As a leading manufacturer with over 25 years of experience, Anping County Boli Hardware Wiremesh Products Factory presents our Industrial Filter with Edge-Wrapped Screen. Designed for demanding applications, this filter delivers 0.1mm precision filtration while withstanding extreme pressures up to 250 Bar and temperatures ranging from -20°C to 200°C. Our factory, established in 1998, exports to global markets including North America, Europe, and Southeast Asia, ensuring consistent quality and reliability.
Key Features & Technical Specifications
- Edge-Wrapped Screen Design – Uses wedge wire wrapped around a support core, providing a robust, self-cleaning surface ideal for high-flow and high-viscosity fluids.
- High Precision Filtration – Exact 0.1mm (100 micron) gap ensures removal of particles down to 100 microns, protecting downstream equipment from wear.
- Extreme Pressure Rating – Rated for 250 Bar (3625 PSI), suitable for hydraulic systems, oil & gas, and high-pressure fluid lines.
- Wide Temperature Tolerance – Operates reliably from -20°C to 200°C, covering both cold climates and hot process fluids.
- Durable Construction – Available in stainless steel (304/316) or carbon steel, with end caps and connections customized to your requirements.
- Easy Maintenance – The edge-wrapped element can be cleaned manually or backwashed, extending service life and reducing replacement costs.
| Parameter | Value |
|---|---|
| Filtration Grade | 0.1 mm (100 μm) |
| Max Working Pressure | 250 Bar (25 MPa) |
| Operating Temperature | -20°C to +200°C |
| Body Material Options | 304/316 Stainless Steel, Carbon Steel |
| Connection Type | Threaded (NPT/BSP), Flanged, Custom |
| Element Length | Standard 10", 20", 30", or custom sizes |
Why Choose Our Edge-Wrapped Industrial Filter?
The edge-wrapped screen technology offers several advantages over traditional mesh or sintered filters:
- Higher Flow Capacity – The wedge wire profile creates a larger open area, allowing higher flow rates with minimal pressure drop.
- Resistance to Clogging – The V-shaped slots prevent particles from wedging, making the filter easy to clean and reuse.
- Mechanical Strength – The self-supporting structure withstands high differential pressure without deforming.
- Customizable Gap – We can adjust the slot width from 0.05mm to 1mm according to your specific filtration needs.
- Broad Application – Ideal for hydraulic oil, lubricating oil, water treatment, chemical processing, gas filtration, and more.
Trust & Reliability from a Proven Manufacturer
Anping County Boli Hardware Wiremesh Products Factory has been a trusted name in the filtration industry since 1998. With an annual export value of US$5–10 million, we ship through major ports including Tianjin, Qingdao, Shanghai, and Foshan to customers across North America, South America, Europe, Asia, and Africa. Our factory is located in Hengshui, Hebei – the renowned wire mesh capital of China. We provide OEM/ODM services, strict quality control, and flexible customization to meet your exact specifications. Whether you need a standard size or a custom design, we are ready to support your project with competitive pricing and timely delivery. Contact us today for a quote or technical consultation.
Frequently Asked Questions (FAQ)
Q1: What is the exact filtration precision of this filter?
A: The standard precision is 0.1mm (100 microns). However, we can customize the gap from 0.05mm to 1.0mm to suit different particle sizes.
Q2: Can this filter be used with water or aggressive chemicals?
A: Yes, when made of stainless steel (304/316), it is suitable for water, oil, and many chemicals. For highly corrosive media, we recommend 316L or Hastelloy – please consult our sales team.
Q3: How do I clean the edge-wrapped screen?
A: The element can be cleaned by backwashing, ultrasonic cleaning, or manual brushing. The robust design allows repeated cleaning without damage.
Q4: What is the maximum differential pressure before the element collapses?
A: The collapse pressure varies with length and material, but typically exceeds 80 Bar. For exact values, please provide your specific requirements.
Q5: Do you offer flanged connections?
A: Yes, we can supply threaded (NPT/BSP) or flanged connections (ANSI/DIN) as per your request. Custom ends are also available.
Q6: What is the minimum order quantity (MOQ)?
A: For standard sizes, MOQ is 10 pieces. For custom designs, MOQ may be higher – please contact us for details.
Q7: What certifications do you hold?
A: Our factory operates under strict quality management systems. Specific certifications (e.g., ISO) can be provided upon request – please inquire for your target market.
Q8: How long does shipping take to North America?
A: Typical lead time is 15–25 working days after order confirmation. We ship from Tianjin or Qingdao ports, with sea freight to the US taking about 25–30 days.
