Help CenterPA66 Coated Filter Cartridge for Industrial Water Filtration, 20 Micron, 304 SS End Caps
Product Spotlights
Related Products
-
PE/PA Filter Cartridge 1 Micron for Food and Beverage Processing Sediment RemovalNegotiableMOQ: 1 Piece -
PE/PA Filter Cartridge 1 Micron 10 Inch 226 O-Ring Standard Compliant With Technical SupportNegotiableMOQ: 1 Piece
-
PE/PA Membrane Filter Cartridge 10 Inch Warranty 1 Year With Mill Test Report and Batch TraceabilityNegotiableMOQ: 1 Piece
-
PE/PA Membrane Filter Cartridge 0.5μm 30-inch Length for Fine Filtration ApplicationsNegotiableMOQ: 1 Piece
-
Polyether Sulfone/Polyamide Filter Cartridge 0.22μm 10-inch With Silicon GasketNegotiableMOQ: 1 Piece
Welcome to Anping County Boli Hardware Wiremesh Products Factory – a trusted manufacturer since 1998, specializing in high-performance filtration solutions. Our PA66 Coated Filter Cartridge with 20 micron rating and 304 stainless steel end caps is engineered for demanding industrial water filtration applications. Combining advanced corrosion resistance, precise filtration, and robust mechanical strength, this cartridge delivers consistent performance across diverse water treatment systems. With over two decades of manufacturing expertise and an annual export value exceeding US$5 million, we ensure every cartridge meets rigorous quality standards for global clients.
Key Features & Technical Specifications
- PA66 Coating: Provides excellent chemical resistance against acids, alkalis, and solvents, extending service life in harsh environments.
- 20 Micron Filtration Rating: Effectively removes suspended solids, sediments, rust, and particles ≥20 µm, ideal for pre-filtration or fine filtration stages.
- 304 Stainless Steel End Caps: High strength and corrosion resistance ensure leak-proof sealing and long-term durability under high pressure or temperature fluctuations.
- High Dirt Holding Capacity: Pleated design (optional) increases surface area, reducing replacement frequency and operational costs.
- Wide Compatibility: Fits standard 2.5" OD filter housings with 1" ID center tube; available in lengths from 10" to 40" to suit various systems.
- Customizable Options: End cap configurations (double open end, flat with gasket, etc.) and media pore size variations available upon request.
| Parameter | Specification |
| Filter Media | PA66 (polyamide 66) coated fabric |
| Filtration Rating | 20 microns nominal |
| End Caps Material | 304 Stainless Steel |
| Max Operating Temperature | 80°C (176°F) continuous |
| Max Pressure Drop | 4.0 bar (58 psi) at 25°C |
| Length Options | 10", 20", 30", 40" (customizable) |
| Outer Diameter | 2.5" (63 mm) |
| Inner Diameter | 1.0" (25 mm) |
| Application | Industrial water filtration, RO pre-treatment, cooling water, process water |
Why Choose Our PA66 Coated Filter Cartridge?
- Durable Construction: The PA66 coating resists hydrolysis and microbial attack, making it suitable for prolonged use in wet environments.
- Cost-Effective Operation: With high dirt holding capacity and low initial pressure drop, the cartridge reduces energy consumption and replacement cycles.
- Enhanced Sealing: 304 SS end caps provide stable sealing even under thermal cycling, preventing bypass of unfiltered water.
- Easy Installation: Standard dimensions ensure drop-in replacement for most industrial filter housings without modification.
- Environmental Compliance: PA66 is a recyclable material, and the stainless steel end caps can be reused, supporting sustainable filtration practices.
Trust in Our Manufacturing Excellence
Anping County Boli Hardware Wiremesh Products Factory has been serving global markets since 1998. With annual exports reaching US$5-10 million, our products are shipped to major ports including Tianjin, Qingdao, Shanghai, and Foshan, reaching customers across North America, Europe, Asia, Africa, and Oceania. Our main markets span over 15 regions, reflecting widespread international recognition. Every filter cartridge undergoes strict quality control, from raw material inspection to final packaging. We are committed to providing reliable filtration solutions that meet diverse industrial requirements. Contact us today for competitive pricing, custom specifications, and prompt delivery.
Frequently Asked Questions (FAQ)
- What is the maximum operating temperature for this cartridge? The cartridge can operate continuously at up to 80°C (176°F). For higher temperatures, please consult our technical team for custom solutions.
- Can this filter be used for chemical solutions? Yes, the PA66 coating offers good resistance to many chemicals, including acids, alkalis, and organic solvents. However, we recommend testing compatibility with your specific fluid before full-scale use.
- What is the typical lifespan of the cartridge? Lifespan depends on feed water quality and operating conditions. Under normal industrial water filtration (TSS
- Are the end caps reusable? The 304 SS end caps are designed for single-use disposable cartridges, but they can be recycled. If you require reusable components, we can discuss alternative designs.
- Do you offer custom lengths or micron ratings? Yes, we can customize the cartridge length (10" to 40") and micron rating (1-100 microns) according to your requirements. Minimum order quantities may apply.
- Is this cartridge suitable for potable water? The materials used (PA66, 304 SS) are generally considered safe for water contact. However, we recommend verifying compliance with local drinking water regulations if used for potable water applications.
- What is the outer diameter of the cartridge? The standard outer diameter is 2.5 inches (63 mm), suitable for most industrial filter housings. Other diameters are available upon request.
- How should I store the cartridges? Store in a cool, dry place away from direct sunlight and extreme temperatures. Keep in original packaging to prevent contamination.
Get in Touch
For bulk orders, samples, or technical inquiries, please contact our sales team. As a manufacturer with over 25 years of experience, we are dedicated to delivering high-quality filter cartridges that optimize your water treatment process. Let us help you achieve cleaner water and lower operational costs.
