Help CenterAlkali and Acid Resistant Monel Woven Wire Mesh for Chemical Processing
Product Spotlights
Related Products
-
Stainless Steel Wire Mesh Screen Sheet 100ft x 4ft for Industrial Filtration Basket StrainerUS$ 0.5MOQ: 1000 Units -
Durable Monel 400 Wire Mesh With High Tensile Strength for Industrial UseUS$ 0.5MOQ: 1000 Units
-
50 Mesh 300 Micron Stainless Steel Filter Wire Mesh for Homebrew Hop Bucket StrainerUS$ 0.5MOQ: 1000 Units
-
Alkali and Acid Resistant Monel Woven Wire Mesh for Chemical Filtration ApplicationsUS$ 0.5MOQ: 1000 Units
-
Monel Fine Wire Mesh – High Precision Nickel-Copper Alloy Filter Mesh for FiltrationUS$ 0.5MOQ: 1000 Units
Anping County Boli Hardware Wiremesh Products Factory, established in 1998, is a professional manufacturer specializing in high-performance woven wire mesh. Our Alkali and Acid Resistant Monel Woven Wire Mesh is engineered for demanding chemical processing environments. Manufactured from premium Monel alloy (typically Monel 400 or K-500), this mesh offers exceptional resistance to both acidic and alkaline media, ensuring long service life in corrosive conditions. With over two decades of export experience and annual export value exceeding US$5 million, we deliver reliable filtration solutions to global markets including North America, Europe, Southeast Asia, and the Middle East.
Product Features & Technical Specifications
- Superior Corrosion Resistance: Monel alloy (Ni-Cu) withstands hydrofluoric acid, sulfuric acid, alkalis, and seawater, making it ideal for chemical processing, petrochemical, and pharmaceutical industries.
- High Temperature Stability: Operates reliably up to 600°C (1112°F) in oxidizing environments and up to 870°C (1600°F) in reducing conditions.
- Precise Mesh Opening: Available from 2 mesh to 400 mesh with strict tolerance control (opening deviation ±5% for standard meshes).
- Customizable Weave Patterns: Plain weave, twill weave, and Dutch weave (including reverse Dutch) for different filtration requirements.
- Uniform Strength: Monel wire provides tensile strength of 550–750 MPa, ensuring durability under mechanical stress.
- Chemical Resistance Table:
| Chemical Medium | Concentration | Temperature | Resistance Rating |
|---|---|---|---|
| Hydrochloric Acid (HCl) | Up to 20% | Room temp | Excellent |
| Sulfuric Acid (H₂SO₄) | Up to 80% | <60°C | Good |
| Sodium Hydroxide (NaOH) | All concentrations | Up to 100°C | Excellent |
| Hydrofluoric Acid (HF) | Up to 50% | Room temp | Excellent |
Key Benefits for Buyers: Our Monel wire mesh reduces downtime by resisting corrosion, and its customizable dimensions allow seamless integration into existing filtration systems. The mesh is available in roll form (up to 30m length) or cut sheets, with standard export packaging to ensure safe transit. We also offer optional annealing for improved ductility in forming applications.
Detailed Specifications
| Parameter | Value |
|---|---|
| Material Standard | Monel 400 (UNS N04400) or Monel K-500 |
| Density | 8.8 g/cm³ |
| Melting Point | 1300–1350°C |
| Tensile Strength (Wire) | 550–750 MPa (as woven) |
| Open Area | 30% – 70% depending on mesh count |
Frequently Asked Questions (FAQ)
-
Q1: What is the difference between Monel 400 and Monel K-500?
Monel 400 offers excellent general corrosion resistance, while K-500 provides higher strength through age-hardening. Both are suitable for chemical processing; we can supply either based on your application. -
Q2: Can you supply custom mesh sizes?
Yes, we offer custom mesh counts from 2 to 400 mesh, with wire diameters from 0.025 mm to 2.0 mm. Custom widths up to 2000 mm are available. -
Q3: How is the mesh packaged for export?
All rolls are wound on heavy-duty cores, wrapped in moisture-proof material, and packed in plywood cases or pallets to prevent damage during shipping. -
Q4: Can this mesh be used for high-temperature filtration?
Monel retains good mechanical properties up to 600°C in oxidizing atmospheres, making it suitable for hot gas filtration and catalyst recovery. -
Q5: What is the typical lead time?
Standard meshes (10–100 mesh) ship within 10–15 working days. Custom orders may require 20–25 working days depending on quantity. -
Q6: Do you provide samples?
Yes, we can send small samples (A4 size) for evaluation. Please contact us with your specific requirements. -
Q7: Is the mesh suitable for hydrochloric acid service?
Monel is widely used for handling dilute HCl at room temperature. For higher concentrations or elevated temperatures, we recommend consulting our technical team. -
Q8: Can you supply certificates of material?
Yes, we can provide mill test certificates per ASTM B127 or equivalent standards upon request.
Why Choose Anping Boli Wiremesh?
As a manufacturer with over 25 years of experience, our factory in Hengshui, Hebei, China, operates advanced weaving looms and quality control systems. Our annual export value of US$5–10 million reflects the trust of global buyers. We ship from major ports including Tianjin, Qingdao, Shanghai, and Foshan, serving markets across North America, South America, Europe, Africa, Oceania, and Asia. Our dedicated team ensures consistent quality, on-time delivery, and competitive pricing.
This Alkali and Acid Resistant Monel Woven Wire Mesh is a proven solution for chemical processing, filtration, and separation. Contact us today to discuss your specific requirements, request a quotation, or order samples. We are committed to providing durable, high-performance mesh that meets your exact needs.
