At Qingdao Conqinphi Environmental Technology Group Co., Ltd., we specialize in manufacturing high-quality industrial evaporation equipment. Our Electric Heating Rising Film Evaporator (220V, 304 Stainless Steel, 150L/h) is designed to deliver efficient and reliable concentration of liquid solutions in various industries. Build with precision and backed by decades of engineering expertise, this evaporator offers a compact yet powerful solution for your thermal separation processes.
The Rising Film Evaporator operates by heating the feed liquid from the bottom, causing it to rise as a thin film along the heated tubes. This design maximizes heat transfer surface area and minimizes residence time, ensuring gentle evaporation for sensitive products. With a capacity of 150 liters per hour, it is ideal for small to medium-scale production lines in the chemical, pharmaceutical, food and beverage, and environmental industries.
Key Features & Technical Specifications
- Electric Heating System: Clean, controllable, and easy to install – no need for steam boilers or external heat sources. Provides precise temperature control for consistent product quality.
- Construction Material: Full 304 Stainless Steel (SS304) – excellent corrosion resistance, hygienic, and compliant with food-grade and pharmaceutical standards. Suitable for a wide range of feed materials.
- High Evaporation Capacity: 150 L/h – efficient for concentrating solutions, recovering solvents, or reducing waste volume.
- Compact Footprint: Space-saving design, ideal for laboratories, pilot plants, or small production workshops.
- Easy Operation & Maintenance: Simple startup, automatic controls available, and easy access for cleaning and inspection.
- Customizable Options: Available with different control systems, additional accessories (e.g., condensers, vacuum pumps, feed pumps), and tailored to specific process requirements.
| Parameter | Specification |
| Heating Method | Electric (220V, 50/60Hz) |
| Material of Construction | 304 Stainless Steel |
| Evaporation Capacity | 150 L/h |
| Operating Temperature | Up to 120°C (customizable) |
| Working Pressure | Atmospheric / Vacuum (optional) |
| Control System | Manual / PLC (optional) |
| Dimensions (L×W×H) | Customizable based on design |
| Weight | Approx. 200 kg (varies) |
Product Advantages & Benefits
- Energy Efficiency: Electric heating directly transfers energy to the process, reducing heat loss compared to indirect steam systems. Lower operating costs over time.
- Product Quality: The rising film mechanism ensures short contact time and low thermal degradation, preserving the flavor, color, and active ingredients of heat-sensitive liquids.
- Versatility: Handles a wide range of viscosities and solids content. Suitable for aqueous solutions, organic solvents, and even some slurries.
- Hygienic Design: 304 SS with smooth surfaces, no dead zones, easy to clean (CIP compatible). Meets strict sanitary requirements for food and pharmaceutical applications.
- Reliability: Manufactured in our 10,000-30,000 m² factory with strict quality control procedures. Each unit is tested before shipment.
- Global Support: We export to over 20 countries and regions, with spare parts available and technical support from our experienced team.
Trusted by industries worldwide: Our company, established in 2015, has grown to a team of 201-300 employees and an annual export value of US$10-50 million. We hold certifications including ISO9001, ISO14000, OHSAS18001, HACCP, SA8000 and many others, demonstrating our commitment to quality, environment, safety, and social responsibility. Our factory is located in Qingdao, Shandong, China – a major port city, ensuring convenient logistics and fast delivery.
We understand that investing in process equipment is a long-term decision. That's why we offer comprehensive after-sales support, including installation guidance, operation training, and maintenance advice. Our evaporators are designed for durability and easy servicing, with readily available replacement parts. Whether you need a standard unit or a customized solution, our engineering team is ready to discuss your requirements.
Contact us today for a quotation or technical consultation. Let Qingdao Conqinphi be your partner in efficient evaporation technology.
Frequently Asked Questions (FAQ)
-
What is the typical energy consumption of this evaporator?
The power consumption depends on the heating demand and the feed properties. At full capacity, the electric heating elements are rated around 12-18 kW (220V). Actual consumption varies with process conditions. We can provide detailed estimates based on your specific application. -
Can this evaporator handle viscous liquids?
Yes, the rising film design is effective for moderate viscosities. For highly viscous materials, a falling film or forced circulation evaporator might be more suitable. We recommend consulting our engineers for a proper evaluation. -
What is the maximum operating temperature?
The standard design allows temperatures up to 120°C. Higher temperatures are possible with optional modifications (e.g., higher temperature gaskets, pressure rating). -
Is vacuum operation possible?
Yes, the evaporator can be configured for vacuum operation to lower boiling points, which is beneficial for heat-sensitive materials. Please specify when ordering. -
What certifications does the product have?
Our manufacturing facility is certified under ISO9001, ISO14000, OHSAS18001, and others. The evaporator itself is designed to meet common industry standards. Specific certifications (e.g., CE, ASME) can be arranged upon request at additional cost. -
How long is the delivery time?
For standard models, delivery is typically 30-45 days after order confirmation. Customized units may take 45-60 days depending on complexity. We ship from Qingdao port. -
What is the warranty period?
We offer a standard 12-month warranty covering manufacturing defects. Extended warranty options are available. -
Can I get a sample or visit the factory?
Yes, we welcome factory visits and can arrange test runs with your materials. Please contact our sales team to schedule.
