Help Center304 Stainless Steel Shell and Tube Heat Exchanger 150 PSI 200°F 20 Tubes 1" Diameter
Product Spotlights
Related Products
-
Customizable Stainless Steel Heat Exchanger 12 Month Warranty Technical Support IncludedUS$ 2170 - 8260MOQ: 1 Combo -
Stainless Steel Heat Exchanger 20 Plates 2" Connections 304 Grade 150 PSI DesignUS$ 2170 - 8260MOQ: 1 Combo
-
1 Year Warranty Stainless Steel Heat Exchanger 304 Grade Mill Test Report AvailableUS$ 2170 - 8260MOQ: 1 Combo
-
Stainless Steel Heat Exchanger 40 Tubes 0.5mm Thickness 150°C Max Temp 304L GradeUS$ 2170 - 8260MOQ: 1 Combo
-
320kW Steam Plate Heat Exchanger With 2 Inch Connection Flange ASME StandardUS$ 530 - 8590MOQ: 1 Combo
As a leading manufacturer from Qingdao Conqinphi Environmental Technology Group Co., Ltd., we present our 304 Stainless Steel Shell and Tube Heat Exchanger designed for efficient heat transfer in demanding industrial applications. With a robust construction rated at 150 PSI and 200°F, this unit features 20 tubes of 1-inch diameter, ensuring reliable performance and long service life. Our factory, spanning 10,000–30,000 square meters with over 200 skilled employees, has been delivering high-quality thermal solutions since 2015, backed by multiple international certifications including ISO 9001 and HACCP.
This heat exchanger is engineered for versatility and durability. The 304 stainless steel shell and tubes resist corrosion and oxidation, making it suitable for water, oil, gas, and chemical media. The shell-and-tube design maximizes surface area for efficient heat exchange, while the 20-tube configuration provides ample capacity for moderate flow rates. Below are key technical specifications:
| Parameter | Value |
|---|---|
| Material | 304 Stainless Steel (Shell & Tubes) |
| Max Working Pressure | 150 PSI (10.3 bar) |
| Max Working Temperature | 200°F (93°C) |
| Number of Tubes | 20 |
| Tube Diameter | 1 inch (25.4 mm) |
| Heat Transfer Area | Approx. 5.2 sq. ft (0.48 m²) |
| Connection Size | Customizable (1" – 2" NPT or Flanged) |
Key Features & Benefits:
- Corrosion Resistance: 304 stainless steel construction ensures long-term durability in harsh environments, reducing maintenance costs.
- High Efficiency: The shell-and-tube design with 20 tubes provides a large heat transfer surface, enabling rapid temperature change.
- Easy Installation: Compact footprint and standard connection sizes allow quick integration into existing systems.
- Versatile Applications: Ideal for HVAC, oil cooling, chemical processing, food & beverage, and pharmaceutical industries.
- Customizable Options: Available with different tube layouts, baffle spacing, and materials upon request.
- Safety Compliance: Designed and manufactured under ISO 9001 and HACCP standards, ensuring consistent quality.
Our heat exchangers undergo rigorous testing including pressure tests and thermal performance verification. Each unit is supplied with a detailed inspection report. The 150 PSI rating and 200°F limit cover a wide range of moderate-temperature processes, while the 1-inch tube diameter allows for easy cleaning and maintenance.
As a trusted manufacturer with annual export value exceeding US$10 million, we serve markets across North America, Europe, Asia, and Africa. Our dedicated engineering team can assist with custom designs, including special tube materials (e.g., 316L) or higher pressure ratings. We also offer OEM/ODM services to meet specific project requirements.
Why Choose Us?
- Established in 2015 with a 10,000+ sqm factory and 300+ employees
- Certified ISO 9001, ISO 14000, SA8000, OHSAS 18001, and HACCP
- Professional QC team performing 100% inspection before shipment
- Flexible payment terms and fast delivery from Qingdao port
- After-sales support with technical documentation and spare parts availability
We invite you to contact us for more details, a quotation, or a custom solution. Our sales team is ready to assist with your heat exchanger needs. Experience the reliability and efficiency of our 304 Stainless Steel Shell and Tube Heat Exchanger – built to perform, backed by experience.
Frequently Asked Questions
-
Q: What is the maximum operating temperature for this heat exchanger?
A: The maximum working temperature is 200°F (93°C). For higher temperature applications, we can customize with alternative materials. -
Q: Can I use this heat exchanger with corrosive fluids?
A: Yes, 304 stainless steel offers good resistance to many corrosive media. However, for highly aggressive chemicals, we recommend consulting our engineers for material selection. -
Q: What is the typical lead time?
A: For standard models, lead time is 15–25 working days after order confirmation. Custom designs may require additional time. -
Q: Do you provide installation support?
A: We provide detailed installation manuals and drawings. On-site technical support is available upon request (additional cost). -
Q: How do I clean the heat exchanger?
A: The 1-inch tube diameter allows for mechanical cleaning (brushes) or chemical cleaning. We recommend periodic maintenance based on the fluid type. -
Q: Is certification provided?
A: Yes, each unit comes with a material test certificate and pressure test report. ISO 9001 and HACCP certifications are available for the manufacturing process. -
Q: Can I get a sample before bulk order?
A: Yes, we can provide a sample unit for evaluation. The sample cost is negotiable based on order quantity. -
Q: What payment methods do you accept?
A: We accept T/T, L/C, Western Union, and other commonly used methods. Please contact our sales team for details.
