Help CenterBrass Embossed Net, 0.3mm Wire, 0.5mm Opening, 300mm Width, Precision Filtering
Product Spotlights
Related Products
-
Embossed Net With 12-Month Warranty, 316SS, 1.0mm Wire, 20mm x 20mm, Technical SupportNegotiableMOQ: 500 Acres -
Expanded Metal 1 Year Warranty 4x8ft Sheets 1/2" x 1" Diamond 16 Gauge With Mill Test ReportNegotiableMOQ: 500 Acres
-
Expanded Metal Catwalk Grating 2"x3" Opening 13 Gauge 4x8ft Load Capacity 300psf for Industrial FlooringNegotiableMOQ: 500 Acres
-
Aluminum Expanded Metal 5052 H32 0.5" x 1" Diamond 0.040" Thickness for Architectural ScreeningNegotiableMOQ: 500 Acres
-
Expanded Metal Screen Mesh 1/4" x 1/2" Opening 24 Gauge Stainless Steel for Machinery GuardingNegotiableMOQ: 500 Acres
Anping Xinye Metal Wire Mesh Products Co., Ltd, located in the wire mesh capital of China – Hengshui, Hebei, proudly presents our Brass Embossed Net with 0.3mm wire diameter, 0.5mm opening and 300mm width. This precision filtering mesh is engineered to deliver consistent and reliable performance in demanding separation and filtration applications. Leveraging over a decade of wire mesh manufacturing expertise, we combine strict quality control with advanced embossing technology to produce a mesh that offers both structural integrity and fine filtration accuracy.
Our brass embossed net is not just a simple wire mesh; it is a carefully crafted product where each wire is precisely positioned and then embossed to create a uniform, stable opening. The 0.5mm opening size makes it ideal for separating fine particles, while the 0.3mm wire diameter ensures adequate strength without excessive weight. Whether you need it for liquid filtration, gas diffusion, or as a protective screen, this mesh delivers consistent results.
In the following sections, we will detail the product specifications, key advantages, and the value we bring as your trusted manufacturer. Let us show you why Anping Xinye is the right partner for your precision filtering needs.
Product Specifications
| Parameter | Value |
| Material | Brass (C26000 / C26800 available) |
| Wire Diameter | 0.3 mm (±0.01 mm tolerance) |
| Opening Size | 0.5 mm (square) |
| Mesh Count | Approximately 40 mesh (based on opening + wire) |
| Width | 300 mm (custom widths up to 1000 mm available) |
| Length per Roll | Standard 30 m, custom lengths available |
| Surface Finish | Embossed (pattern enhances rigidity and flatness) |
| Open Area | ~39% (calculated) |
Key Features & Benefits
- Precision Filtration Accuracy: The 0.5mm opening ensures consistent particle size control, suitable for separating fine solids from liquids or gases.
- Corrosion Resistance: Brass material offers good resistance to oxidation and many chemicals, making it ideal for humid or slightly aggressive environments.
- Enhanced Mechanical Strength: The embossing process creates a rigid mesh structure that resists deformation under pressure, maintaining its shape during use.
- Excellent Flow Rate: With an open area of approximately 39%, the mesh allows efficient passage of fluid while retaining particles.
- Easy to Clean: The smooth brass surface and uniform openings make the mesh easy to backwash or clean mechanically.
- Flexible Sizing: Standard width of 300 mm can be cut to smaller sizes or supplied in wider rolls (up to 1000 mm) upon request.
- Consistent Quality: Each roll is inspected for wire diameter, opening uniformity, and mesh integrity before shipment.
Typical Applications
- Industrial liquid filtration (e.g., coolant, oil, water treatment)
- Gas and air filtration (e.g., vent screens, diffuser elements)
- Protective screening for electronic components or sensors
- Sieving and grading of powders and granules
- Laboratory test sieves and sample preparation
- Decorative and architectural mesh (with brass aesthetic)
Why Choose Anping Xinye?
Anping Xinye Metal Wire Mesh Products Co., Ltd is a professional manufacturer with years of experience in producing high-quality wire mesh. Our factory is located in Anping, Hebei – the world-renowned “Wire Mesh County” – where we benefit from a mature supply chain and skilled workforce. We understand that every filtration application is unique, so we offer customization options including different brass alloys, roll lengths, and edge treatments (e.g., welded edges or hemmed edges).
We take pride in our strict quality management system. Each batch of brass embossed net undergoes dimensional checks, tensile strength testing, and visual inspection. Our team is committed to delivering products that meet your specifications consistently. We also provide samples for testing before bulk orders, ensuring full compatibility with your process.
Customer satisfaction is our top priority. We offer competitive pricing, timely delivery, and responsive after-sales support. Whether you need a small experimental roll or large-scale industrial supply, we are ready to serve you. Contact us today to discuss your brass embossed net requirements and experience the Anping Xinye difference.
Frequently Asked Questions
Q1: What is the difference between brass embossed net and plain brass wire mesh?
A: Brass embossed net undergoes an additional embossing process that creates slight indentations on the wire surface, increasing the mesh’s rigidity and flatness. Plain brass mesh is typically woven without embossing, which may result in a more flexible structure. Embossed net is preferred for applications requiring structural stability under pressure.
Q2: Can this mesh be used for high-temperature filtration?
A: Brass has a melting point around 900–950°C, but for continuous use, we recommend temperatures below 200°C to avoid oxidation and loss of strength. For higher temperature applications, please consult us for alternative materials like stainless steel.
Q3: Is the 0.5mm opening accurate for sieving particles of exactly 0.5mm?
A: The opening size is nominal and may vary within ±0.02 mm due to manufacturing tolerances. For precise sieving, we recommend using a slightly smaller opening (e.g., 0.4 mm) to ensure retention of 0.5 mm particles. We can supply custom opening sizes upon request.
Q4: What widths are available besides 300 mm?
A: We can produce rolls from 100 mm up to 1000 mm in width. Custom widths require a minimum order quantity. Please contact our sales team for details.
Q5: How is the mesh packaged for export?
A: The mesh is wound on sturdy cardboard cores, wrapped with protective paper or plastic film, and then packed in wooden crates or pallets to prevent damage during transit. We also offer custom packaging options (e.g., individual cut sheets) for small orders.
Q6: Can you provide samples before bulk order?
A: Yes, we offer free samples (A4 size or 100×100 mm) for evaluation. The customer only needs to cover shipping costs. Samples are available within 5–7 working days after request.
Q7: Is this brass mesh food-grade?
A: Brass is generally considered safe for incidental food contact, but it is not recommended for prolonged contact with acidic foods due to potential copper leaching. For food-grade applications, we can supply stainless steel or food-grade nylon mesh. Please confirm your specific requirements.
Q8: What is the lead time for standard orders?
A: For standard 300 mm width, 30 m roll length, the lead time is typically 10–15 working days after order confirmation and payment. Custom sizes or large quantities may require 20–25 working days.
