Welcome to Anping Xinye Metal Wire Mesh Products Co., Ltd, a trusted manufacturer based in Hengshui, Hebei, China. Our 160 GSM Heat Insulation Fiberglass Mesh Material is engineered to deliver exceptional thermal protection in demanding environments. This high-density mesh combines superior heat resistance with mechanical strength, making it an ideal solution for building insulation, industrial equipment, and fireproofing applications. With a focus on quality and performance, our product helps you achieve energy efficiency and safety without compromise.
The 160 GSM fiberglass mesh is constructed from alkali-resistant glass fibers, coated with a specially formulated acrylic or silicone layer to enhance its durability and thermal stability. It offers reliable performance at temperatures up to 550°C, ensuring long-term protection in high-heat zones. The mesh is lightweight, flexible, and easy to cut, allowing for quick installation on walls, pipes, and ducts. Its open weave structure provides excellent adhesion for coatings and plasters, while the consistent density ensures uniform insulation across the entire surface.
Key Features and Specifications:
- High Density (160 GSM) – Provides enhanced thermal barrier and dimensional stability.
- Temperature Resistance – Withstands continuous exposure up to 550°C, with peak tolerance up to 600°C.
- Alkali Resistance – Suitable for use with cement, lime, and other alkaline materials without degradation.
- Flexible & Easy to Handle – Can be cut, folded, and shaped to fit irregular surfaces.
- Multiple Coating Options – Available with acrylic or silicone coating to suit specific application requirements.
- Standard Sizes – Commonly supplied in rolls of 1m width × 50m length; custom dimensions available upon request.
| Parameter | Value |
| Weight | 160 g/m² |
| Mesh Opening | 5×5 mm (standard), other sizes available |
| Tensile Strength (Warp) | ≥1200 N/50mm |
| Tensile Strength (Weft) | ≥1000 N/50mm |
| Temperature Range | -50°C to 550°C |
| Coating Content | 20%–25% (acrylic or silicone) |
| Roll Width | 1 m (customizable) |
| Roll Length | 50 m (customizable) |
Benefits for Your Projects: By incorporating this 160 GSM insulation mesh, you can significantly reduce heat transfer, lowering energy costs for heating and cooling systems. Its robust construction prevents cracking and deformation under thermal stress, extending the lifespan of insulation layers. The mesh also acts as a reinforcement for exterior insulation finishing systems (EIFS) and fireproof cladding, enhancing overall building safety. For industrial applications, it protects pipelines and equipment from radiant heat, minimizing maintenance downtime.
At Anping Xinye Metal Wire Mesh Products Co., Ltd, we have been manufacturing wire mesh products for over a decade. Our factory in Hengshui, Hebei, is equipped with advanced weaving and coating lines, ensuring consistent quality and timely delivery. We have supplied insulation mesh to numerous projects across China and abroad, earning a reputation for reliability and customer service. Every roll is inspected for weight, mesh opening, and tensile strength before shipment. We offer flexible packaging options and can provide samples for evaluation. Choose our 160 GSM fiberglass mesh for your thermal protection needs and experience the difference of professional-grade material. Contact us today for a quote or technical consultation.
Frequently Asked Questions (FAQ):
Q1: What is the maximum temperature this mesh can withstand?
A: The mesh can withstand continuous temperatures up to 550°C, with short-term peaks up to 600°C. Always verify the specific temperature requirements of your application.
Q2: Is this mesh suitable for outdoor use?
A: Yes, the acrylic or silicone coating provides UV resistance and weather protection, making it suitable for exterior insulation systems. However, for prolonged direct sun exposure, we recommend using a silicone-coated version for better UV stability.
Q3: Can I cut the mesh to custom sizes?
A: Absolutely. The mesh can be easily cut with scissors or a utility knife. We also offer custom roll widths and lengths upon request. Please contact us with your dimensions.
Q4: How does this mesh compare to lower GSM alternatives?
A: The 160 GSM density provides higher strength and a more effective thermal barrier compared to lighter meshes (e.g., 100 GSM). It is ideal for applications where load-bearing or high insulation performance is required.
Q5: Are there any special installation requirements?
A: The mesh should be embedded in the mortar or adhesive layer during installation. Ensure the surface is clean and dry. Overlap joints by at least 10 cm to maintain continuity. Refer to your system manufacturer’s guidelines for best practices.
Q6: Is the mesh environmentally friendly?
A: Fiberglass is an inert material and does not release harmful substances under normal use. Our manufacturing process follows standard environmental regulations. The mesh is non-toxic and can be recycled as part of construction waste.
Q7: Do you provide samples before bulk order?
A: Yes, we offer free samples (shipping cost may apply) for evaluation. Please send us your request, and we will arrange a sample roll of 1 m² size.
Q8: What is the typical lead time?
A: For standard sizes, lead time is 7–10 working days after order confirmation. For custom specifications, please allow 15–20 working days. We can expedite for urgent orders subject to availability.
