Help Center304 Stainless Steel Filter Screen 100 Mesh 0.15mm Wire Diameter for Liquid Filtration
Product Spotlights
Related Products
-
304 Stainless Steel Filter Screen for Food Processing Sanitary Grade Smooth SurfaceNegotiableMOQ: 500 Acres -
Stainless Steel Filter Screen 200 Mesh 0.5mm Thickness Corrosion Resistant Industrial UseNegotiableMOQ: 500 Acres
-
304 Stainless Steel Filter Screen 20 Mesh 1.5mm Wire Diameter 30% Open AreaNegotiableMOQ: 500 Acres
-
Stainless Steel Filter Screen 30 Micron 0.9mm Hole Diameter High Pressure 10 BarNegotiableMOQ: 500 Acres
-
Aluminum Embossed Net, 0.8mm Thickness, 4mm Hole, 1219x2438mm Sheet, Standard CompliantNegotiableMOQ: 500 Acres
As a leading manufacturer from Anping Xinye Metal Wire Mesh Products Co., Ltd, based in Hengshui, Hebei, China, we are proud to present our 304 Stainless Steel Filter Screen with 100 mesh and 0.15mm wire diameter. This precision-engineered woven mesh is specifically designed for efficient liquid filtration, offering reliable performance in demanding industrial environments. Our decades of experience in wire mesh production ensure consistent quality, tight tolerances, and excellent corrosion resistance, making this product a trusted choice for filtration systems worldwide.
The 100 mesh count provides a fine balance between flow rate and particle retention, effectively filtering out solid contaminants down to approximately 150 microns. The 0.15mm wire diameter contributes to the mesh's strength and durability, allowing it to withstand high pressure and repeated cleaning cycles. Whether you are filtering water, chemicals, oils, or food-grade liquids, this stainless steel filter screen delivers reliable performance and long service life.
Key Features & Technical Specifications
- Material: Premium 304 stainless steel – excellent corrosion resistance, suitable for acidic and alkaline liquids.
- Mesh Count: 100 mesh per linear inch (100 openings per inch).
- Wire Diameter: 0.15 mm (0.0059 inches) – provides strength while maintaining open area.
- Opening Size: Approximately 0.15 mm (150 microns) – allows fine filtration of particles.
- Weave Type: Plain weave – uniform openings and stable structure.
- Open Area: ~36% – ensures good flow rate for efficient filtration.
- Temperature Resistance: Up to 400°C (752°F) in continuous service (depending on environment).
- Available Forms: Rolls, sheets, cut pieces, or custom sizes per your requirements.
- Surface Finish: Annealed (bright) or as-woven; optional ultrasonic cleaning for high-purity applications.
| Parameter | Value |
|---|---|
| Mesh Count | 100 mesh |
| Wire Diameter | 0.15 mm |
| Opening Size (Micron) | ~150 μm |
| Open Area | ~36% |
| Material Grade | 304 Stainless Steel |
| Weave Pattern | Plain Weave |
| Max Temperature | 400°C (approx.) |
Advantages & Customer Benefits
- High Corrosion Resistance: 304 stainless steel withstands exposure to water, chemicals, and many solvents, extending service life in harsh environments.
- Easy to Clean & Reusable: The mesh can be backwashed, ultrasonically cleaned, or chemically cleaned, reducing replacement costs.
- Consistent Filtration Efficiency: Uniform openings ensure reliable particle retention, critical for quality control in liquid processing.
- Customizable Dimensions: We offer custom widths, lengths, and cut shapes to fit your specific filter housings or equipment.
- Cost-Effective Solution: Compared to disposable filter media, stainless steel mesh offers long-term savings with minimal maintenance.
- Wide Application Range: Suitable for water treatment, food & beverage filtration, pharmaceutical processing, chemical industry, oil filtration, and more.
- Strong Mechanical Strength: The 0.15mm wire diameter provides robustness against pressure differentials without deformation.
Our factory in Anping, Hebei – the “Wire Mesh Capital of China” – utilizes advanced weaving looms and strict quality inspection processes. Every roll of 304 stainless steel filter screen undergoes visual inspection and mesh count verification before shipment. We have been serving global clients for over a decade, supplying filtration meshes for industries ranging from municipal water treatment to petrochemical plants.
With a production capacity of 500,000 square meters per month, we can fulfill large orders with consistent lead times. Our quality control team samples each batch to ensure compliance with specified tolerances (±2% on mesh count, ±0.005mm on wire diameter). We also offer custom packaging (palletized, with moisture-proof wrapping) to protect the mesh during transit.
Frequently Asked Questions (FAQ)
-
Q: What is the exact micron rating of this 100 mesh screen?
A: The 100 mesh screen with 0.15mm wire diameter has an approximate opening of 150 microns. This is calculated based on the mesh count and wire diameter. For precise particle retention, we recommend testing with your specific application. -
Q: Can this screen be used for high-temperature filtration?
A: Yes, 304 stainless steel can withstand continuous service temperatures up to about 400°C (752°F) in air. However, the actual temperature limit depends on the environment (e.g., presence of corrosive gases). For higher temperatures, consider 316 or 310 stainless steel alternatives. -
Q: Is the screen available in custom sizes?
A: Absolutely. We offer custom widths from 0.5m to 2m, and lengths up to 30m per roll. We can also cut sheets or circles to your specifications. Please provide your required dimensions for a quotation. -
Q: How do I clean this filter screen?
A: The mesh can be cleaned by backflushing with water or air, ultrasonic cleaning, or soaking in mild acidic/alkaline solutions. Avoid abrasive brushes that may damage the weave. Rinse thoroughly after cleaning. -
Q: What is the typical lead time for this product?
A: For standard rolls (1m x 30m), we usually ship within 7-10 working days. Custom sizes may require 10-15 working days. Urgent orders can be expedited upon request. -
Q: Is this mesh suitable for food-grade applications?
A: 304 stainless steel is commonly used in food processing and is considered food-safe. However, if you require specific certifications (e.g., FDA), we can provide a material compliance statement based on our raw material certificates. Please confirm your requirements. -
Q: Do you provide samples before bulk order?
A: Yes, we offer free samples (A4 size or small roll) for evaluation, with the customer covering shipping costs. We recommend testing the sample under your actual filtration conditions. -
Q: What is the difference between plain weave and twill weave for filtration?
A: Plain weave offers a simple over-under pattern with maximum stability and uniform openings, ideal for general filtration. Twill weave has a diagonal pattern providing more flexibility and higher flow rate for certain applications. For 100 mesh, plain weave is standard.
At Anping Xinye Metal Wire Mesh Products Co., Ltd, we are committed to delivering high-quality stainless steel filter screens that meet your exact filtration needs. Our experienced team is ready to assist with technical advice, custom solutions, and competitive pricing. Contact us today to discuss your project or request a quotation.
Trust Anping Xinye – your reliable partner in wire mesh filtration since 2005. With over 200 skilled workers, 50 advanced looms, and a dedicated quality assurance department, we ensure every shipment meets the highest standards. Our products have been exported to 30+ countries, serving well-known companies in the water treatment, chemical, and food processing sectors. Choose our 304 stainless steel filter screen for consistent performance and long-term value.
