As a leading manufacturer based in Qingdao, China, Qingdao Conqinphi Environmental Technology Group Co., Ltd. has been dedicated to the design and production of industrial evaporation systems since 2015. Our Double Four-Effect Evaporator represents the latest advancement in energy-efficient concentration technology, delivering reliable performance for demanding processes. Built with precision engineering and backed by a 1-year warranty, free technical support, and a comprehensive mill test report, this evaporator ensures your operations run smoothly from day one.
The Double Four-Effect Evaporator integrates two four-effect evaporation cycles in a compact, modular design, maximizing heat recovery while minimizing operational costs. Ideal for concentrating solutions in wastewater treatment, chemical processing, and pharmaceutical manufacturing, this system offers exceptional flexibility and durability. Each unit undergoes rigorous testing before shipment, and our team provides full installation guidance and troubleshooting assistance.
Key Features & Technical Specifications
- High Energy Efficiency: The four-effect design reuses vapor from each effect, reducing steam consumption by up to 60% compared to single-effect evaporators.
- Double Configuration: Two independent four-effect trains allow parallel or series operation, increasing throughput and redundancy.
- Superior Material Quality: All wetted parts are made from 316L stainless steel or customized alloys to resist corrosion and scaling.
- Automated Control: Equipped with a PLC-based control system for precise temperature, pressure, and flow regulation. Remote monitoring and data logging are available upon request.
- Flexible Capacity: Standard evaporation capacities range from 0.5 to 50 tons per hour, with custom designs for larger or smaller requirements.
- Comprehensive Documentation: Each unit includes a mill test report verifying material properties and weld integrity, ensuring compliance with industry standards.
| Parameter | Specification |
|---|---|
| Number of Effects | 4 per train (Double Four-Effect) |
| Evaporation Capacity | 1 – 100 T/h (customizable) |
| Operating Temperature | 60°C – 120°C (adjustable) |
| Material of Construction | 316L SS, 304 SS, or Hastelloy (optional) |
| Power Consumption | 30 – 150 kW depending on capacity |
| Control System | Siemens PLC + HMI touchscreen |
| Warranty | 1 year (parts and labor) |
| Mill Test Report | Included with each shipment |
Customer Benefits
- Reduced Operating Costs: Lower steam and electricity consumption directly cut your utility expenses.
- Minimal Downtime: Robust construction, easy maintenance, and free technical support keep your production on track.
- Compliance & Reliability: Mill test reports provide traceability for quality audits and regulatory requirements.
- Scalability: The modular design allows easy expansion if your capacity needs grow.
Why Choose Qingdao Conqinphi?
With a factory covering 10,000 – 30,000 square meters and a skilled team of 201–300 employees, we have the production capacity to deliver large-scale orders efficiently. Our annual export value exceeds US$10 million, reaching markets across North America, South America, Europe, Asia, Africa, and Oceania. We hold multiple certifications including ISO9001, ISO14000, OHSAS18001, HACCP, SA8000, and others, ensuring our products meet international quality and safety standards.
Our Double Four-Effect Evaporator has been trusted by clients in over 30 countries for its reliability and performance. We provide free technical support throughout the warranty period and beyond, with rapid response to any inquiries. Choose Conqinphi for a partnership that prioritizes your success. Contact us today to discuss your specific evaporation requirements or request a quotation.
Frequently Asked Questions
-
What is the difference between a double four-effect and a conventional four-effect evaporator?
The double four-effect design incorporates two independent four-effect trains, allowing higher total capacity, redundancy, and flexible operation (parallel or series). This configuration also offers better energy recovery and process control. -
What materials are used for the evaporator construction?
Standard construction is 316L stainless steel. Other alloys such as 304 SS, duplex stainless steel, or Hastelloy are available depending on the corrosiveness of your feed solution. Please advise your specific chemical composition. -
How long is the delivery time?
Lead time typically ranges from 45 to 90 days, depending on the customization level and order volume. Faster delivery may be arranged for standard units. -
Do you provide installation and commissioning support?
Yes, we offer remote guidance and on-site commissioning services (optional). Our free technical support covers troubleshooting and maintenance advice. -
What is included in the mill test report?
The mill test report provides material certifications, weld inspection results, dimensional checks, and pressure test records. It is essential for quality assurance and regulatory compliance. -
Can the evaporator handle viscous or fouling liquids?
Yes, the double four-effect design can be equipped with mechanical cleaning systems (e.g., scraped surface or forced circulation) to handle high-viscosity or scaling-prone fluids. We recommend a process evaluation to determine the best configuration. -
What is the warranty coverage?
We offer a 1-year warranty covering defects in materials and workmanship. Free technical support is available during the warranty period, and extended service contracts can be arranged. -
How do you ship the evaporator?
We ship from Qingdao Port in containers or as breakbulk cargo, depending on size. All units are securely packed and protected for ocean freight.
