Help CenterEdge-Wrapped Filter Screen, 316L Stainless Steel, 100 Micron, 500mm x 500mm, 20 Bar, Sanitary Tri-Clamp Connection
Product Spotlights
Related Products
-
Edge-Wrapped Filter Screen for Industrial Filtration, 20 Mesh, 304 Stainless Steel, 0.5m x 1m, High Temperature Resistant up to 400°CUS$ 0.28 - 0.3MOQ: 1 Piece -
304 Stainless Steel Edge-Wrapped Filter Screen for Pharmaceutical Filtration, 100 Mesh, Smooth Surface, Easy Cleaning, Sanitary DesignUS$ 0.28 - 0.3MOQ: 1 Piece
-
Industrial Edge-Wrapped Filter Screen, 304 SS, 200 Micron, 1000mm x 1000mm, 5 Bar, Welded Wire MeshUS$ 0.28 - 0.3MOQ: 1 Piece
-
Edge-Wrapped Filter Screen, 304 SS, 200 Mesh, 600mm x 900mm, Free Technical Support, Fast Delivery Within 15 DaysUS$ 0.28 - 0.3MOQ: 1 Piece
-
Industrial Edge-Wrapped Filter Screen, 304L Stainless Steel, 10 Bar Pressure Rating, 0.2mm Slot WidthUS$ 0.28 - 0.3MOQ: 1 Piece
Anping County Boli Hardware Wiremesh Products Factory (established 1998) presents our premium Edge-Wrapped Filter Screen made from 316L stainless steel with 100 micron precision, measuring 500mm x 500mm and rated for 20 Bar pressure. Designed for sanitary applications, this filter screen features a Tri-Clamp connection for easy installation and maintenance. Our factory has been a trusted manufacturer for over two decades, exporting to global markets including North America, Europe, and Southeast Asia, with annual export value between US$5 million and US$10 million.
This edge-wrapped filter screen is engineered to provide optimal filtration performance in demanding environments. The 316L stainless steel construction ensures excellent corrosion resistance and durability, while the 100 micron mesh effectively captures particles while maintaining high flow rates. The 500mm x 500mm size is versatile for various filtration systems, and the 20 Bar pressure rating makes it suitable for high-pressure applications.
Key Features & Benefits:
- Edge-Wrapped Design: Prevents fraying and extends service life, ensuring consistent filtration performance.
- 316L Stainless Steel: Superior resistance to corrosion, pitting, and chemical attack, ideal for hygienic environments.
- 100 Micron (0.1mm) Mesh: Fine filtration suitable for removing particles while allowing high throughput.
- 500mm x 500mm Panel: Large surface area reduces pressure drop and increases dirt-holding capacity.
- 20 Bar Pressure Rating: Suitable for high-pressure systems up to 290 psi.
- Sanitary Tri-Clamp Connection: Quick disconnect, easy to clean, meets 3-A and FDA standards for food/ pharmaceutical use.
- Electropolished Surface (optional): Reduces roughness, improves cleanability, and minimizes bacterial growth.
- Customizable Options: Micron sizes from 10 to 2000 micron, dimensions up to 1000mm x 1000mm, and various edge styles available upon request.
Technical Specifications:
| Parameter | Value |
| Material | 316L Stainless Steel |
| Mesh Opening | 100 Micron (0.1 mm) |
| Panel Size | 500mm x 500mm |
| Maximum Operating Pressure | 20 Bar (290 psi) |
| Connection Type | Sanitary Tri-Clamp 1.5" or 2" (customizable) |
| Edge Type | Edge-Wrapped (rolled edge) |
| Surface Finish | Standard: 320 grit; Electropolish optional |
| Operating Temperature | -20°C to 200°C |
Applications:
This filter screen is widely used in food and beverage processing (beer, wine, juice, dairy), pharmaceutical manufacturing (sterile filtration), chemical processing, water treatment, and oil & gas where sanitary conditions and high pressure are required. The Tri-Clamp connection allows for quick installation in existing piping systems.
Why Choose Anping County Boli Hardware Wiremesh Products Factory?
- Over 25 years of manufacturing experience (since 1998).
- Annual export value of US$5-10 million, serving global markets including North America, Europe, Asia, and Africa.
- Located in Hengshui, Hebei – the wire mesh capital of China, ensuring access to high-quality raw materials.
- We offer custom sizes, micron ratings, and edge styles to meet your specific requirements.
- Each product is inspected for dimensional accuracy, mesh integrity, and pressure rating before shipment.
- We can ship from major ports: Tianjin, Qingdao, Shanghai, Foshan.
Frequently Asked Questions (FAQ):
1. What is the difference between edge-wrapped and welded filter screens?
Edge-wrapped screens have the mesh edges folded over a frame and secured, preventing fraying and providing a smooth edge. Welded screens are joined by spot welding, which can be less flexible. Edge-wrapped design is preferred for sanitary applications because it eliminates crevices where bacteria can hide.
2. Can I use this filter screen for CIP (Clean-in-Place) systems?
Yes, the 316L stainless steel and electropolished surface option make it suitable for CIP procedures. The Tri-Clamp connection allows easy removal for cleaning.
3. What is the maximum temperature this filter can withstand?
The standard operating temperature range is -20°C to 200°C. For higher temperature applications, please consult our engineering team for custom solutions.
4. Do you offer other micron sizes?
Yes, we can manufacture micron ratings from 10 to 2000 micron. Please specify your requirement when ordering.
5. Is this product certified for food contact?
Our 316L stainless steel material is FDA-compliant and suitable for food contact. We can provide material certificates upon request. Note: specific certifications like 3-A or EHEDG are available as optional extra services.
6. What is the lead time for standard sizes?
Standard sizes (500mm x 500mm, 100 micron) are typically in stock and ship within 7-10 days after order confirmation. Custom orders may take 15-25 days.
7. Can I get a sample before bulk order?
Yes, we offer samples for evaluation. Please contact our sales team to arrange a sample order with shipping charges.
8. How do you package the filter screens for export?
Each filter screen is individually wrapped in protective film, then packed in sturdy cartons or wooden crates depending on quantity. We ensure safe delivery to your port.
With our extensive experience and global reach, Anping County Boli Hardware Wiremesh Products Factory is your reliable partner for high-quality filtration solutions. We invite you to contact us for quotes, technical support, or custom orders. Our team is ready to assist you with your specific filtration needs.
