Help CenterMonel Fine Wire Mesh – High Precision Nickel-Copper Alloy Filter Mesh for Filtration
Product Spotlights
Related Products
-
Y Type Filter DIN F1 Flange Strainer With Stainless Steel Mesh for Pipeline FiltrationUS$ 0.5MOQ: 1000 Units -
Continuous Slot Wedge Wire Well Screen for Water Well and Filtration SystemsUS$ 0.5MOQ: 1000 Units
-
Monel Nickel Copper Alloy Wire Mesh for RFID Shielding and ScreeningUS$ 0.5MOQ: 1000 Units
-
100ft x 4ft Stainless Steel Wire Mesh Screen Sheet for Industrial Filtration Basket StrainerUS$ 0.5MOQ: 1000 Units
-
Monel 400 Wire Mesh Screen for EMI/RFI Shielding ApplicationsUS$ 0.5MOQ: 1000 Units
Founded in 1998, Anping County Boli Hardware Wiremesh Products Factory is a professional manufacturer specializing in high-quality wire mesh products. With an annual export value between US$5 million and US$10 million, we serve global markets across North America, Europe, Asia, and more. Our Monel Fine Wire Mesh – High Precision Nickel-Copper Alloy Filter Mesh is engineered to deliver exceptional filtration performance in demanding environments. Combining the unique properties of Monel alloy with precision weaving technology, this mesh offers superior corrosion resistance, mechanical strength, and thermal stability, making it an ideal choice for critical filtration applications.
Key Features & Technical Specifications
Our Monel fine wire mesh is produced using high-grade Monel 400 nickel-copper alloy wires, which provides excellent resistance to seawater, acidic gases, and alkalis. The precision weaving process ensures consistent aperture size and high filtration accuracy. Below are the main characteristics:
- Material Excellence: Monel 400 alloy (approx. 67% Ni, 23% Cu) – outstanding corrosion resistance in marine and chemical environments.
- High Precision Filtration: Available from 20 mesh (coarse) up to 500 mesh (ultra-fine), with aperture sizes as small as 10 microns.
- Strong & Durable: High tensile strength and good wear resistance, suitable for high-pressure filtration systems.
- Temperature Tolerance: Operational temperature range from -200°C to +500°C, maintaining structural integrity under thermal stress.
- Customizable Dimensions: Widths from 0.5m to 1.5m, rolls or cut sheets, with optional edge treatment (selvage, welded edges).
- Variety of Weaves: Plain weave, twill weave, Dutch weave (for high strength and fine filtration), and reverse Dutch weave.
| Mesh Count (per inch) | Wire Diameter (mm) | Aperture Size (μm) | Open Area (%) |
|---|---|---|---|
| 20 | 0.40 | 850 | 52 |
| 100 | 0.10 | 150 | 36 |
| 200 | 0.05 | 74 | 30 |
| 400 | 0.03 | 37 | 25 |
Advantages & Customer Benefits
Choosing our Monel fine wire mesh brings tangible benefits to your filtration processes:
- Extended Service Life: The corrosion-resistant Monel alloy significantly reduces downtime caused by mesh degradation, especially in acidic or chloride-rich environments.
- Consistent Filtration Efficiency: Precision weaving ensures uniform aperture size, preventing particle bypass and improving product quality.
- Reduced Maintenance Costs: High durability and easy cleaning (backwashing, ultrasonic) allow repeated use without frequent replacement.
- Versatile Application: Suitable for chemical processing, oil & gas filtration, pharmaceutical filtration, water treatment, aerospace fuel systems, and marine equipment.
- Customization Available: We can tailor mesh count, dimension, edge type, and even provide sintered multi-layer laminates for enhanced strength.
Why Choose Anping Boli?
With over 25 years of manufacturing experience, Anping County Boli Hardware Wiremesh Products Factory has established a reputation for quality and reliability. Our annual export value of US$5 million to US$10 million demonstrates our capability to serve international clients. We ship from major ports including Tianjin, Qingdao, Shanghai, and Foshan, ensuring timely delivery. Our main markets span across North America, South America, Europe, Asia, Africa, and Oceania, and we are dedicated to providing professional technical support and after-sales service. Each roll of Monel fine wire mesh undergoes strict quality control to ensure dimensional accuracy and consistent performance. We invite you to contact us for sample testing, custom specifications, or bulk orders. Experience the difference of precision-engineered filtration mesh from a trusted manufacturer.
Frequently Asked Questions
-
Q: What is the difference between Monel 400 and Monel K-500 mesh?
A: Monel 400 is the standard nickel-copper alloy with excellent corrosion resistance. Monel K-500 has additional aluminum and titanium for higher strength and hardness. We can supply both upon request; please specify your requirements. -
Q: Can this mesh be used for food-grade filtration?
A: Monel is not typically recommended for direct food contact unless specifically treated. For food applications, we recommend stainless steel mesh. Please consult our technical team for alternative materials. -
Q: What is the maximum temperature this mesh can withstand?
A: Monel 400 can operate continuously up to 500°C (932°F) in oxidizing conditions, and higher in reducing atmospheres. However, the exact limit depends on the application environment. We can provide detailed data sheets. -
Q: Do you offer custom mesh sizes and shapes?
A: Yes, we can customize mesh width, length, and even die-cut shapes (discs, squares, rectangles) for specific filter elements. Minimum order quantity may apply. -
Q: How is the mesh packaged for export?
A: We use standard export packaging: each roll wrapped in plastic film, then secured with kraft paper and wooden pallets or cartons, suitable for sea freight. Custom packaging is available upon request. -
Q: What is the lead time for a typical order?
A: For standard mesh sizes, lead time is usually 7–15 days after order confirmation. Custom orders may take 15–25 days, depending on complexity and quantity. -
Q: Can you provide samples before bulk order?
A: Yes, we offer free samples (you pay for shipping) for evaluation. Please contact us with your mesh specifications and quantity needed. -
Q: Is the mesh suitable for corrosive liquids like seawater or sulfuric acid?
A: Monel 400 has excellent resistance to seawater and many acids, including sulfuric acid (up to 80% concentration at moderate temperatures). For highly concentrated oxidizing acids, consider other materials. We can help you select the best alloy for your chemical environment.
