North America, South America, Europe, Asia, Africa, and Oceania. Our products are manufactured under strict quality management systems, and we hold certifications such as HACCP, ISO9001, and ISO14000, ensuring that every unit meets international standards. We are committed to providing reliable after-sales support, including installation guidance, commissioning, and spare parts supply.
Why choose Conqinphi? Our extensive experience in evaporation technology, combined with our global shipping capability from Qingdao port, enables us to deliver high-quality equipment at competitive prices. We invite you to contact us for a customized solution tailored to your specific process requirements.
Frequently Asked Questions (FAQ)
-
Q: What is the difference between a double four-effect and a single-effect evaporator?
A: A double four-effect evaporator uses four stages of evaporation, reusing vapor from one effect to heat the next. This design can reduce steam consumption by 50-70% compared to a single-effect unit, making it much more energy-efficient for continuous operation. -
Q: Is the 316L material suitable for all types of liquids?
A: 316L stainless steel offers excellent resistance to corrosion from chlorides, acids, and alkalis. It is suitable for most food, pharmaceutical, and chemical solutions. However, for extremely aggressive media (e.g., concentrated hydrochloric acid), we recommend consulting our technical team for material assessment. -
Q: Can the CIP system be customized for specific cleaning agents?
A: Yes, the CIP system is designed to work with standard cleaning solutions (e.g., NaOH, HNO3). The cycle parameters such as flow rate, temperature, and duration can be adjusted via the PLC program to match your cleaning requirements. We can also provide optional CIP tanks and pumps. -
Q: What is the power consumption of this evaporator at 220V?
A: The total installed power depends on the auxiliary equipment (pumps, control panel, etc.). Typically, the main power consumption is around 15-25 kW for the vacuum pump and circulation pumps. A detailed electrical load sheet can be provided upon request. -
Q: Is the semi-automatic operation easy to learn?
A: Yes, the semi-automatic control system features a touchscreen interface with intuitive menu navigation. Operators can start/stop the process, set temperatures, and monitor key parameters. Basic training takes about 1-2 days, and we provide manuals and remote support. -
Q: What is the delivery time and shipping method?
A: Typical lead time is 30-45 days after order confirmation, depending on customization. We ship from Qingdao port via sea freight. We can arrange FOB, CIF, or other terms as per your requirement. The unit is packed in a wooden crate with proper protection. -
Q: Do you provide installation and commissioning service?
A: Yes, we offer on-site installation and commissioning support by our experienced engineers. Alternatively, we can provide detailed installation drawings and remote guidance. The cost is negotiable based on your location. -
Q: What certifications does this product have?
A: Our manufacturing facility is certified with HACCP, ISO9001, ISO14000, and other quality management systems. The evaporator itself is designed to meet international standards such as ASME or CE (optional). Specific certifications can be provided upon request for your market.
