Stainless Steel Heat Exchanger for Chemical Reactor Cooling 316L 50 Tubes 1MPa
Product Spotlights
316L stainless steel construction with 50 tubes for efficient chemical reactor cooling. Rated 1MPa, customizable design, and full quality assurance (hydrostatic test, ISO9001). Corrosion-resistant, compact, and cost-effective solution from a trusted Chinese manufacturer with global export experience.
US$ 2170 - 8260
MOQ: 1 Combo
Key Specifications
Get Latest Price
Material:
Other, 316L Stainless Steel
Application:
Other, Chemical Reactor Cooling
Tube Count:
50
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
6 days
Related Products
-
316L Stainless Steel Plate Heat Exchanger 200kW Cooling Capacity 30 Bar Pressure RatingUS$ 2170 - 8260MOQ: 1 Combo -
304 Stainless Steel Shell and Tube Heat Exchanger 150 PSI 200°F 20 Tubes 1" DiameterUS$ 2170 - 8260MOQ: 1 Combo
-
Customizable Stainless Steel Heat Exchanger 12 Month Warranty Technical Support IncludedUS$ 2170 - 8260MOQ: 1 Combo
-
Stainless Steel Heat Exchanger 20 Plates 2" Connections 304 Grade 150 PSI DesignUS$ 2170 - 8260MOQ: 1 Combo
-
1 Year Warranty Stainless Steel Heat Exchanger 304 Grade Mill Test Report AvailableUS$ 2170 - 8260MOQ: 1 Combo
Material
Other, 316L Stainless Steel
Application
Other, Chemical Reactor Cooling
Tube Count
50
Design Pressure
1MPa
Type
Shell and Tube Heat Exchanger
Connection Type
Flanged or Threaded (Customizable)
Surface Finish
Pickled & Passivated or Mirror Polished (Optional)
Customization
Available upon request
Qingdao Conqinphi Environmental Technology Group Co., Ltd. is a professional manufacturer with over 10 years of experience in heat transfer equipment, operating from a 10,000-30,000 m² factory in Qingdao, China. Our 316L Stainless Steel Heat Exchanger for Chemical Reactor Cooling is engineered to provide reliable and efficient heat exchange under demanding chemical processing conditions. Featuring 50 tubes and rated for 1MPa pressure, this shell-and-tube heat exchanger is designed to maximize cooling performance while maintaining corrosion resistance and structural integrity. With annual export value exceeding US$10 million and a dedicated team of 201-300 employees, we deliver solutions trusted by clients across North America, Europe, Asia, and more.
Key Features & Technical Specifications
- Premium 316L Stainless Steel Construction: Offers superior resistance to chlorides, acids, and other corrosive chemicals commonly found in reactor cooling loops. Lower carbon content minimizes sensitization during welding, ensuring long service life.
- Optimized 50-Tube Configuration: Provides a large heat transfer surface area while maintaining a compact footprint. The tube layout is designed to reduce fouling and facilitate easy cleaning.
- Rated for 1MPa (10 bar) Operating Pressure: Suitable for moderate to high-pressure cooling applications in chemical reactors, ensuring safety and reliability under standard process conditions.
- Customizable Design: Tube length, shell diameter, baffle spacing, and nozzle orientations can be tailored to match your reactor’s cooling jacket or external loop. Available in flanged or threaded connections.
- Full Penetration Welding: All welds are performed by certified technicians using automated TIG or MIG processes, with optional radiographic or dye-penetrant testing.
- Thorough Quality Assurance: Each exchanger undergoes hydrostatic pressure testing at 1.5 times the design pressure (1.5MPa) and helium leak testing upon request.
| Parameter | Specification |
|---|---|
| Material | 316L Stainless Steel (ASTM A240/A249) |
| Tube Count | 50 |
| Tube Dimensions | Customizable (e.g., OD 19mm × 2mm wall thickness) |
| Design Pressure | 1MPa (10 bar) |
| Design Temperature | -20°C to +200°C (customizable to higher range) |
| Shell Side / Tube Side Media | Cooling water (shell) / reactor fluid (tubes) or vice versa |
| Connections | Flanged (ANSI/DIN/JIS) or threaded (NPT/BSP) |
| Surface Finish | Pickled & passivated (standard); mirror polish available |
| Testing | Hydrostatic 1.5MPa, Helium leak optional |
| Standards Compliance | ISO9001, ISO14001, OHSAS18001 (factory level); product design per ASME VIII (optional) |
Benefits for Your Chemical Reactor Cooling Process
- Enhanced Heat Transfer Efficiency: The 50-tube design with optimized baffle spacing promotes turbulent flow, reducing film resistance and improving overall heat transfer coefficient (U-value).
