Welcome to Anping County Boli Hardware Wiremesh Products Factory – a trusted manufacturer specializing in sintered metal filter elements since 1998. Our Sintered Copper Powder Filter Element is engineered to deliver exceptional filtration performance in demanding industrial applications. With a 1-year warranty and mill test report provided, we ensure every filter meets rigorous quality standards. This product combines high mechanical strength, uniform porosity, and excellent corrosion resistance, making it an ideal choice for fluid and gas purification systems.
Our sintered copper powder filter elements are produced through advanced powder metallurgy technology, resulting in a robust, porous structure that effectively traps contaminants while maintaining high flow rates. Whether you need to filter aggressive chemicals, high-temperature gases, or hydraulic fluids, this element offers reliable and long-lasting performance. Backed by over 20 years of manufacturing experience and annual exports exceeding US$5 million, we are your reliable partner for industrial filtration solutions.
Key Features & Benefits
- Uniform Pore Structure: Controlled sintering process ensures consistent pore size distribution, enhancing filtration accuracy and efficiency.
- High Mechanical Strength: Copper powder bonding provides excellent pressure resistance, suitable for high-pressure applications up to 50 bar.
- Excellent Thermal Conductivity: Copper material allows rapid heat dissipation, ideal for high-temperature filtration (up to 300°C).
- Corrosion Resistance: Resistant to many chemicals, including oils, solvents, and mild acids, extending service life.
- Easy to Clean & Reusable: Can be backwashed, ultrasonically cleaned, or chemically regenerated, reducing replacement costs.
- Customizable Dimensions: Available in various lengths, diameters, and shapes to fit your existing housing.
- 1-Year Warranty: We stand behind our product quality; mill test report included for traceability.
Technical Specifications
| Parameter | Value |
|---|---|
| Material | Sintered copper powder (Cu >99.5%) |
| Filtration Grade | 1 – 100 microns (customizable) |
| Operating Temperature | -20°C to +300°C |
| Max Differential Pressure | 50 bar (at 20°C) |
| Porosity | 30% – 60% (adjustable) |
| Length | 100 – 1000 mm (custom) |
| Outer Diameter | 20 – 200 mm (custom) |
| End Caps | Stainless steel, copper, or other (optional) |
| Warranty | 1 year |
Applications
- Gas Filtration: Compressed air, natural gas, steam, and inert gas purification.
- Liquid Filtration: Hydraulic oils, coolants, solvents, water, and chemical processing.
- Pharmaceutical & Food Industry: Sterile filtration, catalyst recovery, and beverage clarification.
- Petrochemical & Refinery: Filtering corrosive fluids, polymer melts, and high-temperature streams.
- Automotive & Aerospace: Fuel, lubricant, and hydraulic system filtration.
Our sintered copper powder filter elements are designed to replace traditional wire mesh, paper, or polymer filters in harsh environments. The rigid metal structure prevents media migration and withstands high differential pressure, ensuring consistent filtration over long periods. With a 1-year warranty and mill test report provided, you can be confident in the quality and performance of each element.
Why Choose Boli Hardware Wiremesh?
Since 1998, we have been dedicated to manufacturing high-quality industrial wire mesh and sintered products. Our factory is located in Hengshui, Hebei, China, and we export to markets worldwide including North America, South America, Europe, Southeast Asia, Africa, and Oceania. With an annual export value of US$5 million – US$10 million, we have established a strong reputation for reliability and customer service. We offer flexible shipping options from Tianjin, Qingdao, Shanghai, and Foshan ports. Every order is supported by our experienced team, ensuring timely delivery and technical support. We invite you to contact us for custom designs, additional testing, or bulk orders. Your satisfaction is our priority.
