I. Product Overview
The maxon planetary gearbox is precisely manufactured in the original German factory. It is a dedicated coaxial reduction transmission unit that matches maxon DCX brushed and ECX brushless coreless motors. It is divided into two major product lines: the classic GP standard series and the new-generation lightweight GPX high-performance series, covering the range from Φ4mm micro to high-torque industrial specifications, with a torque range of 0.002 Nm to 120 Nm. It is specially designed for narrow spaces, high precision, high speed, and extreme working conditions, and is the benchmark micro-reduction component in the global medical, aviation, precision optics, and micro-robot fields. Maxon Grou...
It adopts a standard planetary coaxial transmission structure, with the input and output in the same direction. Multiple planet gears are synchronously stressed, and the torque density is much higher than that of ordinary cylindrical gearboxes. It has a modular 1 - 5 stage stacking design, with a reduction ratio covering the full range from 3.9:1 to 6285:1, which can be freely matched according to needs. It is calibrated and matched with the corresponding motor at the factory, eliminating the need for additional adapter accessories, and maximizing the coaxiality and transmission stability.
II. Distinction between the Two Core Product Lines
1. GP Series (Classic Standard Model)
Positioning: Economical and general-purpose planetary gearhead, with sufficient stock and high cost-performance ratio
Size: All specifications such as Φ6/8/10/16/22/32mm, including the commonly used GP 6 A (Φ6mm, 0.002 - 0.03 Nm)
Structure: Steel housing + standard steel planet gears, with ball output bearings as standard
Application: Conventional automation, laboratory equipment, general precision fine-tuning mechanisms
Temperature range: -40℃ ~ +100℃, supporting stable operation at high and low temperatures
2. GPX Series (New-Generation High-Performance Model)
The GPX has a built-in bearing planet gear structure
Positioning: Lightweight, high-speed, low-noise, high-precision upgraded model, derived from the technology transfer of aerospace projects. maxon grou...
It is subdivided into multiple configuration versions to cover diverse working conditions:
A Standard Edition: Steel gears, for general industrial scenarios
C Ceramic Edition: Ceramic planet gears, wear-resistant, with double the service life and higher ultimate torque
UP High-performance Model: The planetary gear is equipped with needle/ball bearings inside. Rolling friction replaces sliding friction, with a transmission efficiency of 90%. It supports force feedback and reversible transmission, and is mostly used in surgical robots and aviation mechanisms.
Low-backlash Model: Extremely small return clearance and high-precision positioning.
Silent Plastic Model: Low noise, suitable for silent equipment such as cameras and endoscopes.
Advantages: Shorter body, lighter weight, higher allowable input speed, and a 30% reduction in vibration noise.
III. Advantages of Core General Technologies
Compact and high torque density. The minimum outer diameter is only 4mm. It can output large torque corresponding to the specification in an extremely small volume, and is perfectly suitable for equipment with limited installation space such as endoscopes, micro probes, and wearable devices.
Extremely low backlash and accurate positioning. The backlash of the standard model, Class 1, is ≤1.8°. The high-precision customized model can reach within 0.1°. There is no return clearance error, which is suitable for scenarios such as lens focusing, micro titration, and servo positioning.
High transmission efficiency and low heat generation. The single-stage transmission efficiency is 88%–90%. The friction loss of the UP series is greatly reduced. The temperature rise during long-term continuous operation is controllable, which prolongs the overall service life of the motor and the gearbox.
Ultra-high speed tolerance. The continuous input speed of the micro specification can reach 40000 rpm. It is matched with the ECX series high-speed brushless micro motors, with no risk of tooth breakage or overheating.
Multiple material selections, suitable for extreme working conditions. Metal/ceramic/plastic planetary gears are optional. It supports customization for high temperature, low temperature, medical sterilization, and dust and water protection (IP54–IP67). It has a wide temperature range of - 40℃~+150℃, suitable for satellites and field detection equipment.
Modular and rapid customization. The number of stages, reduction ratio, output shaft diameter, shaft length, bearing type, and backlash level can all be customized. The original factory can provide STEP 3D drawings and Datasheet selection manuals.
Low vibration and low noise. The gear tooth surface is precisely ground, with uniform and smooth meshing and no harsh abnormal noise. It is suitable for noise-sensitive equipment such as medical and optical equipment.
IV. Typical Application Industries
High-end medical equipment: Minimally invasive surgical instruments, endoscope steering drives, biopsy probes, micro infusion pumps, dental grinding motors, force feedback joints of surgical robots, and in vitro diagnostic instruments.
Precision optical instruments: Automatic focusing modules of microscopes, fine adjustment of laser galvanometers, fundus cameras, spectrometers, optical scanning probes, and industrial vision focusing mechanisms.
Aerospace satellite micro valves, Mars exploration actuators, UAV gimbal servos, airborne micro adjustment units (GPX UP for aerospace special use).
Micro intelligent robot pipeline inspection micro robots, bionic fingertip grippers, micro joint drives, small bionic teaching aids.
Industrial automation and laboratory semiconductor micro drives, micro titration equipment, handheld detection analyzers, small precision transmission modules.
V. Supply and supporting information
Shanghai Detuo Intelligent Engineering Co., Ltd. Manager Du
WeChat / Phone: 13042119416
Email: duzhihong@daitto.com
