304 Stainless Steel Double Four-Effect Evaporator, PLC Control, 380V, 1500L/H Capacity
Product Spotlights
High-efficiency 304 stainless steel double four-effect evaporator with PLC control, 1500L/H capacity, 380V. Energy-saving design reduces steam consumption by 40%. Fully automatic operation, suitable for food, pharmaceutical, and chemical industries. Customizable voltage and CIP options. Backed by a 10,000+ m² factory with ISO9001 and HACCP certifications.
US$ 4260 - 785000
MOQ: 1 Combo
Key Specifications
Get Latest Price
Type:
Other, Double Four-Effect
Material:
304 Stainless Steel
Capacity:
1500 L/H
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
90 days
Related Products
-
Mvr and Tvr Evaporators Machine Water Treatment Plant EquipmentUS$ 2140 - 7500MOQ: 1 Combo -
Sewage Treatment Equipment Salt Wastewater Water Mvr EvaporatorUS$ 2140 - 7500MOQ: 1 Combo
-
Forced Circulation/Falling Film Single-Effect Mvr Evaporation Crystallization EvaporatorUS$ 2140 - 7500MOQ: 1 Combo
-
Lithium Carbonate in Battery Manufacturing Mvr EvaporatorUS$ 2140 - 7500MOQ: 1 Combo
-
Water Thin Film Aluminium Plate Vacuum Mvr EvaporatorUS$ 480 - 879000MOQ: 1 Combo
Type
Other, Double Four-Effect
Material
304 Stainless Steel
Capacity
1500 L/H
Voltage
380V, 50Hz, 3 Phase
Control System
PLC with Touch Screen
Application
Pharmaceutical, Food, Chemical
Certification
ISO9001, HACCP, CE (optional)
Heating Method
Steam / Electric (optional)
Evaporation Temperature
Adjustable 40-100°C
Welcome to Qingdao Conqinphi Environmental Technology Group Co., Ltd. – a professional manufacturer with over 10 years of experience in evaporation equipment. Our 304 Stainless Steel Double Four-Effect Evaporator is designed to deliver high-efficiency concentration with a capacity of 1500 L/H, powered by a PLC control system and 380V power supply. This unit combines advanced multi-effect technology with durable construction, ensuring energy savings and reliable operation for demanding industrial processes. Whether you need to concentrate fruit juice, pharmaceutical extracts, or chemical solutions, this evaporator provides consistent performance and easy operation.
Key Features and Benefits:
- Double Four-Effect Design: Utilizes multiple effects to maximize heat recovery, reducing steam consumption by up to 40% compared to single-effect units.
- 304 Stainless Steel Construction: Corrosion-resistant and food-grade material ensures product purity and long service life.
- PLC Control System: Fully automatic operation with touch-screen interface, allowing precise control of temperature, pressure, and flow rate.
- High Capacity (1500 L/H): Suitable for medium to large-scale production lines, handling continuous processing efficiently.
- 380V Power Supply: Standard industrial voltage, compatible with most factory setups; customizable voltage available upon request.
- Energy Saving: Multi-effect circulation reduces energy consumption, lowering operational costs.
- Easy Maintenance: Modular design with quick-access chambers for cleaning and inspection.
Technical Specifications:
| Parameter | Value |
| Material | 304 Stainless Steel |
| Evaporation Capacity | 1500 L/H |
| Power Supply | 380V, 50Hz, 3 Phase |
| Control System | PLC + Touch Screen |
| Number of Effects | Double Four-Effect (8 effects total) |
| Evaporation Temperature | 40-100°C (adjustable) |
| Steam Consumption | Approx. 0.35 kg steam per kg water evaporated |
| Dimensions (L×W×H) | Customizable |
Detailed Advantages:
- High Efficiency: The double four-effect configuration means the vapor from each effect is reused to heat the next, dramatically reducing energy input.
- Precision Control: PLC system monitors and adjusts parameters in real time, preventing product degradation and ensuring consistent quality.
- Versatility: Suitable for heat-sensitive materials (e.g., dairy, fruit juice, herbal extracts) as well as chemical solutions.
- Durability: 304 stainless steel resists corrosion and meets sanitary standards for food and pharmaceutical industries.
- Low Maintenance: CIP (Clean-in-Place) design available, simplifying cleaning between batches.
Trust and Quality Assurance: As a manufacturer with a 10,000-30,000 m² factory and 200+ skilled employees, Qingdao Conqinphi has been delivering evaporation solutions since 2015. Our annual export value exceeds US$10 million, serving markets across North America, Europe, Asia, and more. We hold certifications including ISO9001, HACCP, and QS9000 (available upon request), ensuring each machine meets rigorous quality standards. Our team provides comprehensive after-sales support, including installation guidance and spare parts supply. Contact us today to discuss your specific evaporation needs – we are committed to helping you achieve efficient production with reliable equipment.
Frequently Asked Questions (FAQ)
-
Q: What is the difference between a double four-effect evaporator and a standard multi-effect evaporator?
A: The double four-effect design combines two sets of four-effect evaporators in series, allowing for higher concentration ratios and better energy efficiency. It is especially effective for viscous or heat-sensitive liquids. -
Q: Can this evaporator handle materials with high fouling tendency?
A: Yes, the 304 stainless steel construction and optional CIP system make it suitable for materials like fruit juice, milk, and herbal extracts. For extremely sticky substances, we recommend adding a forced circulation option. -
Q: What is the minimum steam pressure required?
A: Typically, we recommend saturated steam at 0.3-0.6 MPa. However, the system can be customized for lower or higher pressures upon request. -
Q: Does the PLC control support remote monitoring?
A: Yes, our PLC system can be equipped with Ethernet or wireless modules for remote data logging and monitoring via SCADA systems (optional). -
Q: What is the warranty period?
A: We offer a standard 12-month warranty from the date of shipment, covering manufacturing defects. Extended warranties are available as an option. -
Q: Can you customize the voltage or frequency?
A: Absolutely. The standard model is 380V/50Hz, but we can adapt to 220V, 415V, 60Hz, or other specifications based on your local power supply. -
Q: What certifications does this product have?
A: Our factory is certified under ISO9001, HACCP, and other standards. Specific product certifications (e.g., CE, GMP) can be arranged for an additional fee. -
Q: How long does delivery take?
A: Typically 30-45 working days after order confirmation, depending on customization requirements.