- Corrosion Resistance Minimizes Downtime: 316L withstands aggressive chemicals such as sulfuric acid, phosphoric acid, and chloride-containing solutions, extending maintenance intervals.
- Reliable Performance Under 1MPa: The robust construction ensures safe operation even during pressure fluctuations, protecting your reactor from thermal shock.
- Easy Integration: Compact design allows installation in limited spaces; multiple nozzle orientations adapt to existing piping layouts.
- Customizable for Specific Reactor Designs: Whether you need a vertical or horizontal configuration, we can adjust tube length, shell diameter, and support saddles to match your reactor’s cooling jacket or external circulation loop.
- Cost-Effective Solution: Compared to exotic alloys, 316L offers a balance of performance and affordability, lowering your total cost of ownership.
Why Choose Qingdao Conqinphi?
As a manufacturer with a 10,000–30,000 m² factory and annual export value between US$10 million and US$50 million, we have the capacity to deliver high-quality heat exchangers consistently. Our team of 201–300 skilled professionals implements strict quality controls under ISO9001, ISO14001, and OHSAS18001 management systems. We have shipped cooling solutions to markets across North America, South America, Europe, Southeast Asia, Africa, Oceania, and the Middle East. Each stainless steel heat exchanger is backed by comprehensive testing and a responsive after-sales service team. We invite you to request a quotation or discuss your specific reactor cooling requirements – our engineers will provide a tailored design within 24 hours.
Frequently Asked Questions
-
Q: Can this heat exchanger be used with corrosive chemicals other than typical reactor coolants?
A: Yes. 316L stainless steel is suitable for many corrosive media, including dilute sulfuric acid, phosphoric acid, and organic acids. For highly corrosive environments like hydrochloric acid, we recommend evaluating the specific concentration and temperature; alternatively, we can offer higher-grade alloys (e.g., 904L or Hastelloy) upon request. -
Q: What is the typical lead time for a custom heat exchanger with 50 tubes?
A: Standard lead time is 30–45 days after order confirmation, depending on complexity and current production load. Expedited delivery may be available for urgent projects. -
Q: Do you provide thermal performance data (e.g., heat transfer area, U-value)?
A: Yes. We perform thermal calculations based on your process conditions (flow rates, inlet/outlet temperatures, fluid properties). We can provide a detailed datasheet including surface area, LMTD, and estimated U-value for your approval before manufacturing. -
Q: Can the heat exchanger be designed for vertical installation?
A: Absolutely. We offer both vertical and horizontal configurations. Vertical designs are common for minimizing footprint and facilitating natural drainage. Please specify your preference during inquiry. -
Q: What certifications or quality documentation do you supply?
A: We provide a material test certificate (MTC) per EN 10204 3.1, hydrostatic test report, and welding procedure qualification records (WPQR). Our factory is ISO9001 certified, and we can also comply with ASME VIII Div.1 (U-stamp) at additional cost. -
Q: How do you ensure the cleanliness of the tubes for pharmaceutical or food-grade applications?
A: For applications requiring high cleanliness, we offer electropolishing and passivation, followed by bagging and sealing. We also provide certification of surface finish (Ra ≤ 0.8 μm) if required. -
Q: What is the maximum operating temperature for this 316L heat exchanger?
A: Standard design temperature range is -20°C to +200°C. For higher temperatures up to 400°C, we can adjust the material thickness and gasket selection. Please consult our engineering team for specific thermal requirements. -
Q: Can you supply spare tubes or tube bundles for future replacement?
A: Yes, we can provide spare tube bundles or individual tubes with the same specifications. We recommend ordering a spare set during initial procurement to avoid production delays.
Contact us today to discuss your chemical reactor cooling needs. Our team is ready to deliver a reliable, custom-engineered 316L stainless steel heat exchanger that meets your pressure, temperature, and corrosion requirements. Qingdao Conqinphi – your partner in thermal management solutions.
