Help Center304 Stainless Steel Embossed Net, 0.5mm Wire Diameter, 2mm Mesh Opening, Industrial Filtration
Product Spotlights
Related Products
-
Galvanized Embossed Net, 1.2mm Thickness, 10x10mm Hole, 1000mm Width, Standard CompliantNegotiableMOQ: 500 Acres -
PVC Coated Embossed Net, 1.5mm Wire, 50mm x 50mm Mesh, UV Resistant, 20m RollNegotiableMOQ: 500 Acres
-
316L Stainless Steel Embossed Net, 1.0mm Wire, 6mm Mesh, 1.5m Width, Mill Test ReportNegotiableMOQ: 500 Acres
-
Embossed Net Used in Speaker Grille Fabrication, Aluminum Alloy, 1.2mm Thickness, 5mm HoleNegotiableMOQ: 500 Acres
-
Brass Embossed Net, 0.3mm Wire, 0.5mm Opening, 300mm Width, Precision FilteringNegotiableMOQ: 500 Acres
Anping Xinye Metal Wire Mesh Products Co., Ltd, located in the heart of China's wire mesh industry in Hengshui, Hebei, brings you a high-performance 304 Stainless Steel Embossed Net with a precise 0.5mm wire diameter and 2mm mesh opening. Engineered for demanding industrial filtration applications, this embossed mesh combines robust mechanical strength with excellent flow characteristics, ensuring reliable separation and long service life. Our advanced manufacturing process guarantees consistent mesh dimensions and superior corrosion resistance, making it a trusted choice for filtration systems across various sectors.
The embossed surface pattern not only enhances the structural rigidity of the mesh but also improves its ability to capture and retain particles without clogging. Whether you need to filter liquids, gases, or solids, this product delivers exceptional performance under harsh conditions. Backed by decades of industry expertise, Anping Xinye is your reliable partner for precision metal wire mesh solutions.
Key Features & Technical Specifications
| Property | Details |
| Material | 304 Stainless Steel (AISI) – excellent corrosion resistance |
| Wire Diameter | 0.5 mm (±0.02 mm tolerance) |
| Mesh Opening | 2 mm (square aperture) |
| Open Area | Approximately 64% (calculated based on wire and opening) |
| Surface Treatment | Embossed (raised diamond or rectangular pattern – customizable) |
| Weave Type | Plain weave (standard); twill weave available upon request |
| Roll Width | 1 m, 1.2 m, 1.5 m (custom widths available) |
| Roll Length | 30 m, 50 m, or customized per request |
| Temperature Range | -200°C to +800°C (continuous service) |
| Edge Treatment | Raw cut, welded edge, or plastic-coated – optional |
Product Advantages & Customer Benefits
- Enhanced Structural Integrity: The embossed pattern increases the mesh's rigidity, reducing deformation under high pressure or heavy loads. This means longer service life even in demanding filtration environments.
- Excellent Filtration Accuracy: With a precise 2mm mesh opening, the net effectively filters particles of that size while maintaining high flow rates. The open area of ~64% minimizes pressure drop, saving energy in continuous filtration systems.
- Superior Corrosion Resistance: Made from 304 stainless steel, the mesh withstands exposure to moisture, chemicals, and high temperatures, making it suitable for food processing, petrochemical, water treatment, and pharmaceutical industries.
- Easy to Clean & Reusable: The smooth embossed surface reduces particle adhesion, allowing quick backwashing or mechanical cleaning. This reusability lowers operational costs.
- Customizable Dimensions: We offer flexible roll widths, lengths, and edge finishes to match your specific equipment or installation requirements. Custom mesh opening sizes are also available for specialized applications.
- Cost-Effective Solution: Compared to woven wire cloth with similar specifications, our embossed net provides better mechanical strength per unit weight, reducing material usage while maintaining performance.
Suggested Applications
- Industrial liquid filtration (paint, ink, oil, chemicals)
- Gas filtration and air intake screens
- Solid particle sieving and grading
- Protective screens for machinery and enclosures
- Food and beverage processing (filtration of juices, syrups, etc.)
- Pharmaceutical and biotechnology filter supports
- Water treatment and wastewater screening
Trust & Reliability – Why Choose Anping Xinye?
As a leading manufacturer based in Hengshui, Hebei, Anping Xinye has been dedicated to producing high-quality wire mesh products for over 20 years. Our factory covers an area of 10,000 square meters and is equipped with advanced automatic weaving machines and inspection equipment. We strictly follow international quality standards, and every batch of raw material is tested for chemical composition and mechanical properties before production. With an annual output of over 500,000 square meters of stainless steel mesh, we serve clients from more than 30 countries worldwide.
We understand the critical role filtration plays in your operations. That's why we offer free samples for quality evaluation, technical support from our experienced engineers, and flexible packaging (plywood drums, cartons, or pallets) to ensure safe delivery. Our commitment to on-time delivery and responsive after-sales service has earned us long-term partnerships with many filtration system integrators.
Contact us today to discuss your specific filtration requirements. Whether you need a standard roll or a custom-designed embossed net, we are ready to provide a competitive quotation and fast turnaround. Let Anping Xinye be your trusted partner for industrial filtration solutions!
Frequently Asked Questions (FAQ)
-
Q: What is the difference between embossed net and plain woven wire mesh?
A: Embossed mesh has a raised pattern on the surface, which increases rigidity and reduces slippage. It also provides better particle retention in some filtration applications. Plain woven mesh is flat and more flexible. The embossed net is preferred when structural stability is critical. -
Q: Can I get a different mesh opening size than 2mm?
A: Yes, we can customize mesh openings from 0.5mm to 10mm for the same wire diameter, depending on the weave pattern. Please contact us with your specific requirements. -
Q: Is this product suitable for high-temperature filtration?
A: 304 stainless steel can withstand continuous temperatures up to 800°C, so it is suitable for many hot gas filtration applications. However, for extremely high temperatures or corrosive environments, we recommend 316 or 316L stainless steel, which we can also supply. -
Q: How do you package the mesh for export?
A: Standard packaging includes plywood drums or pallets with plastic film wrapping to prevent moisture and scratches. Custom packaging (e.g., wooden crates, cut pieces) is available upon request. -
Q: What is the minimum order quantity (MOQ)?
A: For standard sizes (1m width, 30m length), the MOQ is 1 roll. For custom sizes, the MOQ may be higher. Please inquire for details. -
Q: Do you provide samples before bulk order?
A: Yes, we offer free samples (A4 size or 200x200mm) for quality evaluation. The customer only needs to cover the shipping cost. Samples are usually dispatched within 2 working days. -
Q: Can this mesh be used for food contact?
A: 304 stainless steel is food-grade and complies with international standards such as FDA and EU regulations. It is safe for direct contact with food products during processing. -
Q: What is the lead time for production?
A: For standard products, lead time is 7-10 working days after order confirmation. For customized orders, it is typically 15-20 working days, depending on complexity and quantity.
