1 Product Overview
The low concentration sodium hypochlorite generator is a new generation of safe and eco-friendly on-site water disinfection equipment, specially developed for scenarios requiring mild, standardized and non-irritating disinfection treatment. Based on saturated brine electrolysis technology, the equipment uses refined salt and tap water as raw materials to continuously produce low-concentration sodium hypochlorite solution through electrochemical reaction, with the effective chlorine concentration stably maintained in the safe and applicable range.
Compared with traditional disinfection methods such as liquid chlorine dosing and high-concentration hypochlorite disinfection, this equipment eliminates hidden dangers including chemical leakage, residual chlorine exceeding the standard and corrosive damage to pipeline equipment. The low-concentration disinfectant produced by the machine has mild oxidation performance, strong sterilization and algae removal capabilities, and can be naturally decomposed after water treatment without producing harmful by-products. With compact structure, fully automatic unattended operation and low operating cost, it is a mainstream compliant disinfection equipment for municipal water supply, environmental protection sewage treatment and civil water purification projects worldwide.
2 Technical Principle
The equipment adopts normal-temperature brine electrolysis electrochemical principle, with refined salt dissolved in tap water to form dilute brine as the only reaction raw material. After precise filtration and flow regulation, the brine is sent to the professional electrolytic cell. Under the action of stable direct current provided by the rectifier, electrolytic oxidation-reduction reaction occurs in the electrode gap.
During the electrolysis process, chloride ions in the brine are oxidized to produce chlorine gas, which fully reacts with water in the electrolytic cell to generate low-concentration sodium hypochlorite disinfectant. The whole reaction process is stable and controllable, and the system intelligently adjusts electrolytic current and brine feeding volume according to water demand, so as to ensure the output of low-concentration NaClO solution is always within the safe and effective range. A small amount of hydrogen produced in the reaction is safely discharged through a closed exhaust system to ensure zero safety risk. The entire production process requires no chemical additives, realizing pure physical electrolysis green disinfection.
3 Main Features
(1) Safe Low-Concentration Output, No Excessive Residue: The equipment precisely controls the electrolysis reaction efficiency, and the produced sodium hypochlorite solution is low in concentration, mild and non-corrosive. It effectively avoids pipeline corrosion, water quality secondary pollution and excessive residual chlorine, fully meeting civil and industrial water disinfection safety standards.
(2) On-Site Real-Time Preparation, Zero Chemical Storage Risk: It adopts on-demand electrolysis and real-time dosing mode, without purchasing and storing high-risk liquid chlorine, high-concentration hypochlorite and other hazardous chemicals. It completely eliminates safety hazards such as chemical leakage and explosion during storage and transportation.
(3) Full Intelligent Automatic Operation: Equipped with high-precision PLC intelligent control system, the equipment realizes automatic brine proportioning, automatic electrolysis, automatic dosing and automatic shutdown. It supports 24-hour unattended operation, with real-time fault self-inspection and alarm functions, reducing manual operation costs.
(4) Energy-Saving and Low Consumption, Low Operating Cost: Optimized electrolytic cell electrode structure and power supply system improve electrolysis conversion rate, reduce invalid energy consumption. The raw materials are only refined salt and tap water, with extremely low daily operating cost, far lower than traditional chemical dosing disinfection.
(5) Green Environmental Protection, Zero Secondary Pollution: The low-concentration sodium hypochlorite disinfectant has strong sterilization effect and good degradability. It can be automatically decomposed after completing water disinfection, no harmful disinfection by-products are generated, which is in line with international environmental protection and water quality safety regulations.
(6) Compact Modular Design, Easy Installation: The whole machine adopts integrated skid-mounted structure, small floor area, simple on-site installation and commissioning. It can be quickly put into use after connecting water and power supply, suitable for various limited installation spaces.
4 Core Advantages
(1) Precise Concentration Control, Wide Safety Margin: Different from traditional high-concentration hypochlorite generators that are prone to excessive concentration, this equipment supports stepless adjustment of disinfectant concentration. The low-concentration stable output ensures uniform disinfection effect, avoids local excessive oxidation and water quality damage, and is more suitable for long-term continuous water treatment.
(2) Ultra-Low Operation and Maintenance Cost: The equipment has high electrolysis efficiency and low power consumption, and the raw material cost of refined salt is extremely low. The core electrode has long service life, no frequent replacement and no regular cleaning and maintenance, which greatly reduces the full-cycle operation and maintenance cost of the water treatment system.
