As a leading manufacturer with over 25 years of experience, Anping County Boli Hardware Wiremesh Products Factory proudly presents our Standard Compliant Polyester Dryer Mesh Belt in 1.6m width. This high-performance belt is engineered to meet the rigorous demands of industrial drying applications, ensuring consistent airflow, efficient moisture removal, and long-lasting durability. With our dedicated technical support included for installation, you can integrate this belt into your existing system with confidence and ease.
Our polyester dryer mesh belt is constructed from premium polyester monofilament yarns, offering excellent heat resistance, low elongation, and superior dimensional stability. The open mesh structure allows for optimal air circulation, which accelerates drying times and reduces energy consumption. Whether you are drying paper, textiles, food products, or chemicals, this belt delivers reliable performance under continuous operation.
Key Features & Technical Specifications
- Material: 100% Polyester monofilament – resistant to rot, mildew, and most chemicals.
- Width: Standard 1.6m (custom widths available upon request).
- Weave Patterns: Plain weave, twill weave, or spiral weave options to suit different drying requirements.
- Temperature Range: Suitable for continuous use up to 150°C (peak 180°C for short periods).
- Tensile Strength: High tensile strength with low stretch – ensures stable operation over long periods.
- Mesh Open Area: Typically 30%–60% depending on weave, enabling efficient air and water permeability.
- Seam Type: Available with pin seam, spiral seam, or endless (no seam) for easy installation and maintenance.
- Color: Standard green, blue, or white; other colors customizable.
| Parameter | Value |
|---|---|
| Material Composition | 100% Polyester |
| Standard Width | 1.6m (63 inches) |
| Thickness | 2.0 – 4.5 mm (depending on weave) |
| Maximum Operating Temperature | 150°C continuous |
| Tensile Strength (Warp) | ≥ 800 N/cm |
| Air Permeability | 2000 – 6000 m³/m²/h at 200 Pa |
| Seam Type Options | Pin, Spiral, Endless |
Advantages for Your Business
- Energy Savings: The open mesh design reduces air resistance, allowing lower fan speeds and cutting energy costs by up to 20%.
- Extended Service Life: Polyester material resists hydrolysis, abrasion, and edge fraying, minimizing downtime and replacement frequency.
- Easy Installation: With our included technical support, your team receives on-site guidance or remote assistance for proper fitting and tensioning.
- Versatile Applications: Suitable for paper machines, textile dryers, food dehydrators, pulp dryers, and nonwoven fabric lines.
- Compliance Assurance: Our belts are manufactured to meet international standards for dimensional tolerance and performance, ensuring compatibility with most OEM equipment.
We understand that every drying process has unique requirements. That is why we offer customization in length, mesh count, edge reinforcement (selvedge), and connector type. Our engineers work closely with you to design a belt that optimizes your production efficiency.
Trusted by Global Industries
Since 1998, Anping County Boli Hardware Wiremesh Products Factory has been a reliable partner for industrial mesh solutions. Our annual export value exceeds US$5 million, with shipments to over 20 countries including North America, Europe, Southeast Asia, and Oceania. We are experienced in international logistics, shipping from major ports like Tianjin, Qingdao, Shanghai, and Foshan. Our factory is located in the renowned wire mesh industrial cluster of Anping, Hebei, giving us access to top-quality raw materials and skilled craftsmanship.
We stand behind every product we deliver. Each dryer mesh belt undergoes strict quality checks – including tensile strength tests, dimensional accuracy verification, and visual inspection – before packing. Our dedicated after-sales team provides prompt technical support, and we offer spare parts and replacement belts at competitive prices.
Contact us today to discuss your specific drying needs. We are ready to provide samples, technical drawings, or a customized quotation. Let Boli Wiremesh help you improve your drying efficiency and product quality.
Frequently Asked Questions
-
What is the standard width of this dryer mesh belt?
Our standard width is 1.6m, but we can produce custom widths from 0.5m to 3m or more. Please specify your requirement. -
Can this polyester belt be used for high-temperature drying above 150°C?
For continuous operation, 150°C is the recommended maximum. For short peaks up to 180°C, it can be used, but we advise consulting our engineers for application-specific advice. -
Does the belt come with a seam? Which type do you recommend?
We offer pin seam, spiral seam, and endless options. For most industrial dryers, a pin seam provides easy installation and replacement. Endless belts are preferred for high-speed or sensitive applications. -
How do I clean the polyester mesh belt?
Cleaning can be done with low-pressure water or mild detergent. Avoid harsh chemicals or high-pressure washing that may damage the fibers. Our technical support team can provide detailed cleaning guidelines. -
What is the delivery time for a 1.6m belt?
Typical lead time is 15–25 working days, depending on quantity and customization. We can expedite urgent orders upon request. -
Is technical support included in the price?
Yes, we provide installation guidance and technical support via phone, email, or video call. On-site support may be available for large orders with additional charges. -
Can you provide a sample before bulk order?
Absolutely. We can send a small sample (e.g., 30cm x 30cm) for testing. Please contact us to arrange shipping. -
What are the main markets for your dryer mesh belts?
Our belts are used in paper mills, textile factories, food processing plants, and chemical dryers worldwide. We export to North America, Europe, Asia, and Africa.
