Industrial Fast Food Microwave Drying Machine Food Grade SUS304 Continuous Drying Equipment
Our Industrial Microwave Drying Machine is specially designed for fast food, ready-to-eat products, snacks, baked foods, instant foods, and convenience foods. The system combines rapid moisture removal and optional sterilization in a continuous production process, helping improve production efficiency while maintaining product quality.
Manufactured with food-grade SUS304 stainless steel, the equipment meets high hygiene standards and is suitable for modern food processing plants. The PLC intelligent control system ensures stable operation, precise process control, and consistent drying performance.
Key Features
Food-grade SUS304 stainless steel construction
Continuous automatic drying
Rapid and uniform microwave heating
Optional drying and sterilization in one process
PLC touch-screen intelligent control
Adjustable microwave power
Adjustable conveyor speed
Energy-efficient operation
Stable 24-hour continuous production
Easy cleaning and maintenance
Customized machine configuration
OEM & ODM manufacturing
CE-compliant design available
Suitable Products
The equipment is suitable for:
Fast Food Products
Ready-to-Eat Meals
Snack Foods
Fried Snacks
Baked Foods
Instant Noodles
Bread Crumbs
Biscuits
Crackers
Cereal Products
Pet Food
Dehydrated Vegetables
Other food products requiring controlled moisture reduction
Working Principle
Microwave energy penetrates the food and directly heats internal moisture, allowing water to evaporate rapidly from the inside out. Compared with conventional hot-air drying, microwave drying can provide faster and more uniform moisture removal for suitable products. Process parameters can also be adjusted to assist with microbial reduction where required.
Applications
Widely used in:
Fast food factories
Snack food manufacturers
Ready meal production plants
Bakery processing facilities
Frozen food manufacturers
Central kitchens
Food ingredient suppliers
-
Commercial food processing enterprises
Technical Specifications
Machine Model |
GS-20HMV |
GS-40HMV |
GS-60HMV |
GS-100HMV |
GS-200HMV |
Work Frequency |
2450±50MHZ |
2450±50MHZ |
2450±50MHZ |
2450±50MHZ |
2450±50MHZ |
Rated Apparent Power |
≤25KW |
≤50KW |
≤75KW |
≤120KW |
≤240KW |
Output Power |
≥20KW |
≥40KW |
≥60KW |
≥100KW |
≥200KW |
Dehydration Capacity |
16-20kg/hour |
30-40kg/hour |
48-60kg/hour |
80-100kg/hour |
160-200kg/hour |
Work Process Temperature |
70-200℃ |
70-200℃ |
70-200℃ |
70-200℃ |
70-200℃ |
Cooling Type |
Water Cool/Air Cool |
Water Cool/Air Cool | Water Cool/Air Cool | Water Cool/Air Cool | Water Cool/Air Cool |
Work Time |
24h Continuously Work |
24h Continuously Work | 24h Continuously Work | 24h Continuously Work | 24h Continuously Work |
Operation |
PLC & Touch Screen |
PLC & Touch Screen | PLC & Touch Screen | PLC & Touch Screen | PLC & Touch Screen |
Feeding Inlet Height |
40-100mm |
40-100mm | 40-100mm | 40-100mm | 40-100mm |
Belt Height |
60-1000mm |
60-1000mm | 60-1000mm | 60-1000mm | 60-1000mm |
Belt Running Speed |
0-4.5m/min or Customized |
0-4.5m/min or Customized | 0-4.5m/min or Customized | 0-4.5m/min or Customized | 0-4.5m/min or Customized |
Belt Width |
500±100mm |
800±100mm |
800±100mm |
1000±100mm |
1200±100mm |
Belt Material |
Teflon Material or Customized |
Teflon Material or Customized | Teflon Material or Customized | Teflon Material or Customized | Teflon Material or Customized |
Size |
8640×1220×2200mm |
10960×1500×2200mm |
13200×1500×2200mm |
15600×1700×2200mm |
22560×1900×2200mm |
Remark: Above parameter is for reference. All microwave dryer specific parameter need to be designed based on customer’s specific industrial request
Fast Food Microwave Drying Machine
Industrial Microwave Dryer
Food Microwave Drying Equipment
SUS304 Stainless Steel Dryer
Microwave Sterilization Machine
Food Processing Equipment
Continuous Microwave Dryer
Industrial Food Dryer
Microwave Moisture Removal Machine
Ready-to-Eat Food Dryer
Snack Food Drying Machine
Food Dehydration Equipment
PLC Microwave Dryer
Continuous Belt Dryer
Industrial Microwave Oven
Food Grade Drying Machine
Energy Saving Food Dryer
OEM Microwave Dryer
Food Manufacturing Equipment
Industrial Drying System
Optional Configurations
To meet different production requirements, the microwave drying line can be equipped with:
Automatic feeding system
Multi-layer conveyor structure
Infrared temperature monitoring
Cooling conveyor section
Moisture detection system
Remote control module
Data acquisition system
Automatic unloading system
Why Choose Our Microwave Drying Machine?
Professional industrial microwave equipment manufacturer
Factory-direct competitive pricing
Food-grade hygienic design
Customized engineering solutions
Stable continuous production
Installation guidance and operator training
One-year warranty
Lifetime technical support
Exported to customers worldwide
FAQ
Q1: What food products can this machine process?
It is suitable for snack foods, ready-to-eat meals, baked products, cereals, bread crumbs, dehydrated vegetables, and many other food products.
Q2: Why is SUS304 stainless steel used?
SUS304 stainless steel offers excellent corrosion resistance, durability, and hygienic performance, making it widely used in food processing equipment.
Q3: Can the machine be customized?
Yes. We provide customized solutions for capacity, conveyor dimensions, microwave power, voltage, and factory layout.
Q4: Do you provide OEM & ODM services?
Yes. We offer complete OEM & ODM services, including customized machine design, branding, and turnkey production line solutions.
We are the manufactuer of Industrial Microwave Dryer, we can supply different kinds of microwave drying machine, like batch microwave oven for lab use or for
small capacity industrial use, industrial automatic tunnel mircrowave dryer, vaccum dryer specially for food & pharma industry etc. We have more than 10 years
experience on export, export to all over the world, like USA, Canada, Russia, India, Sri Lanka, Turkey, Vietnam, Indonesia, Pakistan,Philippines, Brazil, Egypt,
Czech, Singapore, Armenia, Iraq, Iran, Malaysia, Bangladesh, Mexico, Peru, Algeria, Poland, Thailand, Nepal, Azerbaijan etc.