(3) Strong Sterilization and Antifouling Ability: Although the disinfectant concentration is low, the active chlorine components are stable and uniform, which can effectively kill E. coli, bacteria, viruses and algae in water, inhibit microbial reproduction and biofilm formation in pipelines, and ensure long-term clean water quality and smooth pipeline operation.
(4) Strong System Compatibility: The equipment can be seamlessly connected with municipal water supply systems, sewage treatment equipment, swimming pool water circulation systems and industrial cooling water systems. It supports automatic linkage operation with host equipment, with high compatibility and easy system integration.
(5) Multi-Dimensional Safety Protection: Built-in hydrogen exhaust protection, over-current and over-voltage protection, water shortage protection, pipeline pressure protection and fault interlock shutdown function. The whole machine operates safely and stably, with zero safety accidents in long-term industrial operation.
5 Core Components
(1) High-Efficiency DSA Electrolytic Cell (Core Component): Made of titanium alloy substrate and coated with ruthenium-iridium DSA noble metal coating, it has excellent corrosion resistance and electrolysis activity. It ensures uniform electrolysis reaction, stable low-concentration disinfectant output, long service life and no scaling blockage.
(2) Intelligent PLC Control Cabinet: The core control unit of the equipment, integrating parameter setting, automatic operation, data monitoring, fault alarm and remote transmission functions. It accurately controls brine flow and electrolytic power to stabilize disinfectant concentration.
(3) High-Precision Brine Proportioning Module: Consists of salt dissolving tank, filter and flow stabilizer, which realizes automatic quantitative salt dissolving and brine purification, ensures stable brine concentration entering the electrolytic cell, and avoids reaction fluctuation.
(4) Intelligent Rectifier Power Supply: Converts industrial alternating current into stable low-voltage direct current, resists grid voltage fluctuation, ensures constant electrolysis power, improves electrolysis efficiency and reduces energy consumption loss.
(5) Automatic Dosing & Residual Chlorine Monitoring Module: Equipped with precision dosing pump and online residual chlorine sensor, it monitors water residual chlorine data in real time, dynamically adjusts dosing volume, ensures standardized water quality and avoids disinfection excess or deficiency.
(6) Closed Hydrogen Exhaust System: Special negative pressure exhaust device safely discharges trace hydrogen generated by electrolysis, prevents gas accumulation in the equipment cabin, and ensures safe indoor and outdoor operation of the equipment.
(1) Municipal Tap Water Supply Project: Suitable for disinfection and sterilization of urban water plants, community secondary water supply and rural centralized water supply, ensuring tap water meets national and international drinking water safety standards.
6 Application Fields
(2) Domestic Sewage Treatment: Used for terminal disinfection of urban domestic sewage and community sewage, killing pathogenic microorganisms in effluent water and ensuring compliant discharge of treated sewage.
(3) Swimming Pool & Leisure Water Scenarios: Applied to circulating water disinfection of swimming pools, hot spring water and scenic water bodies. Low-concentration disinfection is non-irritating to human body and skin, with uniform and safe sterilization effect.
(4) Industrial Circulating Water Treatment: Used for sterilization and algae removal of industrial cooling circulating water, preventing pipeline biofouling and scaling, improving heat exchange efficiency and extending the service life of industrial equipment.
(5) Food & Beverage Factory Water Treatment: Suitable for production water disinfection and workshop domestic water sterilization in food, beverage and dairy factories, meeting high-standard food-grade water safety requirements.
(6) Remote & Emergency Water Supply: The miniaturized and modular equipment is suitable for emergency water disinfection in remote mountainous areas, construction sites and disaster relief scenarios, with flexible deployment and stable performance.
Boasting 25 years of professional industry experience in production and supply, Chlory factory delivers premium,cost-effective chemical products with reliable quality. Equipped with fully automatic production systems and scientific modular production line design, we achieve stable output, high efficiency and low energy consumption while strictly complying with industrial standards. Different from ordinary manufacturers, Chlory provides flexible customized services tailored to diverse customer needs on product specifications, packaging and solutions. With direct factory pricing and optimized production processes, we help clients cut procurement costs and obtain high-quality, stable chemical supplies with comprehensive professional support.
