As a trusted manufacturer since 1998, Anping County Boli Hardware Wiremesh Products Factory proudly presents the Custom Glass Fiber Filter Cartridge specifically engineered for demanding chemical processing applications. With an annual export value exceeding US$5 million and a global footprint spanning North America, Europe, Asia, and beyond, we combine decades of wire mesh expertise with advanced filtration technology. This cartridge delivers reliable 0.5 micron filtration, withstands extreme temperatures up to 250°C, and features a robust 304 stainless steel core and end caps — all while meeting ISO compliance standards. Our products are designed to optimize your process efficiency and reduce downtime, backed by a factory that prioritizes quality and customization.
Product Features & Technical Specifications
- High-Efficiency Filtration: 0.5 micron absolute rating ensures removal of fine particles, suspended solids, and contaminants from aggressive chemical streams.
- Thermal Resistance: Capable of continuous operation at 250°C, suitable for hot chemical processes, oil filtration, and high-temperature gas filtration.
- Corrosion-Resistant Construction: 304 stainless steel core and end caps provide excellent resistance to acids, alkalis, and solvents, extending cartridge life.
- Glass Fiber Media: High dirt-holding capacity, low pressure drop, and consistent performance across varying flow rates and viscosities.
- ISO Compliant Manufacturing: Produced under strict quality control procedures to ensure dimensional accuracy and filtration consistency.
- Fully Customizable: Available in a range of lengths, O-ring materials (e.g., Viton, EPDM, PTFE), and end cap configurations to fit standard or proprietary housings.
- Broad Chemical Compatibility: Suitable for acids, bases, solvents, hydrocarbons, and other aggressive media used in chemical processing.
| Parameter | Specification |
|---|---|
| Filtration Rating | 0.5 micron (absolute) |
| Maximum Operating Temperature | 250°C (482°F) |
| Core & End Cap Material | 304 Stainless Steel |
| Filter Media | Borosilicate Glass Fiber |
| Initial Pressure Drop | 0.2 bar (typical) at 10 L/min per 10" cartridge |
| Maximum Differential Pressure | 3.5 bar (50 psi) at 25°C |
| Standard Lengths | 10", 20", 30", 40" (custom lengths available) |
| Seal Options | Viton, EPDM, PTFE, Buna-N (customizable) |
| Compliance | ISO 9001 (manufacturing quality system) |
Why Choose Our Custom Glass Fiber Filter Cartridge?
Enhanced Process Efficiency – The 0.5 micron filtration ensures that your chemical processes maintain high purity, reducing product rejects and protecting downstream equipment from abrasive particles. The low initial pressure drop minimizes energy consumption, while the high dirt-holding capacity extends service intervals, lowering your total cost of ownership.
Superior Durability in Harsh Conditions – Glass fiber media combined with 304 stainless steel components withstands aggressive chemicals and thermal cycling. Whether you are filtering hot acids, alkaline solutions, or high-temperature solvents, this cartridge maintains structural integrity and consistent performance over time.
Customization for Your Specific Needs – As a manufacturer with over 25 years of experience, we offer full customization: length, outer diameter, end cap type (open end, closed end, 222/226 fins), and gasket materials. Our engineers work closely with you to ensure the cartridge fits your existing housing and meets your process parameters.
Frequently Asked Questions (FAQ)
Q1: What is the maximum differential pressure at 250°C?
A: At 250°C, the maximum recommended differential pressure is 2.0 bar (29 psi). For higher delta P applications, please consult with our technical team for special design options.
Q2: Can I use this cartridge for water filtration?
A: While designed for chemical processing, it can be used for water applications requiring high-temperature or fine filtration. However, for standard water filtration, we offer more economical alternatives. Please contact us for recommendations.
Q3: Is the cartridge compatible with my existing housing?
A: We provide standard dimensions compatible with most common housings (e.g., 222/226 O-ring, flat closed end, etc.). For custom housings, we can adjust the length, end cap, and gasket to ensure a perfect seal.
Q4: What seal materials are available for high-temperature applications?
A: For temperatures above 200°C, we recommend Viton (FKM) or PTFE encapsulated O-rings. EPDM and Buna-N are suitable for lower temperatures. We can provide a seal compatibility chart upon request.
Q5: How do I order a custom-length cartridge?
A: Simply provide your desired length (in inches or millimeters), end cap style, and gasket material. Our sales team will confirm the lead time and pricing. Minimum order quantity may apply for custom sizes.
Q6: Does this filter cartridge meet any specific industry standards?
A: Our manufacturing facility is ISO 9001 certified, and each cartridge is produced following ISO-compliant procedures. We also offer testing certificates for filtration efficiency and material traceability on request.
Q7: What is the typical lifespan of this cartridge?
A: Lifespan depends on the contaminant load and operating conditions. Under typical chemical processing environments, a 0.5 micron glass fiber cartridge can last 3–6 months before replacement is needed. We recommend periodic differential pressure monitoring to determine change-out intervals.
Q8: Can you provide samples for testing?
A: Yes, we offer sample orders for evaluation. Please contact our sales team with your specific requirements, and we will arrange a sample with a competitive lead time.
Trusted by Global Industries – Over 25 Years of Filtration Excellence
Since 1998, Anping County Boli Hardware Wiremesh Products Factory has been a reliable partner for chemical processing, oil & gas, pharmaceutical, and water treatment industries. With annual exports of US$5–10 million and a presence in over 30 countries (including North America, Europe, Southeast Asia, Africa, and Oceania), we have shipped thousands of custom filter cartridges worldwide. Our facility in Hengshui, Hebei, China, is equipped with advanced production lines and rigorous quality testing. We ship via Tianjin, Qingdao, Shanghai, and Foshan ports, ensuring fast and cost-effective logistics. Choose our custom glass fiber filter cartridge — a product built on precision, experience, and a commitment to your process success. Contact us today for a quote or technical consultation.
