1. Product Overview
Recreational water dedicated low concentration sodium hypochlorite generator is special mild disinfection equipment for human contact water environments such as swimming pools and hot springs. Recreational water is directly exposed to human skin; traditional chlorine tablets and commercial bleach easily cause excessive residual chlorine, skin itching and pungent odor, and stored disinfectants will decompose and lose efficacy. This equipment adopts low-dose constant electrolysis technology to continuously generate mild low-titer sodium hypochlorite solution, which quickly eliminates pathogenic bacteria, mold and algae in circulating water, keeps water clear and odorless, and fully complies with international swimming pool water health standards. The whole machine supports small and medium flow matching, optional wall-mounted and integrated skid-mounted structures, low noise operation, suitable for commercial resorts, community swimming pools, indoor constant-temperature hot spring halls and scenic artificial landscape water bodies.
2. Technical Principle
The system adopts food-grade dilute brine low-energy constant-current electrolysis process. Edible refined salt and softened clean water are automatically stirred and filtered to form 2.8% low-impurity dilute brine. The qualified brine flows into sanitary MMO titanium electrolytic cells, and stable low-voltage DC electrolysis produces 0.5%-0.8% low-concentration sodium hypochlorite. The fresh disinfectant is quantitatively injected into the circulating pipeline of pool water. Mild active chlorine destroys microbial cell walls to achieve sterilization and algae removal, and naturally decomposes rapidly in water without long-term residual stimulation to human body. The PLC control system is connected with online residual chlorine sensor, automatically increasing or reducing electrolysis power to stabilize residual chlorine between 0.3-1.0mg/L. Trace hydrogen generated by electrolysis is safely diluted and discharged through negative pressure closed pipeline to avoid gas accumulation in indoor equipment room.
3. Main Features
Skin-Friendly Mild Disinfectant Output: 0.5%-0.8% low available chlorine concentration, no eye irritation, no skin itching for swimmers
Residual Chlorine Automatic Interlock Regulation: Real-time water quality monitoring, automatic adjustment of chlorine production to avoid chlorine excess or insufficient sterilization
Optional Wall-Mounted Compact Structure: Small footprint, suitable for small swimming pool narrow equipment room installation
Low Noise Indoor Operation Design: Optimized water pump and electrolysis structure, no harsh noise to disturb leisure area
Automatic Backwashing Brine Filter: Prevent electrode scaling caused by salt impurities, extend electrolytic cell service life
4. Core Advantages
Improve Visitor Experience: No pungent chlorine odor, solve skin allergy problems caused by traditional chlorine tablet disinfection
Zero Chemical Storage Safety Risks: Only store edible salt, cancel bleach and chlorine tablet storage warehouse, reduce resort safety management pressure
Stable Long-Term Water Clarity: Continuous algae inhibition, reduce pool water replacement frequency and water consumption cost
Low Daily Operating Expense: Only consume salt and electricity, save recurring procurement cost of chlorine tablets and liquid bleach
Remote Mobile Monitoring Function: Support hotel/resort central control platform access, real-time viewing of water disinfection status
5. Core Components
Sanitary Anti-Corrosion MMO Titanium Electrolytic Cell: Food-grade coating, no heavy metal precipitation, produce mild hypochlorite for human contact water
Low Noise Energy-Saving Constant Current Rectifier: Stable low-power DC output, adapt to 24h continuous circulation of pool water
Automatic Food-Grade Brine Preparation & Precision Filtration Unit: Remove salt impurities to guarantee pure disinfectant liquid
Residual Chlorine Linked PLC Intelligent Control Cabinet: Automatically adjust output according to real-time pool water quality data
-
Micro Quantitative Anti-Corrosion Dosing Pump Assembly: Uniformly distribute hypochlorite into circulating water pipeline for balanced disinfection
6. Application Fields
Indoor constant temperature swimming pool circulating water disinfection, hot spring resort bath water sterilization, large water park wave pool water treatment, community artificial lake landscape algae control, hotel villa private swimming pool water maintenance
Boasting 25 years of professional industry experience in production and supply, BLUEWAV factory delivers premium,cost-effective chemical products with reliable quality. Equipped with fully automatic production systems and scientific modular production line design, we achieve stable output, high efficiency and low energy consumption while strictly complying with industrial standards. Different from ordinary manufacturers, BLUEWAV provides flexible customized services tailored to diverse customer needs on product specifications, packaging and solutions. With direct factory pricing and optimized production processes, we help clients cut procurement costs and obtain high-quality, stable chemical supplies with comprehensive professional support.
