MC300-G01-U2-P1-C01 is a pressure controller, featuring high precision, fast response, and long-term stability.
By adopting Yokogawa's unique silicon resonant sensor and a control system using a needle valve, its relative output accuracy can reach 0.04%.
In addition to excellent linearity and repeatability, it can also achieve smooth pressure control, minimizing the overshoot until the target setpoint is reached.
Two optimized models are suitable for different pressure ranges
Model for gauge pressure range of 10 kPa
Model for gauge pressure range of 200 kPa
Excellent linearity and repeatability
MC300 is supported by Yokogawa's proprietary sensing technology - a combination of a silicon resonant sensor and a precision needle valve process control - with a relative output accuracy of ±0.04%, ensuring long-term stability for up to one year. Extremely low hysteresis, excellent linearity, and high repeatability ensure stable and reliable pressure control during long-term operation.
I. Core Positioning
Product type: Pneumatic pressure controller (standard pressure generator).
Core technology: Built-in Yokogawa self-developed silicon resonant sensor + needle valve servo actuator to achieve closed-loop precision control.
Accuracy level: Relative output accuracy of ±0.04%, with an accuracy guarantee period of 12 months.
II. Key Parameters
Pressure range (gauge pressure):
Low-pressure type: 0～10 kPa
Standard type: 0～200 kPa (other ranges are optional)
Control characteristics:
Stability: Extremely low long-term drift, suitable as a standard source in laboratories / production lines
Response: High-speed pressure reaching, small overshoot, and smooth pressure curve
Output medium: Clean and dry air (nitrogen is optional).
Display and operation: High-definition LCD, supporting digital setting, real-time pressure display, and status monitoring.
With precision needle valve control, MC300 can reduce the risk of overpressure of the device under test caused by rapid pressurization through smooth process control. Even when approaching the setpoint, it can still maintain fine pressure control, thereby minimizing overshoot as much as possible while achieving a response time of less than 5 seconds
The pressure control part of MC300 uses a needle valve servo mechanism, which can adjust the airflow through the needle position to regulate the output pressure. Different from the solenoid valve system that relies on rapid on/off operations,
the needle valve can move continuously and smoothly. This design achieves stable pressurization and depressurization processes while minimizing wear, thus ensuring long-term stable operation.
III. Main Functions
Basic control: Fixed-point pressure control, Auto-step, Sweep, and segmented output.
Advanced features:
Micro negative pressure output (expand vacuum testing capabilities)
Output status monitoring and external alarm/control signals
It can be linked with the MT300 digital pressure gauge to achieve high-precision calibration automation.
4. Typical applications
Calibration and factory testing of pressure sensors/transmitters
Medical equipment: Accuracy verification and pressure simulation of electronic blood pressure monitors
Air tightness testing: Leak detection of small cavities and pipelines
Industrial automation: Pressure closed-loop control of precision pneumatic systems
