As a manufacturer with over 25 years of expertise, Anping County Boli Hardware Wiremesh Products Factory is proud to present our Industrial Edge-Wrapped Filter Screen, crafted from premium 304 stainless steel. This robust product features a 200 micron mesh size, 1000mm x 1000mm dimensions, and a 5 Bar pressure rating, making it ideal for demanding industrial filtration applications. Our edge-wrapped design ensures enhanced durability and easy installation, while the welded wire mesh construction provides consistent performance and long service life.
This filter screen is engineered to meet the rigorous needs of sectors such as chemical processing, water treatment, food and beverage, and oil and gas. With annual exports exceeding US$5 million and shipping to global markets via Tianjin, Qingdao, Shanghai, and Foshan, our products are trusted by clients across North America, Europe, Asia, and beyond. Below, we detail the key features, technical specifications, and benefits that set this filter screen apart.
Key Features and Benefits
- Premium 304 Stainless Steel: Offers excellent corrosion resistance and high tensile strength, suitable for harsh environments and repeated use.
- 200 Micron Precise Mesh: Ensures reliable particle retention (approx. 74 microns) for fine filtration, balancing flow rate and efficiency.
- Edge-Wrapped Construction: Reinforced edges prevent fraying and deformation, simplifying installation in frames or housings.
- Welded Wire Mesh: Each intersection is fusion-bonded, providing uniform openings and resisting shifting under pressure.
- 5 Bar Pressure Rating: Capable of withstanding up to 5 bar (approx. 72.5 psi) differential pressure, suitable for high-flow systems.
- Large 1000mm x 1000mm Panel: Reduces the number of seams needed, lowering installation time and potential leak points.
- Customizable Options: Available in different mesh sizes, dimensions, and edge treatments (e.g., folded, hemmed) upon request.
Technical Specifications
| Parameter | Value |
| Material | 304 Stainless Steel (SS304) |
| Mesh Opening | 200 Micron (0.200 mm) |
| Wire Diameter | Approx. 0.16 mm (typical for 200 mesh) |
| Panel Dimensions | 1000 mm × 1000 mm (39.4" × 39.4") |
| Maximum Operating Pressure | 5 Bar (72.5 psi) |
| Weaving Type | Welded (Resistance Welding) |
| Edge Finish | Edge-Wrapped (hemmed or folded edge) |
| Temperature Range | -20°C to +400°C (depending on media) |
Detailed Product Description
Our Industrial Edge-Wrapped Filter Screen is manufactured using precision welding technology that ensures each intersection is securely bonded, preventing mesh distortion even under high differential pressure. The 304 stainless steel offers excellent resistance to oxidation and many chemicals, making it a reliable choice for aggressive filtration environments. The edge-wrapped finish not only protects the screen edges from unraveling but also facilitates quick mounting in filter presses, housing frames, or custom assemblies.
The 200 micron mesh size is ideal for removing fine particulates while maintaining good flow rates. Typical applications include:
- Chemical and petrochemical filtration
- Water and wastewater treatment (including reverse osmosis pre-filtration)
- Food and beverage processing (e.g., juice, syrup, beer filtration)
- Pharmaceutical and biotech sieving
- Oil and gas sediment removal
- Mining and mineral processing
Compared to woven wire mesh, the welded construction offers superior dimensional stability and resistance to fraying. The 5 Bar pressure rating ensures the screen can handle moderate to high-pressure systems without bursting or deforming. Additionally, the large 1000x1000mm panel size reduces the number of joints required, lowering the risk of leakage and simplifying maintenance.
Why Choose Anping County Boli Hardware Wiremesh Products Factory?
Since 1998, we have been a dedicated manufacturer of wire mesh products, serving clients in over 20 countries and regions. Our annual export value of US$5-10 million reflects our commitment to quality and reliability. We ship from major Chinese ports (Tianjin, Qingdao, Shanghai, Foshan) to North America, Europe, Asia, Africa, and Oceania. Each filter screen undergoes rigorous quality control to ensure consistent mesh opening, uniform welding, and precise dimensions.
We offer flexible customization: different mesh sizes (from 50 to 500 micron), alternative stainless steel grades (316L available upon request), and various edge treatments (folded, hemmed, or with gasket). Our experienced team provides technical support to help you select the optimal screen for your specific application. With over 25 years of industry experience, we are confident in delivering products that meet your expectations.
Contact us today for a quote or sample. Whether you need a single panel or bulk orders, we are ready to serve you with competitive pricing and fast lead times.
Frequently Asked Questions (FAQ)
Q1: What is the exact opening size of 200 micron mesh?
A: 200 micron corresponds to 0.200 mm opening. For a 200 mesh screen (200 wires per inch), the typical opening is about 74 microns, but here "200 micron" refers to the nominal opening size. Please confirm with our technical team for exact specifications.
Q2: Can this filter screen be used for high-temperature applications?
A: Yes, 304 stainless steel can withstand temperatures up to approximately 400°C in continuous service, depending on the environment. For higher temperatures, we recommend 310S or 316L grades.
Q3: Is the edge-wrapped finish suitable for welding into a frame?
A: Absolutely. The edge-wrapped design provides a clean, reinforced edge that can be easily welded or clamped into place. It also helps prevent the mesh from fraying during installation.
Q4: What is the tolerance on dimensions?
A: Our standard manufacturing tolerance for panel dimensions is ±2 mm. For tighter tolerances, please discuss with our sales team.
Q5: Can you provide a sample for testing?
A: Yes, we offer sample pieces (e.g., 200x200 mm) for evaluation. Samples are available at a reasonable cost, which is refundable for bulk orders. Contact us for details.
Q6: What is the minimum order quantity (MOQ)?
A: For standard sizes, MOQ is 10 pieces. For custom dimensions, MOQ may vary. We are flexible and welcome small trial orders.
Q7: How do you ensure the mesh openings are consistent?
A: We use automated welding machines with precise positioning and conduct 100% visual inspection plus periodic mesh opening measurement with optical instruments. This ensures uniformity across the entire panel.
Q8: Does the product come with any certifications?
A: Our factory adheres to strict quality management systems. Specific certifications can be provided upon request based on your requirements. We are happy to discuss compliance with your industry standards.
